- Page 1 페이지 1 / 1 C-motech CGU628 User Manual mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12...
- Page 2 CHU-628S 사용자 프로그램 설치 페이지 1 / 5 User program Install Install Modem USB port connection. And Install is worked automatically. User program installs a Modem driver to User computer Install program support Windows 2000, Windows XP, Vista 32bit, Vista 64bit. Install start You can start connect a Modem to USB port, It starts automatic Installation.
- Page 3 CHU-628S 사용자 프로그램 설치 페이지 2 / 5 C-motech Modem Manager Install Wizard operation, Push ‘Next(N)’ button To change Install path, Please select a path for ‘Change(C)’button click. If you want a standard Install, Push ‘Next(N)’ button. mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12...
- Page 4 CHU-628S 사용자 프로그램 설치 페이지 3 / 5 Function Selected for Install and push 'Next(N)' button. ‘Install(I)’ button push mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12...
- Page 5 CHU-628S 사용자 프로그램 설치 페이지 4 / 5 It displays the Install process status. Push the Install ‘complete’button. mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12...
- Page 6 CHU-628S 사용자 프로그램 설치 페이지 5 / 5 Install completed, and Shortcut Icon is generated to Window After User program Install completed, The Modem driver is Installed automatically. Finally the driver Install completed. The display is showing below.. mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12...
-
Page 7: Modem Connection
CHU-628S 모뎀 연결방법 페이지 1 / 1 Modem connection Connection Method Insert to USB port of Modem Laptop or Desk top PC for connection. Modem direct connection is not suitable to you. Please use USB extension line. Check the LED power lamp is on in the Modem. You can see the Install information in the Hardware Manager of XP window. - Page 8 페이지 1 / 1 User program Use Double click for Icon( ) at Window. The program is operated well. And you can see the user program as Main Window. It shows Ready operation and service working status. Let’s see the Main Window control Main Window Modem status information Icon Icon...
- Page 9 페이지 1 / 1 User program Use Double click for Icon( ) at Window. The program is operated well. And you can see the user program as Main Window. It shows Ready operation and service working status. Let’s see the Main Window control Main Window Modem status information Icon Icon...
- Page 10 전화 접속 네트워크 페이지 1 / 1 Telephone connection network Network connection button Click for internet connection. button Click for network connection try. After the service verification, enroll the network for user. When internet connection is successful case, button is changed to button mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%...
- Page 11 페이지 1 / 1 Network connection close Network connection close If you want to finish the internet connection, Click button below widow and "data connection disconnected…" message are displayed. And internet connection is finished. After the quit for the service, the display back to the main status window. mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%...
-
Page 12: Introduction Of Menu
메뉴 소개 페이지 1 / 1 Introduction of Menu : You can open or close the Menu Window. (SMS): To read received SMS messages or send SMS messages. (Phone Book): To save mobile numbers and names. (Setting Infomation): General Setting, Roaming Setting, USIM Setting, User Infomation (Help): You can see a user manual. -
Page 13: Sms Function
SMS 기능 페이지 1 / 6 SMS Function SMS is the function to sending a short text to recipient. It supports writing, reading, USIM save, forwarding, Number save, reply, delete, delete all data functions. SMS menu In main Window (MENU button) -> (message) button click and SMS Function Use. - Page 14 SMS 기능 페이지 2 / 6 SMS is saved to PC and USIM, A Picture above (activated tap) You an check the current status. Message write To make a new text, (new text writing) button Click. (new text writing) button Click. And text Input window is displayed below for short length message.
- Page 15 SMS 기능 페이지 3 / 6 SMS Receiving Display for a new text receive for message Alarm window. Main Window Icon number indicates the number of new texts. mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12...
- Page 16 SMS 기능 페이지 4 / 6 Letter Icon is closed for a new text, letter Icon is opened for checked text. SMS new message Confirm Received new message can be selected and contents can be confirmed.. mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12...
- Page 17 SMS 기능 페이지 5 / 6 SMS Receive Message Click ’Receive Message’ button to check received message, message contents and receiving time, sending number detail information SMS Received message ’Received message’button click and, Sending messages are shown to list display. And each message can be selected and can check detailed information for a sending time, receive number.
- Page 18 SMS 기능 페이지 6 / 6 SMS resending ’Receiving message’, Some designated messages can be selected and click button to resending the message with receiving number of Receiving message' SMS delete Select a list to delete and click button. Click button to delete total list.
- Page 19 주소록 사용하기 페이지 1 / 2 Phone Book Use Phone Book Use (Telephone number) button for Phone Book Dialogue. ’Phone Book Total Information’ button Click for total Phone Book ‘group add/delete’ button Click new group add or delete. standard group are undetermined, family, friend, company. And standard group cannot be deleted. (PC save) or (USIM save) Save PC Phone Book data to USIM or, Phone Book data of USIM can be saved to PC...
- Page 20 주소록 사용하기 페이지 2 / 2 To add Phone Book button click, and input name, Telephone number information button click, Cellular phone number standard number is saved for basic setting. Edit To change Phone Book, Please select Phone Book Edit button Click, And the edit window is showing.
- Page 21 옵션 설정하기 페이지 1 / 1 Setting Infomation Setting Infomation (Setting) Genaral Setting, Roaming Setting, USIM Setting, User Infomation mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12...
-
Page 22: General Setting
옵션 설정하기 페이지 1 / 1 General Setting 1.Effect sound Setting Effect sound setting for window open or close effect sound (sound on/off) 2. Always Pop Up status Windows pop up in the first widow display. 3. Window hidden after the data connection Program is automatically hidden to tray after the internet connection 4. -
Page 23: Roaming Setting
페이지 1 / 1 Roaming Setting If you select wrong service area, It is impossible to have a service to you. Please check the service area change. International automatic Roaming Setting WCDMA automatic/Manual Service Selection. button supports automatic current connection. Try a connection after a overage search. - Page 24 USIM 설정 페이지 1 / 2 USIM Setting PIN Use (Lock Setting by USIM CARD PIN number) button click and, below window. Here, PIN number Input to input window. Click “USIM PIN Use button” and (Product initial value for 0000 Setting). Lock Setting condition for HSDPA Modem Use, You must input the PIN number to use Modem.
- Page 25 USIM 설정 페이지 2 / 2 If the setting of the USIM PIN function is “Use” status, It is possible to change PIN number. To change the PIN number, The function button activated, And click to display for the window pop up..
-
Page 26: Use Information
USIM 설정 페이지 1 / 1 Use information Data Use quantity from the initialization to previous connection. Total Use quantity is sending/Receiving accumulated quantity displayed. For effective management, you may initialize the data 1day before in every month Virus Infected User’s PC can make a wrong data display. Please check periodic virus inspection & correction is recommended. -
Page 27: Network Setting
제목 없음 페이지 1 / 1 Network Setting mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12... -
Page 28: Profile Setting
제목 없음 페이지 1 / 1 Profile Setting mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12... -
Page 29: Sms Setting
제목 없음 페이지 1 / 1 SMS Setting mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12... -
Page 30: Help Information
도움말 보기 페이지 1 / 1 Help Information Help Information (Help) User Manual mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12... -
Page 31: Version Information
버전 보기 페이지 1 / 1 Version information Version information Click (Version information) button for firmware and PC manager Version information & number. Version information shall be changed. mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12... - Page 32 버전 보기 페이지 1 / 1 Memory save Function Memory save Function is used by a Modem Memory, maximum save quantity is 45MB. Memory save Function is not working in the data connection mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12...
- Page 33 User program remove Remove To remove the software, Please click the computer Control Panel and program add/remove. Please find C-motech Modem Manager and Click “remove”. change, recover, remove windows are popup for you. And you may click the remove and “next”. mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%...
- Page 34 설치 제거 하기 페이지 2 / 3 Message box is popup for you and If you can click ” Yes(Y)” button to remove operation. If you don’t want to remove, Please push “No(N)” button. Remove operation is proceeding, Completed sit, complete window is displayed. mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%...
- Page 35 설치 제거 하기 페이지 3 / 3 mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12...
- Page 36 부록 페이지 1 / 1 Appendix Specification and Features Size 87.8(length) x 31.9(width) x 9(Height)mm Weight Output Power 0.2W Operating -20℃ ~ +50℃ Temperature Relative Humidity 5% ~95% mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12...
- Page 37 FCC Regulations: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
-
Page 38: Customer Service Center
페이지 1 / 1 Customer Service Center ◆ Cmotech Customer Center Questions for Modem Use Method & Repair Contact : 02) 368- 9834 ~ 5 Address : Yongsan Building 8 floor, 14-14 Yoido-Dong, Yeongdeungpo-Gu, Seoul Web Page : www.cmotech.com mk:@MSITStore:H:\001.%20프로젝트%20자료\004.%20CGU-628\010.%20시험%... 2008-03-12...
