L-39
Specifications:
Wingspan: 900mm (35.4")
Overall Length: 810mm (31.9")
Includes:
Painted fibreglass fuselage
•
Factory built and covered balsa wings and tail
•
Assembled ducted fan unit and motor
•
Pushrods and linkages
•
Clear hinge tape
•
Bungee launching system
•
http://www.jperkinsdistribution.co.uk
IMPORTANT!
!
Radio controlled model!
NOT A TOY!

Instruction Manual

This high performance model
must be assembled and operated
according to the instructions.
EDF
Electric Ducted Fan
http://www.modelengines.com.au
May cause serious injury to persons or
property if not used responsibly.
Unsuitable for children under 14 years.
