- Page 1 Instructions Manual Quick Guide: Field Hawk Refer Questions to Support@Aero-hawk.com Aero-hawk.com...
-
Page 2: Disclaimer And Warning
Disclaimer and Warning This product is NOT a toy and is not suitable for children under the age of 18. Adults should keep the Aero Hawk UAV out of the reach of children and exercise caution when operating this aircraft in the presence of children. It is highly recommended that any pilot using this product have a Small Unmanned Aircraft System- Remote Pilot Airman Certificate. -
Page 3: What's Included
You will receive your drone in its special ordered case. Please go through the list and insure you have received everything you purchased. ❏ Instruction manual ❏ Aerohawk M4HR camera ❏ Usb Cable ❏ Field Hawk ❏ Windows Surface Tablet ❏ Remote Control with batteries ❏ 8x Propellers ❏... - Page 4 Field Hawk Diagram Features: • Pixhawk 2 Autopilot • HERE GNSS • 10000MaH Or 5200MaH 4S Lipo Battery • 26 Minute Flight Time • Carbon Fiber Construction Propellor 10. M4HR 4 Camera Array • 4X8mp Camera’s Motor 11. M4HR Power Wire •...
-
Page 5: Important Battery Information
IMPORTANT BATTERY INFORMATION How to setup your charger to charge lipo batteries. Press Enter Press & hold Beeps when full or Press Enter Check your Enter time limit is reached battery Full battery-16.8V Near empty-13.6V Setup Plug the yellow connectors together, and PROPER CHARGE Insert balance lead in the appropriate We recommend charging the 4S batteries at (1.5-3.5amps). - Page 6 Remote Control Diagram 12.Battery Cover Features: 1.Power Switch 13.Earphone Port • 2.4Ghz 2.Strap Hook 14.Trainer Port • High Range above 1.5Km 3.Digital Trim Adjustment 15.Remote Control Battery Voltage • Quad Ball Bearing Gimbals 4.Carrying Handle 16.Remote Signal Strength Indicator (RSSI) •...
-
Page 7: Remote Control Use
Remote Control Use Remote Batteries REMOTE BASICS Sticks can be used in any flight mode, for It is recommended to Left Stick Right Stick small adjustments. Ex: charge for 8 hours. Do Commands Commands avoidance landing not turn on while charging. - Page 8 Compass Calibration You May/will need to calibrate the compass for your region. Follow the steps below to calibrate your Field Hawk. Calibration must be performed in an area that is at least 20 meters from Metal ITEMS NEEDED: Objects and buildings. For a Video on how to calibrate your Field Hawk visit •...
- Page 9 Compass Calibration Part 2 7. Begin by physically moving 8. Start by grabbing the Field Hawk by an arm and spinning it 360°. Do this to each the drone around as outlined arm. Then spin it upright and upside down and repeat until Mission Planner asks you next.
-
Page 10: Creating A Flight Plan
Creating a Flight Plan →https://youtu.be/MhHomssqD7k 1. Open Mission Planner on Laptop 2. Right click on the screen and 3. Left click around the edges of your 4.Right click and select Auto and click on flight planner tab. choose add Polygon Point. field to chose your flight area. - Page 11 Led Symbol Guide Yellow Symbols: Yellow and Blue Symbol with tone: -Double Flashing: Failing pre arm checks -Gps Glitch or Gps Failsafe activated -Single Flashing: Radio Failsafe activated. -Flashing with tone: Battery Failsafe activated. Blue Symbols: Red and Yellow Symbol with tone: -Flashing: Disarmed, No gps lock -Ekf or Inertial Nav failure -Solid:armed, No gps Lock...
- Page 12 2. Plug the Battery back into the Field 1. Once you have created your 3. Turn on the Remote Control. The LED indicators on the Hawk and place the Field Hawk on the mission & Uploaded it to your camera and drone will turn GREEN when ready.
- Page 13 2. Press the connect button then press proceed. Field Hawk and open the AeroHawk File Transfer This will warn you that it will disconnect you from Wizard on your Laptop. For a faster upload of an your current Wifi network to connect to the Field individual camera, you can connect to the individual Hawk’s Wifi, unless you chose to upload via usb.
- Page 14 Using AeroHawk Maps Watch the Video►https://www.youtube.com/watch?v=K9OW6jiX6SA 1.Locate Aero Hawk Maps in the start menu, right click and 2. Select the group individual indexes 3. Select Browse folder 4. Select Read images. If you open as administrator. After the initial setup you will not you would like to view.
