Antenna Booster
V1
Ordercode: D1425
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Antenna Booster and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DAPAudio Antenna Booster

  • Page 1 MANUAL ENGLISH Antenna Booster Ordercode: D1425 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
  • Page 2: Table Of Contents

    Antenna Booster Table of contents Warning ....................................2 Unpacking Instructions ..............................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Return Procedure ................................4 Claims ....................................4 Description of the device ..............................5 Features ..................................5 Overview ..................................5 Installation ................................... 6 Set Up and Operation ...............................
  • Page 3: Warning

    Save the carton and all packing materials. In the event that a device must be returned to the factory, it is important that the device is returned in the original factory box and packing. Your shipment includes: • DAP Antenna booster • Antenna •...
  • Page 4: Operating Determinations

    Antenna Booster IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorized modification to the system.  Never let the power cord come into contact with other cables! Handle the power cord and all connections with the mains with particular caution! ...
  • Page 5: Return Procedure

    Antenna Booster Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
  • Page 6: Description Of The Device

    Indicates that the unit is active. 04) Input Make sure you connect the Antenna booster to a device which is capable of supplying phantom Power (12 -18Vdc) via the BNC antenna connector. E.g. DAP audio D1444 Antenna Distributor. 05) Mounting socket/screw The mounting socket has a 5/8”...
  • Page 7: Installation

    Phantom power (12 – 18Vdc) via a BNC plug. E.g. DAP audio D1444 Antenna Distributor. Maintenance The DAP Audio Antenna Booster requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid.
  • Page 8: Product Specifications

    Antenna Booster Product Specifications Model: DAP Audio Antenna Booster Frequency Range: 470-870MHz Antenna gain: 1,8dBi Booster gain: 10(+2, -1)dB Coverage angle: 360 degrees Operation Voltage: 12 – 18Vdc Dimensions (Booster only): 80 x 18 x 52 mm (LxWxH) Weight: 0,36 kg Design and product specifications are subject to change without prior notice.
  • Page 9: Notes

    Antenna Booster Notes Ordercode: D1425...
  • Page 10 Antenna Booster Ordercode: D1425...
  • Page 11 Antenna Booster Ordercode: D1425...
  • Page 12 ©2015 DAP Audio...
