Sony XTL-750W Operating Instructions Manual

Mobile color tv
Hide thumbs Also See for XTL-750W:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, Operating Instructions Manual
Mobile Color TV
Operating Instructions
###
Owner's Record
The model and serial numbers are located on the bottom of the unit.
Record the serial number in the space provided below.
Refer to these numbers whenever you call upon your Sony dealer regarding this
product.
Model No. XTL-750W Serial No.
For installation and connections, see the supplied installation/connections
manual.
# # #
# # #
XTL-750W
© 1999 by Sony Corporation
GB
CT

Advertisement

Table of Contents
loading

Related Manuals for Sony XTL-750W

Summary of Contents for Sony XTL-750W

  • Page 1 The model and serial numbers are located on the bottom of the unit. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. XTL-750W Serial No.
  • Page 2 Warning WARNING To prevent fire or shock hazard, do not expose the unit to rain or This equipment has been tested and moisture. found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 Welcome! Thank you for purchasing the Sony Mobile Color TV. • This unit can receive the TV broadcasts in the USA, China or Hong Kong, the country depending on the model. • You can connect both PAL and NTSC video playback units (China only).

  • Page 4: Table Of Contents

    Table of Contents Warning and Precautions ..................5 Getting Started Selecting a TV system (China only) ............6 Storing TV stations automatically (Automatic memory function) ..7 Watching a TV Program ..................8 Viewing the Wide Screen ..................9 Watching a Video ....................11 Listening to the TV/video Sound with the Picture Off (Visual off function) ..................

  • Page 5: Warning And Precautions

    If you have any questions or problems concerning your unit that are not covered in this manual, please consult your nearest Sony dealer. Preventing accidents The TV/video pictures appear only after you park the car and set the parking brake.

  • Page 6: Getting Started

    Getting Started Selecting a TV system (China only) If you select the TV system, press (CHN/HKG) on the wireless remote. If there is no sound, press (CHN/HKG) again. When you select the TV system, the TV program numbers appear as follows. China Hong Kong CHN/HKG...

  • Page 7: Storing Tv Stations Automatically (Automatic Memory Function)

    Storing TV stations automatically (Automatic memory function) You can store up to 12 VHF/UHF stations. VHF stations on program numbers 1 through 12 are stored on the program number buttons. UHF stations on program numbers 21 through 69 (13 through 57 for China, 14 through 69 for USA) are stored in order after the stored VHF stations.

  • Page 8: Watching A Tv Program

    Watching a TV Program Note The TV picture does not appear while the car is moving for safety reasons. NAVI TV/VIDEO CHN/HKG SEEK button SEEK DSPL button V OFF A.MEM DSPL 2SEC POWER indicator Press (POWER). The POWER indicator lights up. Press the program number buttons (1 through 12) to select the desired TV station.

  • Page 9: Viewing The Wide Screen

    Viewing the Wide Screen In addition to normal screen mode, full screen, zoom screen, and wide-zoom screen modes are also available. SELECT button Press the SELECT button. Pressing the SEL button switches the screen mode in the following sequence: Normal (regular) screen Full screen An image with an aspect ratio An image with an aspect ratio...
  • Page 10 (Continued) • Images may appear coarse-grained when viewed in the zoom screen mode. • This unit is manufactured according to wide-zoom specifications for typical home-use wide TV sets. • Changing the screen mode will also change the scale of the map screen on your navigation system.

  • Page 11: Watching A Video

    Watching a Video Note The video picture does not appear while the car is moving for safety reasons. You can watch video CDs and cassettes recorded in either the PAL or NTSC color system (China only). Make sure a video player is correctly connected to the TV tuner unit.

  • Page 12: Listening To The Tv/Video Sound With The Picture Off (Visual Off Function)

    Listening to the TV/video Sound with the Picture Off (Visual off function) NAVI TV/VIDEO CHN/HKG SEEK V OFF A.MEM DSPL V (visual) OFF button 2SEC Press (V OFF) for two seconds. Only hear the sound of the selected program is heard. To cancel the visual off function, press (V OFF) again.

  • Page 13: Adjusting The Picture

    Adjusting the Picture You can adjust the color, hue and brightness of the picture. NAVI TV/VIDEO CHN/HKG SEEK V OFF A.MEM DSPL 2SEC POWER indicator Press (POWER). The POWER indicator lights up. Press (SEL). Each time you press (SEL), the items change as follows. COL (color) BRIGHT (brightness) BRIGHT...
  • Page 14 (Continued) Tips • To restore the factory settings, press (SEL) for more than two seconds, VISUAL STD (standard) appears. • If the picture is too dark or too bright from the viewing position, press (SEL) to select BRIGHT and press (+) or (-).

  • Page 15: Gb Adjusting The Screen Brightness (Auto Bright Control)

    Adjusting the Screen Brightness (Auto bright control) Depending on the surrounding light, you can adjust the screen brightness by controlling the brightness of the fluorescent pipe installed in the liquid crystal panel. Change the DIMMER selector located on the side of the monitor to LOW, HIGH, or AUTO.

  • Page 16: Using The Navigation System

    A.MEM DSPL 2SEC POWER indicator Press (POWER). The POWER indicator lights up. Press (NAVI) momentarily. NAVI appears for five seconds in the upper left corner of the screen. Note As of January 1999, the Sony navigation system is not available.

  • Page 17: Listening To The Tv/Video Sound While Using The Navigation System (Simultaneous Play Function)

    Listening to the TV/video Sound while Using the Navigation System (Simultaneous play function) You can listen to the TV or video sound even while the navigation system is on. NAVI TV/VIDEO CHN/HKG SEEK V OFF A.MEM DSPL 2SEC Press (POWER) and select a TV program, or select VIDEO 1 or VIDEO 2 and begin video playback.

  • Page 18: Additional Information

    Additional Information Installing the batteries Two size AA (R6) batteries (not supplied) Battery life is about six months depending on how much you use the wireless remote. Notes on batteries To avoid damage from battery leakage and subsequent corrosion: — insert the batteries matching the “+” and “–” on the batteries to the “+”...
  • Page 19 About the liquid crystal display (LCD) panel • Do not press on the LCD panel of the monitor unit as doing so can distort the picture or cause a malfunction. The picture may become unclear or it may damage the LCD panel. •...

  • Page 20: Location Of Controls

    Location of Controls Monitor SELECT button Brightness sensor SEARCH button NAVI (navigation) button TV/VIDEO button DIMMER (LOW/ POWER (on/off) switch HIGH/ AUTO) selector VOL (volume) Left button speaker* Right speaker* Wireless remote sensor POWER indicator * Monaural sound is heard from the left and right loudspeakers.
  • Page 21 Wireless remote NAVI (navigation) button TV/VIDEO button (Press for two seconds for CHN/HKG (China/Hong simultaneous play function.) Kong select) button (China only) NAVI TV/VIDEO CHN/HKG +/- button SEEK button SEL (select) button SEEK DSPL (display) button V OFF A.MEM DSPL A.MEM (auto memory) 2SEC VOL (volume) button...

  • Page 22: Specifications

    Specifications Monitor Input terminals System Liquid crystal color display Video input (2 system): RCA pin 1 Vp-p, Display Transparent TN LCD panel 75 ohm Drive system TFT active matrix system Audio input: RCA pin -10 dBs, 10 kohm Picture size 7 in.; 155.52 × 87.75 mm, Antenna input: mini plug 178.57 mm Navigation input: Square 16 -pin...

  • Page 23: Troubleshooting Guide

    Troubleshooting Guide Problem Cause/Solution No picture, no sound •The power cord or battery has been disconnected. •The fuse has blown. •Press (TV/VIDEO). Press the (+) side of the volume button on Good picture, but no sound the wireless remote, or the VOL button on the monitor.
  • Page 24 *I-3-866-745-11* Sony Corporation Printed in Japan...
