Sea Vixen
Specifications:
Wingspan: 835mm
Overall Length: 930mm
Includes:
Four Channel FM Radio (installed)
Three Micro Servos (installed)
Brushless Out Runner Motor (installed)
Electronic Speed Controller (installed)
Lithium Polymer Flight Battery
Dedicated Lithium Polymer, Balance Type, Battery Charger
AC Power Adapter
Spare Propeller
IMPORTANT!
!
Radio controlled model!
NOT A TOY!

Instruction Manual

http://www.modelengines.com.au
This high performance model
must be assembled and operated
according to the instructions.
May cause serious injury to persons or
property if not used responsibly.
Unsuitable for children under 14 years.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sea Vixen and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Model Engines Sea Vixen

Summary of Contents for Model Engines Sea Vixen

  • Page 1: Instruction Manual

    Sea Vixen Instruction Manual Specifications: Wingspan: 835mm Overall Length: 930mm Includes: Four Channel FM Radio (installed) Three Micro Servos (installed) Brushless Out Runner Motor (installed) Electronic Speed Controller (installed) Lithium Polymer Flight Battery Dedicated Lithium Polymer, Balance Type, Battery Charger...

  • Page 2: Items Required

    Please note that, whilst every effort is made to ensure the accuracy of instructions and material included with this product, mistakes can occur and neither Model Engines (Aust.) Pty. Ltd nor it’s distributors will be held liable for any loss or damage arising from the use of this model or for any loss or damage arising from omissions or inaccuracies in the associated instructions or materials included with this product.
  • Page 3 Contents Four channel FM transmitter Tail plane assembly 240V AC power adapter Lithium Polymer battery charger Lithium Polymer flight battery Right hand wing panel Fuselage assembly Left hand wing panel Left hand tail boom 10. Right hand tail boom...
  • Page 4 Wing Assembly Turn the fuselage assembly upside down and line up the wing panels. Connect the servo lead to the pre-installed servo extension lead in the fuselage. Peel the backing off the double tape to secure the servo lead once the wings are joined. Lay the white front and rear wing joiners in position as shown.
  • Page 5 Lay the grey upper wing joiners in position and secure with the screws provided. Please note that the metal screws are used for the rear joiners and nylon screws for the front. Push the servo connector and lead into place. Fitting the Tail Booms Slide the tail booms into place.
  • Page 6 Fitting the Landing Gear The Sea Vixen can be hand launched and belly landed or the landing gear can be used. If using the landing gear, slide the landing gear wire into the supports as shown.
  • Page 7 Charging the Flight Battery The included battery charger can operate from a 12VDC power source, such as a car battery, or from the included 240VAC power adapter. If operating the charger from a 12VDC power source, connect the alligator clips to the terminals.
  • Page 8 Checking the Transmitter Operation and Flight Controls Load 8 x AA size alkaline batteries into the transmitter. Transmitter control layout for Mode 1 radio: Rudder Control* Elevator Control Rudder Trim Lever* Elevator Trim Lever Throttle Trim Lever Aileron Control Throttle Control Aileron Trim Lever Battery Indicator 10.
  • Page 9 Connect the flight battery to turn on the model. Slide the battery into position and secure by fitting the hatch cover. Make sure that all of the trim levers are in the centre and check that each flight control is centred.
  • Page 10 Neutral To check that the ailerons move in the right direction, view the model from behind and move the aileron control stick. When the aileron control stick is moved to the right, the left hand aileron will move downwards and the right hand aileron will move up. Right aileron applied When left aileron is applied, the left hand aileron will move up and the right hand aileron...
  • Page 11 • Do NOT run the flight battery down completely. Lithium Polymer batteries can be damaged by over discharging them • Only fly this model in areas where the flying of RC models is permitted. • This model is NOT a TOY and is recommended for experienced RC pilots. If you are relatively new to RC flying, seek assistance from an experienced RC pilot.
