Overview

Figure 1: Outer Case Description of Polaris
Figure 2: Inner Body Description of Polaris
POLARIS USER MANUAL
4
Specifications Specifications
GPS Receiver:
Acquisition Time:
Update Rate:
Accuracy:
Antenna:
Physical Size:
Power:
Battery Duration:
Temperature Range:
POLARIS USER MANUAL
L1 band (1575.42MHz),
C/A code, 12-channel
Hot start: <10sec
Warm start: < 40sec
Cold start: <120sec
1 Hz, continuous
Position : 10m CEP S/A off
Velocity : 0.1/sec S/A off
Time : 1ms
Built-in patch
131.4mm (H), 61.8mm (W)
28mm (D),
Three 1.5V AAA Batteries
16 hours
0 0
-15 C to + 70 C
21
