Page 2
User manual whirlpool D-series with Bluetooth Foreword: This manual is general for all whirlpools in the BT-series. The user manual describes safety procedures, operating instructions and general maintenance. Please take your time to read through this manual before installing and using the product and make the instructions available. Important note to installer/ customer: Please check the description on the packaging matches the item you have ordered and check the packaging visually on damages upon delivery.
Page 3
User manual whirlpool D-series with Bluetooth Before installation: You must ensure that water inlet, electricity and drain pipe are ready and suitable for installation of the product. We refer to the technical specifications in this manual. Use a splash proof socket to connect the product with the power supply. The drain hose has a diameter of 40mm.
Page 4
User manual whirlpool D-series with Bluetooth After installation: Before starting up the product for the 1 time you have to go over all connections to control that they are well connected. Recommended control points are water fittings and pipes on the faucet to the various functions. Before starting up the product for the 1 time you have to check if all electrical wires are connected correctly.
Page 5
User manual whirlpool D-series with Bluetooth Turn on/off the display: The system is "standby" when the whirlpool connected to the power network. If the system is on "standby" state, the on/off symbol is visible on the dark screen. If touch any of the buttons on the screen will activate the backlight with 50% strength.
Page 6
User manual whirlpool D-series with Bluetooth Heater: When water level is above the water level sensor, the heater can be activated. Press the constant temperature button to activate the heater. Once the water temperature is below the set temperature, the pump and heater will activate. If the set temperature reaches, the heater will stop automatically.
Page 7
User manual whirlpool D-series with Bluetooth Once a device is connected to the system it will auto-detect when Bluetooth function activated on the control panel. If there is more than one device paired to the system, the system will choose one of them automatically. If the system connects to wrong device, deactivate the Bluetooth function by pressing the Music button then press and hold the Music button for 3 seconds and the Bluetooth symbol will start flash and the system is in search mode.
Page 8
User manual whirlpool D-series with Bluetooth How to operate the faucet: A: Change over valve: B: Temperature adjustment: Water jets H for hot water Hand shower L for cold water Waterfall Air regulator: Maintenance: When to clean the whirlpool use a soft sponge and a detergent without ammonia and acetone to prevent the surfaces in the whirlpool gets math.
Page 9
User manual whirlpool D-series with Bluetooth Technical Parameters: Operation Conditions and Characteristics Rated voltage AC220V-240 Rated frequency 60HZ Rated current 11.8A Rated power 2600W >20M Insulating resistance Waterproof level IPX5 Load Parameters Type of Load Rated Load Voltage Rated Load Frequency Rated Load Power Water pump AC220V-240...
