2.3.1 OMNI board jumper settings

As previously mentioned, a jumper is a connector that, when placed over two jumper pins,
provides continuity. On the OMNI board, jumpers are used to set various functions on the
board. The OMNI board jumpers range from JP1 to JP13. Tables 3, 4, and 5 outline the
jumpers and IRQs (computer interrupt settings) associated with each function and the
appropriate settings. Table 6 outlines the setting for switch S1.
Table 3. Jumper numbers and corresponding IRQ numbers used by the seismograph trigger.
Jumper JP4 and IRQ 11 is the normal selection.
Jumper no.
JP3
JP4
JP5
JP6
All of the acquisition boards in the system must be set to the same IRQ as the OMNI board.
This IRQ must not conflict with any other IRQ used by the system.
Table 4. Jumper numbers and corresponding IRQ numbers used by the seismograph keypad.
Jumper JP7 and IRQ 10 is the normal selection.
Jumper no.
JP7
JP8
JP9
JP10
TM
SmartSeis Maintenance Manual
IRQ no.
IRQ 10
IRQ 11
IRQ 12
IRQ 15
IRQ no.
IRQ 10
IRQ 11
IRQ 12
IRQ 15
15
