14. TECHNICAL DATA..................22 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
The appliance must be connected to the water mains • using the new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre. Old hose sets must not be reused. • If the mains power supply cable is damaged, it must •...
ENGLISH access to the mains plug after the • Follow the safety instructions on the installation. detergent packaging. • Do not touch the mains cable or the • Do not put flammable products or mains plug with wet hands. items that are wet with flammable •...
3. PRODUCT DESCRIPTION 3.1 Appliance overview Worktop Detergent dispenser Control panel Door handle Rating plate Drain pump filter Feet for levelling the appliance 3.2 Fixing plate kit Read carefully the instructions supplied with the accessory. (4055171146) Available from your authorised dealer.
ENGLISH Options selection touchpad Extra rinse indicator Door locked indicator Start/Pause touchpad Indicators: Delay Start touchpad Child lock indicator 5. PROGRAMME CHART Programme Maximum Programme description Temperature load (Type of load and soil level) range Maximum spin speed 7 kg White cotton and coloured cotton.
ENGLISH During the washing phase the programme duration is automatically cal‐ culated and can be greatly reduced if the laundry load is lower than the maximum load capacity (e.g. Cotton 60°C, maximum load capacity 7 kg, the programme duration exceeds 2 hours; actual load 1 kg, the pro‐ gramme duration will be less than 1 hour).
The related indicator comes on. Rinse Hold • Set this option to prevent the laundry 7.6 Rinse Only creases. • The related indicator comes on. With this option you can perform only a • There is a water in the drum when the last rinse of a selected washing programme is completed.
ENGLISH • To activate/deactivate this option, • The programme is completed. • The appliance has a malfunction. touch the buttons at the To deactivate/activate the acoustic same time until the indicator signals, touch the buttons comes on/goes off. the same time for 4 seconds. Activate this option after you touch the If you deactivate the button...
Page 12
10.2 Using detergent and additives Compartment for liquid addi‐ tives (fabric conditioner, 1. Measure out the detergent and the starch). fabric conditioner. CAUTION! 2. Put the detergent and the fabric Do not exceed conditioner into the compartments. the MAX level.
ENGLISH • Position A for powder detergent (factory setting). • Position B for liquid detergent. When you use the liquid detergent: • Do not use gelatinous or thick liquid detergents. • Do not put more liquid then the maximum level. •...
To cancel the delay start: 2. Wait until the indicator goes off. 1. Touch the button to set the 3. You can open the door. appliance to pause. 4. Close the door and touch the button 2. Touch the button until the again.
ENGLISH 2. When the programme is completed to decrease the energy consumption. All the indicators go off when : and the door lock indicator goes off, you can open the door. • You do not use the appliance for 5 3.
11.5 Water hardness • If your appliance does not have the detergent dispenser with the flap If the water hardness in your area is high device, add the liquid detergents with or moderate, we recommend that you a dosing ball (supplied by the use a water softener for washing detergent's manufacturer).
ENGLISH 12.5 Cleaning the detergent dispenser 12.6 Cleaning the drain filter Do not clean the drain filter if the water in the appliance is hot. Regularly check the drain pump filter and make sure that it is clean. Repeat the steps 2 and 3 until the water stops flowing out.
Page 18
Always keep a rag nearby to Make sure that the impeller dry up any water spillage. of the pump can rotate. If it does not rotate, contact the Authorised Service Centre. Make sure also that you tighten the filter correctly to...
ENGLISH 12.7 Cleaning the inlet hose and the valve filter 45° 20° 12.8 Emergency drain 0° C, remove the remaining water from the inlet hose and the drain pump. Because of a malfunction, the appliance 1. Disconnect the mains plug from the cannot drain the water.
13. TROUBLESHOOTING WARNING! Refer to Safety chapters. 13.1 Introduction The start of the appliance does not occur or it stops during operation. First try to find a solution to the problem (refer to the table). If not, contact the Authorised Service Centre.
Page 21
ENGLISH Problem Possible solution The appliance does not • Make sure that the water tap is open. fill with water properly. • Make sure that the pressure of the water supply is not too low. For this information, contact your local water authority.
Problem Possible solution The appliance makes • Make sure the levelling of the appliance is correct. Refer an unusual noise. to 'Installation instruction'. • Make sure that the packaging and/or the transit bolts are removed. Refer to 'Installation instruction'.
ENGLISH Spin Speed Maximum 1200 rpm 1) Connect the water inlet hose to a water tap with a 3/4'' thread. 15. ENVIRONMENTAL CONCERNS appliances marked with the symbol Recycle materials with the symbol with the household waste. Return the Put the packaging in relevant containers product to your local recycling facility or to recycle it.
