  • Page 1 Instruction Manual Backup Camera System With Flush Mount Camera And Mirror Monitor RVS-509620 RVS Systems, Inc. © 2017 Reverse With Confidence ™...
  • Page 2 TV viewer or screen located forward of the back of the driver’s seat or in any location that is visible, directly or indirectly, to the driver while operating the vehicle. RVS Systems Reverse With Confidence ™...
  • Page 3: Installation

    System. If you back up while looking a metal case, cover the cable with • Dropping the unit may cause only at the monitor, you may cause friction tape. A short circuit possible mechanical failure. RVS Systems Reverse With Confidence ™...
  • Page 4 Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility RVS Systems of them being damaged while vehicle is in use. Keep all cables away 1797 Atlantic Avenue from hot or moving parts and electrical noisy components.
  • Page 5 Fasten all cables and secure all excess cable. Connect camera to the • Feed as much cable as possible into vehicle & clamp securely. This reduces the possibility of cable being hooked or snagged. camera extension cable which runs inside the vehicle. Figure 1.2 RVS Systems Reverse With Confidence ™...
  • Page 6 0.2M space from the car. FIGURE 1.2 Accuracy Distance grid line accuracy may vary based on your camera angle. Adjust the distance grid lines to fit your application. RVS Systems Reverse With Confidence ™...
  • Page 7 FIGURE 2.1 FIGURE 2.2 1. RED- Power (+) 2. YELLOW- Video 3. GREEN- Mirror / Normal Imaging 4. WHITE- Audio 5. BLACK- Ground (-) RVS Systems Reverse With Confidence ™...
  • Page 8: Specifications

    16:9 in water Color Depth: 16.7M dithering • Heavy duty metal Pixel Pitch (mm) 0.219x0.219 Power Consumption: Working Voltage: DC 9V-32V VIDEO-IN to GPS/DVD Video Input: (Default) Camera to backup camera Signal System: PAL/Auto/NTSC RVS Systems Reverse With Confidence ™...
  • Page 9 Verify that the green positive Auto trigger on power harness is set to re- Auto verse power 12v+ S/N Ratio More than 48dB Video Output CVBS Signal 1.0vp-p Impedance 75Ω Power Supply DC 9V-32V RVS Systems Reverse With Confidence ™...
  • Page 10 TO NORMAL WEAR AND TEAR, THIS DAMAGE IS DUE TO ABUSE, IMPROPER MAINTENANCE, REARWARD CLEARANCE AND THAT YOUR VEHICLE CAN MANEUVER SAFELY. NEGLECT OR ACCIDENT; OR THE DAMAGE IS DUE TO USE OF THE RVS SYSTEMS, INC. SYSTEM RVS SYSTEMS AND/OR ITS AFFILIATES SHALL HAVE NO RESPONSIBILITY OR LIABILITY AFTER PARTIAL FAILURE OR USE WITH IMPROPER ACCESSORIES.
  • Page 11 If you have any questions about this product, contact: RVS SYSTEMS, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 888.881.2601 Better Cameras. Better Service. IT’S OUR GUARANTEE. RVS Systems...
