NVM-4070 Portable Navigation System
Instruction Manual
FOR SERVICE ASSISTANCE, CALL
Customer Information 1-800-421-5013
Weekdays 7:30 AM – 5:00 PM Pacific Time
NVM-4070

Advertisement

   Related Manuals for Sanyo NVM-4070

   Summary of Contents for Sanyo NVM-4070

  • Page 1

    NVM-4070 Portable Navigation System NVM-4070 Instruction Manual FOR SERVICE ASSISTANCE, CALL Customer Information 1-800-421-5013 Weekdays 7:30 AM – 5:00 PM Pacific Time...

  • Page 2

    - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. NVM-4070 Portable Navigation System Introduction...

  • Page 3

    • Avoid exposing your device to direct sunlight or strong ultraviolet light for SANYO and the SANYO logo are registered trademarks of SANYO. Other extended periods of time. products or system names appearing in this document are trademarks or regis- •...

  • Page 4

    SANYO and its subsidiaries assume no responsibility for any damage or loss resulting from the use of this SANYO NVM-4070 Portable Navigation System.

  • Page 5: Nvm-4070 Portable Navigation System

    California and Minnesota from using suction mounts on their windshields while operating motor vehicles. SANYO does not take any Do not use the adaptor if the cord becomes damaged. responsibility for any fines, penalties, or damages that may be incurred as a result of disregarding this notice.

  • Page 6

    (as “Licensee”, whether an individual translate, sell, lease or otherwise transfer, distribute the Software, in whole or a corporation, regardless) and SANYO Electric Co., Ltd. (“Licensor”) con- or in part, nor may Licensee use the Software with the intent to clone any cerning the Licensee's use of a single SANYO SOFTWARE PRODUCT (“the...

  • Page 7

    THE ENTIRE RISK ARISING OUT OF THE USE OR PERFORMANCE OF THE PRODUCT AND DOCUMENTATION REMAINS WITH LIC- ENSEE. IN NO EVENT SHALL LICENSOR OR ITS SUPPLIERS BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, DIRECT, INDI- RECT, SPECIAL, PUNITIVE OR OTHER DAMAGES WHATSOEVER NVM-4070 Portable Navigation System Introduction...

  • Page 8: Table Of Contents

    4.4 Data Transfer ................30 2.1.2 External Features ..............12 4.4.1 File Transfer ................30 2.2 Mounting the NVM-4070 in your vehicle ......14 4.4.2 Import Phonebook ..............31 2.3 Set up TMC antenna unit in your vehicle ......17 4.4.3 Export Contacts to SD ............31 Chapter 3 System ................

  • Page 9

    7.11 Getting a GPS fix takes longer time than normal....44 7.12 Factory reset does not mean a GPS reset......44 7.13 Bluetooth functions do not work......... 44 7.14 Unavailable functions ............44 Index ....................45 NVM-4070 Portable Navigation System Contents...

  • Page 10

    Index Chapter 1 NVM-4070 Features and Specifications SANYO NVM-4070 Feature Hardware Main unit The SANYO NVM-4070 Portable Navigation System is a powerful multifunc- 4" Touch screen, 480 x 272 pixel, TFT, 16.7M Display tion GPS navigation and entertainment device. colors...

  • Page 11

    DC Output 5.0V, 2A CE,UL,TUV-GS,CCC,BSMI,K mark, C-Tick, Certificates Singapore Safety USB Cable Length 4' (120 cm) SD Card Support Capacity Maximum 4GB (SDHC Support) MMC (Multi Media Card) Support Capacity Maximum 2GB NVM-4070 Portable Navigation System Chapter 1 Features and Specifications...

  • Page 12: Chapter 2 Getting Started

    Contents Index Chapter 2 Getting Started This chapter describes the hardware interface of the SANYO NVM-4070 and 2.1.2 External Features its peripherals. Instructions for setting up the device and some basic system Figure 1: Front Panel View operations are also discussed.

  • Page 13: Chapter 3 System

    Restarts your device with (a soft reset). DC Power For AC Adaptor or Car Adaptor input SD/MMC Accepts a SD (Secure Digital) or MMC (MultiMediaCard) slot for data storage. TMC antenna Standard TMC antenna jack. jack NVM-4070 Portable Navigation System Chapter 2 Getting Started...

  • Page 14

    The NVM-4070 comes with a car Mounting kit and a car adaptor to help install your device in your vehicle. The car Mounting kit uses a suction cup on the windshield/dashboard to offer flexible mounting options for the NVM-4070.

  • Page 15

    Fixes the car mount to the selected mounting 4 Suction cup area. Pull to release the vacuum seal of the suction 5 Suction cup release tab cup. Dashboard Mounting For Dashboard mounting usage Disc NVM-4070 Portable Navigation System Chapter 2 Getting Started...

  • Page 16

    Contents Index Using the car Mounting kit Plug the car adaptor into the side of the NVM-4070 and position the cord Clean and dry the mounting surface with a clean cotton cloth. to an appropriate location. If the ambient temperature is below +60°F (15°C), you can warm the mounting area and the suction cup (e.g.

  • Page 17

    Figure 7: Mounting on the dashboard Set up TMC antenna unit in your vehicle Figure 9: TMC antenna with take up reel New Photograph Detach the NVM-4070 from the Car mounting kit (ratching plate) Figure 8: Mounting on the dashboard No. Component Description...

  • Page 18

    WARNING: When you reel off the TMC antenna real, you must do it holding the plug, because reeling speed is very fast. SANYO is not responsible for the availability or quality of traffic NOTE: information provided by TMC. NVM-4070 Portable Navigation System...

  • Page 19: Date & Time

    Calibration is repeated until it succeeds. NOTE: When you first turn on your device, you will be asked to calibrate the NOTE: screen. This process ensures the accuracy of the touchscreen when used. NVM-4070 Portable Navigation System Chapter 3 System...

  • Page 20

    Tap the “Time” in the “Date & Time” Menu. When you tap “12H”, the time format changes to “24H” format. Tap the Return button to set the Time and return to the “Date & Time” Menu. NVM-4070 Portable Navigation System Chapter 3 System...

  • Page 21

    Index Next, tap “Time Zone” in the “Date & Time” Menu. No. Description If you check “Automatic daylight saving time”, NVM-4070 adjusts clock FM Transmitter Icon (This icon is displayed when FM-Transmitter is for daylight saving automatically. 2 Battery Status Bluetooth Status : Bluetooth is “ON”.

  • Page 22: Volume

    When tapping the bottom-left button in the Volume screen, the Check mark is added. NVM-4070’s Speaker output is set to OFF. Volume is changed to the max- imum value automatically and FM Transmitter output is turned ON. Tap the Frequency (XX.X MHz) button.

  • Page 23: Power

    When AC adaptor or Car adaptor is disconnected, you can view the Tap the center of the target as it moves around the screen. remaining battery power in the Battery Level bar. Tap the Return button to return to the System Menu. NVM-4070 Portable Navigation System Chapter 3 System...

  • Page 24

    Tap “GPS Reset” to open a dialog box to select whether to reset the GPS satellite receiver. Tap “YES” to reset the receiver and “NO” not to reset the receiver. Tap the Return button to return to the System Menu. NVM-4070 Portable Navigation System Chapter 3 System...

  • Page 25: Connection

    1 The name of the connected mobile phone Bluetooth Status : Bluetooth is “ON”. Tap the “Search” button. NVM-4070 starts to search available mobile Mobile phone is not connected. phones. The available phones are displayed on the phone list. Select one of the : Mobile phone is connected.

  • Page 26: Mobile Phone Connection (reconnect)

    “ON”. tions” screen. The name of the connected phone is displayed on the title (For more detailed information, see your phone’s manual.) bar. And the Bluetooth icon changes to green. NVM-4070 Portable Navigation System Chapter 4 Communications...

  • Page 27: Hands-free Calling

    Call-out from the contacts. In detail, refer to 4.3. Tap the “Call-out” button of the “Communications”, the Call-out screen opens. Input a phone number and tap NVM-4070 starts to make a call. , the phone call quits. NVM-4070 Portable Navigation System Chapter 4 Communications...

  • Page 28: Receiving A Call

    1 Save: Save the entry 2 Category Up / Down On the “Settings”, you can do the setting of the automatic answer to phone 3 Item Up / Down call. 4 Keyboard (Alphabet, Numbers, and Symbols) NVM-4070 Portable Navigation System Chapter 4 Communications...

  • Page 29: Contacts

    Index Input each item. All categories and items are as follows: 4.3.2 Call-out Select the entry and tap the “Call-out” button. Select one of the enabled buttons, NVM-4070 starts to make a call to the Category Record selected number. First...

  • Page 30: Call-out

    Tap “YES” to delete. 4.4.1 File Transfer Not all mobile phones support “File Transfer”. NOTE: Tap “File Transfer” button. Files and folders on mobile phone appears. moves to upper folder. File display scroll NVM-4070 Portable Navigation System Chapter 4 Communications...
