- Page 1 Network IR PTZ Camera User’s Manual Outdoor Ver. 1.3 001C83XZZ1A3...
-
Page 2: Table Of Contents
Table of Contents Overview ..........................2 Features ........................2 Package Contents ....................... 3 Dimensions ........................4 Connectors ........................5 Camera Cabling ........................6 Power Connection ....................... 7 Ethernet Cable Connection ..................7 Audio / AIarm I/O & RS-485 Connection ..............8 System Requirements ...................... -
Page 3: Overview
Overview With the latest encoding technology and built-in IR LEDs, Network IR PTZ Camera presents strong HDR and high sensitivity performance, and is capable of capturing high resolution images during daylight hours and even, in pitch-black darkness. At night, or in any low/zero lighting environments, Network IR PTZ Camera is able to provide effective illumination to the objects 200 meters away, and also delivers crystal clear images with high quality 30x optical zoom lens in long distance. -
Page 4: Package Contents
Package Contents Please check the box contains the items listed here. If any item is missing or has defects, DO NOT install or operate the product and contact the dealer for assistance. Outdoor Network IR PTZ Camera M4 Security Screw with Rubber Quick Guide 3-Pin Power 14-Pin Alarm/Audio I/O... -
Page 5: Dimensions
Dimensions... -
Page 6: Connectors
Connectors Refer to the diagrams below for the positions of the reset button and various connectors of the camera. Definition of the reset button and the connectors are given as follow. Connector Definition Audio/Alarm I/O & RS-485 Audio/Alarm I/O & RS-485 connection Connector * Power Connector (DC12V) DC12V power connection... -
Page 7: Camera Cabling
Camera Cabling The outdoor models are being IP66-rated to prevent water from entering the camera. However, water might still enter the camera if it is being improperly installed. Please make sure the warnings below are strictly followed when installing the camera. Place all cables and the adaptor in dry and well-waterproofed ... -
Page 8: Power Connection
Power Connection To power up the camera, connect the DC12V or AC24V / DC28-48V power adaptor to the power connector of the camera and the power outlet. Refer to the diagram and pin definition below for AC24V / DC28-48V power connection. Definition AC24V N DC28-48V +... -
Page 9: Audio / Aiarm I/O & Rs-485 Connection
Audio / AIarm I/O & RS-485 Connection Please refer to the diagram and pin definition tables below for audio/alarm I/O & RS-485 connection. Definition Definition Definition Definition Audio In Alarm In 1 Alarm In 3 RS-485 D- Audio Out Alarm Out A1 Alarm Out B1 14 RS-485 D+ GND (Alarm... -
Page 10: System Requirements
System Requirements To perform the camera via web browser, please ensure the PC is in good network connection, and meet the system requirement as described below. Items System Requirement Minimum : ® 1. Intel CoreTM i5-2430M @ 2.4 GHz 2. 2 GB RAM or more Personal Computer Recommended : ®... -
Page 11: Access Camera
Access Camera For initial access to the camera, users can search the camera through the installer program: DeviceSearch.exe, which can be found in “Device Search” folder in the supplied CD. Accessing the Camera by Device Search Software Step 1: Double click on the program Device Search.exe. Step 2: After its window appears, click on the <Device Search>... - Page 12 Step 8: A prompt window requesting for default username and password will appear. Enter the default username and password shown below to login to the camera. Login ID Password Admin 1234 NOTE: ID and password are case sensitive. NOTE: It is strongly advised that administrator’s password be altered for the security concerns.
- Page 13 Once the Viewer is successfully installed, the Home page of the camera will be shown as the figure below. Zoom and Focus Adjustment The live image will be displayed on the Home page when the camera is successfully accessed. If zoom or focus is not at the desired position, please use the function buttons on the Home page for adjustment.
-
Page 14: Setup Video Resolution
Setup Video Resolution Users can setup video resolution on Video Format page of the user-friendly browser-based configuration interface. Video Format can be found under this path: Streaming> Video Format. The default value of the video resolution is as below. H.264- 1920 x 1080 (60/50 fps) + Normal Mode H.264- 720 x 480 (60 fps) / 720 x 576 (50 fps) H.264- 1920 x 1080 (30/25 fps) +... -
Page 15: Configuration Files Export / Import
Configuration Files Export / Import To export / import configuration files, users can access the Maintenance page on the user-friendly browser-based configuration interface. The Maintenance setting can be found under this path: System> Maintenance. Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the camera. -
Page 16: Tech Support Information
Tech Support Information This chapter will introduce how to delete previously-installed DCViewer in the PC and how to setup the Internet security. Delete the Existing DCViewer For users who have installed the DCViewer in the PC previously, please remove the existing DCViewer from the PC before accessing to the IP camera. Deleting the DCViewer In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or Remove Programs>. -
Page 17: Setup Internet Security
Setup Internet Security If ActiveX control installation is blocked, please either set Internet security level to default or change ActiveX controls and plug-ins settings. Internet Security Level: Default Step 1: Start the Internet Explorer (IE). Step 2: Click on the <Tools> tab on the menu bar and select <Internet Options>.
