7 FT KIDS TRAMPOLINE SET + TIC-TAC-TOE
MODEL# 9011TS
PRODUCT MANUAL - VERSION 02.17.03
• The contents of this package are not suitable
for children under 3 years of age. Contains
small parts which may cause choking.
• Adult supervision is required while in use.
• ADULT ASSEMBLY REQUIRED.
CUSTOMER SERVICE
GQBrands.com
CustomerService@GQBrands.com
1-866-498-5269
4009 Distribution Dr, Suite 240
Garland, TX 75041
Advertisement
Table of Contents
Related Manuals for PURE 9011TS
Summary of Contents for PURE 9011TS
- Page 1 7 FT KIDS TRAMPOLINE SET + TIC-TAC-TOE MODEL# 9011TS PRODUCT MANUAL - VERSION 02.17.03 FOR AGES: WEIGHT LIMIT: 54 Kgs ADULT(S) NEEDED: TOOLS NEEDED: WARNING/ADVERTENCIA CUSTOMER SERVICE GQBrands.com • Do not allow more than one person on this • The contents of this package are not suitable product at any time.
-
Page 2: Customer Service Information
CUSTOMER SERVICE INFORMATION Thank you for purchasing: 7FT KIDS TRAMPOLINE SET + TIC-TAC-TOE MODEL# 9011TS At Global Quality Brands®, we want all of our customers to be To order these parts, or if you have any other questions or concerns completely satisfied with their purchase. -
Page 3: Limited Warranty
TO USE. ALL MERCHANDISE IS SOLD ON THIS CONDITION, WHICH NO products are not covered by the product warranty. No other warranty REPRESENTATIVE OF GQ BRANDS® CAN WAIVE OR CHANGE. beyond that specifically set forth above is authorized by GQBrands®. MODEL# 9011TS... -
Page 4: Important Message
WARNINGS IMPORTANT MESSAGE WARNING - PLEASE READ ADULT ASSEMBLY REQUIRED CHOKING HAZARD - Small Parts NOT for children under 3 years of age. WARNING: While every attempt is made to ensure the highest degree of protection in all equipment, we cannot guarantee freedom from injury. The user assumes all risks of injury due to use. - Page 5 These may cause a strangulation is NOT intended for use in commercial or physical hazard. applications and/or use in public areas such as schools, parks, nurseries, day • This Trampoline is NOT for adult or schools, day cares, etc. adolescent use. MODEL# 9011TS...
-
Page 6: Parts List
PARTS LIST Jump Mat and Frame Pad Top Rail Corner Top Rail with Socket Vertical Leg Extension Plastic Horizontal Leg Base Plastic Vertical Leg Extension Galvanized Spring 8A - Straight Frame Tube Straight Frame Tube Foam 9A - Curve Frame Tube Curve Frame Tube Foam 10 - 10A -... - Page 7 PARTS LIST 11 - 12 - Enclosure Netting Plastic Flat Plate 13 - Chalk 14 - Wrench 16 - Spring Loading Tool 17 - 18 - Arc Washer Screw Allen Wrench Not Available in this Model# Version MODEL# 9011TS...
- Page 8 ASSEMBLY INSTRUCTIONS STEP 1: Parts: Part 4 (x6) - Vertical Leg Extension Part 12 (x6) - Plastic Flat Plate Connect the Plastic Flat Plate (Part 12) at the bottom of all Vertical Leg Extensions (Part 4). (12) STEP 2: Parts: Part 6 (x1) - Plastic Horizontal Leg Base Insert the 2x Vertical Leg Extensions at both openings of the Plastic Horizontal Leg...
- Page 9 Horizontal Leg Base. STEP 4: Parts: Part 3 (x2) - Corner Top Rail with Socket Slide 2x Corner Top Rail with Socket (Part 3) and align to the upper opening of the Vertical Leg Extensions. MODEL# 9011TS...
- Page 10 ASSEMBLY INSTRUCTIONS STEP 5: Parts: Part 8 (x2) - Straight Frame Tube Slide 2x Straight Frame Tubes (Part 8) onto the openings of the Corner Top Rail with Socket. NOTE: Make sure all 3 bolt openings align for Parts 3, 4, & 8. STEP 6: Parts: Part 2 (x1) - Top Rail...
- Page 11 Secure all openings from the Vertical Leg Extension, Corner Top Rails, and Straight Frame Tube with a 1x Screw (Part 18), 1x Arc Washer (Part 17), and 1x Nut (Part 20) Repeat until all Screws are tightened. (18) MODEL# 9011TS...
- Page 12 ASSEMBLY INSTRUCTIONS STEP 10: Parts: Part 1 (x1) - Jump Mat and Frame Pad Place the Jump Mat and Frame Pad (Part 1) with the Logo facing upwards. Each corner of the Jump Mat and Frame Pad will have an opening. Slide the Straight Frame Tubes through these openings.
- Page 13 Top Rail, install the remaining 20 Springs. NOTE: Failure to install the springs to the correct V-Ring and Top Rail openings and/ or not follow the Spring Order Installation as shown, may result in tearing or injury while in use. MODEL# 9011TS...
- Page 14 ASSEMBLY INSTRUCTIONS STEP 13: Parts: Part 8A (x6) - Straight Frame Tube Foam (8A) (8A) (8A) Locate the tube 3 Foams, 8A, 9A, & 10A. (8A) The shortest foam is the Straight Frame (8A) Foam (Part 8A). (8A) Slide all 6x Straight Frame Foams to the Straight Tubes.
- Page 15 ASSEMBLY INSTRUCTIONS STEP 15: (9A) Parts: Part 9A (x6) - Curve Frame Tube Foam (9A) Slide all 6x Curve Frame Tube Foams (Part (9A) (9A) 9A) to the Curve Frame Tubes. (9A) (9A) MODEL# 9011TS...
- Page 16 ASSEMBLY INSTRUCTIONS STEP 16: Parts: (11) Part 11 (x1) - Enclosure Netting Place the Enclosure Netting (Part 11) outside the Curved Frame Tubes. NOTE: Make sure the Hook & Clasps, and chalk pocket are on the outside. The location will be an indicator if the netting is placed on the correct side.
- Page 17 Parts: Part 10 (x3) - Horizontal Tube Part 10A (x3) - Horizontal Tube Foam Slide the Horizontal Tube Foam (Part 10A) into the Horizontal Tube (Part 10). (10) Make sure all Horizontal Tubes are protected with foam. (10A) MODEL# 9011TS...
- Page 18 ASSEMBLY INSTRUCTIONS STEP 20: Slide into upper enclosure sleeves Slide the Horizontal Tube with the foam attached into it, through the Enclosure Netting sleeves from one opening until it reaches the second opening. Twist the Curve Frame Tube until the Snap &...
- Page 19 ASSEMBLY INSTRUCTIONS STEP 21: Close the Enclosure Netting door by using the zippers. For extra security, close the clasps from the outside. STEP 22: Place the chalks into the chalk pocket located near the Enclosure Netting door. (13) MODEL# 9011TS...
-
Page 20: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS • Question: “The foam padding or mat is • Question: “I had a part missing from damaged, what should I do?” my box” or “something was damaged in shipping, can you send it to me?” Answer: If you are still within your warranty period (90 Days from initial Answer: If it has been 30 days or less purchase) you should contact customer...
