Host Application Objects
9.2

Modbus Host Object (FAh)

Category
Extended
Object Description
This object implements Modbus related settings in the host application.
The implementation of this object is optional; the host application can support none, some, or all of the attrib-
utes specified below. The module will attempt to retrieve the values of these attributes during startup; if an at-
tribute is not implemented in the host application, simply respond with an error message (06h, "Invalid
CmdExt[0]"). In such case, the module will use its default value.
If the module attempts to retrieve a value of an attribute not listed below, respond with an error message
(06h, "Invalid CmdExt[0]").
See also ...
• Anybus CompactCom 40 Software Design Guide, "Error Codes"
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance no.
®
Anybus CompactCom ™ 40 Modbus-TCP
Get_Attribute
Process-modbus-message
Get_Attribute
Access Data Type
Get Array of
CHAR
Get UINT8
Get UINT16
Get UINT16
®
Transparent Ethernet Network Guide
Value
"Modbus"
01h
0001h
0001h
41 (70)
SCM-1202-022 1.1
