Important:
Please read these instructions carefully prior to installation.
Please refer to your fitting instruction to ensure that the roof racks are installed in the correct locations.
Check the contents of kit before commencing fitment and report any discrepancies.
Place these instructions in the vehicle's glove box after installation is complete.
Layout
Note: The poles and ropes must always be
used when the FOXWING Eco awning is open
Recommendations
It is essential that all bolt connections be checked after driving a short distance when you first install your Rhino
FOXWING Eco Awning. Bolt connections should be checked again at regular intervals (probably once a week
is enough, depending on road conditions, usage, loads and distances travelled). You should also check the
roof bars each time they are refitted.
Use only non-stretch fastening ropes or straps.
Please remove FOXWING Eco Awning and crossbars when putting vehicle through an automatic car wash.
Load Ratings
With the addition of the FOXWING ECO Awning, the load capacity of your crossbars will have to be adjusted
accordingly. The FOXWING ECO Awning and 2 crossbars weigh approximately 14kg. When roof racks are to be
used in off-road conditions, please build a safety factor of 1.5 into this load limit. Although the roof racks are tested
and approved to AS1235-2000, Australian road conditions can be much more rigorous.
Note for Dealers and Fitters
It is your responsibility to ensure that this fitting instruction is given to the end user or client.
Rhino-Rack
3 Pike Street, Rydalmere,
NSW 2116, Australia.
(Ph) (02) 9638 4744
(Fax) (02) 9638 4822
These instructions remain the property of Rhino-Rack Australia Pty Ltd and may not be used or changed for any other purpose than intended.
Rhino-Rack FOXWING ECO Awning 31117
Important Information
Document No: R367
Prepared By: Kayle Everett
Authorised By: Chris Murty
Note: The foxwing Eco shade
span opens up to 270 degrees (±5
degrees due to material variation)
Issue No: 01
Issue Date: 11/03/2014
Page 1 of 15

Advertisement

loading
Need help?

Need help?

Do you have a question about the FOXWING ECO and is the answer not in the manual?

Questions and answers

Summary of Contents for Rhino-Rack FOXWING ECO

  • Page 1 Issue No: 01 (Fax) (02) 9638 4822 Authorised By: Chris Murty Issue Date: 11/03/2014 These instructions remain the property of Rhino-Rack Australia Pty Ltd and may not be used or changed for any other purpose than intended. Page 1 of 15...
  • Page 2: General Parts List

    Rhino-Rack FOXWING ECO Awning (31117) General Parts List Crossbar Bracket Item Component Name Part No. FOXWING Eco Awning (pg 2) Crossbar Bracket C774 Crossbar Bracket Plate C785 M8 x 23mm T-Bolt C779 M8 X 17mm Flat Washer W020 M8 Nyloc Nut...
  • Page 3 Rhino-Rack FOXWING ECO Awning (31117) Foxwing Parts List Item Component Name Part No. End Cap C778 Rubber Strap C783 Rivet (1661 - 0613) H004 Pole Holder C782 H008 Rivet (1661 - 0619) Backing Extrusion M8 x 150mm Bolt C775 M8 Flat Washer...
  • Page 4 Rhino-Rack FOXWING ECO Awning (31117) Minimum Crossbar Distance Distance measured from bar centre to bar centre 700mm Distance measured from bar centre to bar centre Fitting Instruction When locating and inserting each T-bolt (A), ensure that you do not drop it into the recess.
  • Page 5 Rhino-Rack FOXWING ECO Awning (31117) For Sportz / Aero Crossbar For Heavy Duty Crossbar Do not fully tighten Do not fully tighten at this point at this point Cut buffer strip to size Cut buffer strip to size Page 5 of 15...
  • Page 6 Rhino-Rack FOXWING ECO Awning (31117) Adjust the location of the crossbar bracket assembly Adjust the location of the crossbar bracket assembly to suit the crossbar distance on your vehicle to suit the crossbar distance on your vehicle Side View Side View...
  • Page 7 Rhino-Rack FOXWING ECO Awning (31117) Operation Instruction Note: Be careful in windy conditions, assistance from a second person is recommended. Refer to supplement. Front of Car Open awning bag, see steps 3 - 5 for instructions on how to undo the velcro flaps.
  • Page 8 Rhino-Rack FOXWING ECO Awning (31117) Unzip the awning cover all the way to the front (as shown) Peel the cover to the rear as shown. Make sure when opening the awning that the bag is clear of the hinge area...
  • Page 9 Rhino-Rack FOXWING ECO Awning (31117) Secure the top pole onto the nearest crossbar. Pull the strap tightly (as shown) to maintain tension and shape of the awning. Page 9 of 15...
  • Page 10 Rhino-Rack FOXWING ECO Awning (31117) Insert the telescopic Secure each pole pole at each awning to the awning with pole tip as shown the velcro straps Page 10 of 15...
  • Page 11 Rhino-Rack FOXWING ECO Awning (31117) Secure the awning with the extra Shorten the RAIN pegs and guy ropes as shown. telescopic pole slightly Storing Instruction Undo the tensioning straps, the telescopic poles, guy ropes and pegs. Store these items in the supplied travel bags.
  • Page 12 Rhino-Rack FOXWING ECO Awning (31117) Secure the poles with the rubber strap before rolling awning material up (see inset picture). Fold the awning as shown on right. Roll the awning all the way up till you see the corresponding clips (A).
  • Page 13: Replacing The Spar Hinge

    Rhino-Rack FOXWING ECO Awning (31117) Replacing the spar hinge Should the spar hinge be damaged from stronger than expected windy conditions, please follow these steps to replace the spar hinge (we have included 2 spares with this kit). Open the awning bag and expose the spar hinge assembly as shown.
  • Page 14 Rhino-Rack FOXWING ECO Awning (31117) Disassemble the skewer as shown. Determine which spar hinge that needs to be replaced. Pull out the corresponding hinge pin. Undo the self tapping screw to release the spar hinge Page 14 of 15...
  • Page 15 Rhino-Rack FOXWING ECO Awning (31117) Insert replacement spar hinge and self tapping screw as shown. Assemble the skewer sub assembly back and tighten. Page 15 of 15...
