Service Manual
Refrigerator
Model: AR-815NF
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http://svc.dwe.co.kr
S/M No. : FRP4210000
BK-8152NF
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo AR-815NF
Summary of Contents for Daewoo AR-815NF
- Page 1 S/M No. : FRP4210000 Service Manual Refrigerator Model: AR-815NF BK-8152NF Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
-
Page 2: Table Of Contents
CONTENTS 1. Specification 2. External View 3. Name Of Parts 4. Wiring Diagram 5. Air Flow Diagram 6. Refrigerant Cycle Diagram 7. Wiring Diagram 8. Exploded View 9. Part List... -
Page 3: Specification
1. SPECIFICATION Input Power, Voltage Frequency AC 220V / 50Hz Refrigeration Cycle Compressor Type SL28YE-4E Refrigerant (Charge Volume) R-12 (180g) Cooling System Fan-Cooling System Refrigeration System Air Forced Convection Defrost System Fin-Evaporator-Forced Cold Control Refrigerator Adjustable Freezer 111 L Refrigerator 299 L Usable Capacity Total... -
Page 4: Name Of Parts
3. NAME OF PARTS Freezer Shelf Case Icing Case Ice Case Child Shelf Refrigerator Refrigerator Temperature Control Crisper Cover Crisper Adjustable Foot 10 Front Grille 11 Freezer Door Pocket 12 Egg Pocket 13 Case Egg 14 Refrigerator Pocket (SM) 15 Refrigerator Pocket (Medium) 16 Refrigerator Pocket (BG) 17 Deodorant 4. -
Page 5: Air Flow Diagram
5. AIR FLOW DIAGRAM Freezer door pocket Do not put ice cream or frozen Freezer room food in freezer door pocket to Do not put any bottle such as store for a long term. Opening beer or beverage because it can and shutting the door can rise up -16~-18 -16~-18... -
Page 6: Refrigerant Cycle Diagram
6. REFRIGERANT CYCLE DIAGRAM ACCUM SUC-PIPE... -
Page 7: Wiring Diagram
7. WII R ING DIAGRAM - ACTUAL L AYOUT... -
Page 8: Exploded View
8. EXPLODED VEIW... -
Page 9: Part List
9. PART LIST Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART CODE PART NAME QUANTITY... - Page 10 PART CODE PART NAME QUANTITY REMARK 3012001102 D-SENSOR FIXR 4010G03106 EVA AS 400EL21212 FUSE TEMP AS 4017Z90590 THRM FUSE FIXR 4017Z73570 COVER HTR E R S *T D F O T 400EL22311 110V, 127V HTR GLASS TUBE AS 400EL22211 220V, 240V 4017Z73580 COVER HTR E R S *T D F O T...
- Page 11 PART CODE PART NAME QUANTITY REMARK 4010G55114 SHELF R 3017801110 ONLY TURKEY 3011403130 CRISPER COVER 3011403120 ONLY TURKEY 4010G30520 (OPTION) GASKET CRISPER FRONT 3012300310 ONLY TURKEY (OPTION) 4010G30530 (OPTION) GASKET CRISPER BACK 3012300410 ONLY TURKEY (OPTION) 4018G30043 (OPTION) PANEL AQUATIC 3013502310 ONLY TURKEY (OPTION) 4010G30551...
- Page 12 PART CODE PART NAME QUANTITY REMARK 4010G30640 BOTTLE POCKET 3019001610 ONLY TURKEY 4010G30654 (OPTION) DIVISION PLATE BOTTLE POCKET 3015300210 ONLY TURKEY (OPTION) 4010E59900 DEODORANT (OPTION)
