Synrad UC-2000 Quick Start Manual

Hide thumbs Also See for UC-2000:

Unpacking:

Your UC-2000 laser arrives in its own box. The wiring is on-top of the foam to prevent damage to the

controller underneath the foam top.

1.1 UC-2000 wire harness.

Upon arrival, inspect all shipping containers for signs of damage. If you discover shipping damage,

document the damage (photographically if possible), then immediately notify the shipping

carrier (responsible party for any transportation damage) and SYNRAD®. See the inventory section

with in the Introduction chapter of the Operation Manual for packaging list(s).

Important

Keep All Foam and Packaging, you will need to re-use it when moving your unit to

Note:

prevent damage that could void your warranty. Refer to this guide and the Technical

Reference chapters in the laser's Operation Manual when re-packaging for shipping

and/or relocation. Remove all accessory items not originally attached (if applicable)

prior to re-packaging for shipping.

UC-2000™ Quick Start Guide

Danger,

Warning,

a Novanta company

Caution terms, symbols, and instructions located

http://www.synrad.com/synrad/docroot/products/

1.2 UC-2000 & power connection.

QSG UC-2000 Ver 2.0

Table of Contents

Do you have a question about the UC-2000 and is the answer not in the manual?

Page 1 Unpacking: Your UC-2000 laser arrives in its own box. The wiring is on-top of the foam to prevent damage to the controller underneath the foam top. 1.1 UC-2000 wire harness. 1.2 UC-2000 & power connection.
Page 2 Novanta company Power & Control Connections: Connect the mini-Din to the power cord as shown below. The BNC from the UC-2000 controller to the laser’s port(s) shown in the figure below located on the rear of the laser. A B C D...
Page 3 Before proceeding, make note of the UC-2000 laser controller’s factory settings. You will need to restore the unit to factory settings after the laser’s power has been verified. Set the UC-2000 to MAN- UAL mode, utilizing the ‘SELECT’ button to scroll through the menu selections, and set the PWM Adj Knob to provide zero percent output (0.0%).
Page 4 UC-2000’s Lase ‘On/Off’ button to toggle on or off lasing. The LASE indicator on the UC-2000 turns off and the laser’s LASE LED may go dim, flicker, or go out entirely. Refer to the UC- 2000 operators manual for more detailed information. Restore the UC-2000 factory settings.
Page 5 Note: to your unit could occur! Return your UC-2000 controller to factory and/or appropriate settings. Turn off the DC power supply, shut off the chiller or otherwise stop coolant flow through the laser when not actively in use to minimize the risk of condensation damage that will void your warranty.
