Service Manual
Vacuum Cleaner
Model: A2161
RC-507
RC-408B
RC-408F
A2161, RC-507, RC-408B
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
http : //svc.dwe.co.kr
S/M No. : RC408F0010
RC-408F
Mar. 2000
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo A2161
Summary of Contents for Daewoo A2161
-
Page 1: Vacuum Cleaner
Vacuum Cleaner Model: A2161 RC-507 RC-408B RC-408F A2161, RC-507, RC-408B RC-408F Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). -
Page 2: Table Of Contents
TABLE OF CONTENTS 1. SPECIFICATIONS .......................... 2 2. EXTERNAL VIEWS ......................... 3 1. ASSEMBLY ........................... 3 2. MODEL A2161, RC-507 ....................... 3 3. DIAGRAM ............................4 1. WIRING DIAGRAM ........................4 2. CIRCUIT DIAGRAM ........................5 4. TROUBLE SHOOTING GUIDE ....................... 6 5. -
Page 3: Specifications
1. SPECIFICATIONS MODEL A2161 / RC-507 RC-408F RATED VOLTAGE/FREQUENCY 230V/50Hz INPUT WATT NOR(1100W) MAX(1300W) WEIGHT(BODY) 3.7Kg DIMENSION(LHD) 482 X 272 X 223KW CORD LENGTH POWER CONTROL ELECTRONIC VARIABLE ON/OFF DUST METER MECHANICAL HOSE NON-CURRENT 1.6m 2 PLASTICS / STEEL PIPE... -
Page 4: External Views
E - CORD REWIND BUTTON F - POWER CORD G - HOSE ASSY H - NORMAL BRUSH I-1 - EXTENSION PIPE (2 Plastic Tubes) I-2 - EXTENSION PIPE (Steel Telescopic Tube) POWER CONTROL ELECTRONIC VARIABLE ON/OFF TYPE 2. MODEL RC-507, A2161... -
Page 5: Diagram
3. DIAGRAM 1. WIRING DIAGRAM 1) MODEL : A2161, RC-507 2) MODEL : RC-408F... -
Page 6: Circuit Diagram
DIAGRAM 2. CIRCUIT DIAGRAM 1) MODEL : A2161, RC-507 2) MODEL : RC-408F... -
Page 7: Trouble Shooting Guide
4. TROUBLE SHOOTING GUIDE T R O U B L E C A U S E C O U N T E R M E A S U R E S U C T I O N P O W E R F I L T E R B A G ( P A P E R O R C L O T H ) C H A N G E I T W I T H N E W O N E IS W E A K... -
Page 8: Disassembling And Treatment
5. DISASSEMBLING AND TREATMENT 1. CLEANER ASSEMBLY 1) TAKE THE COVER TOP OUT OF THE COVER BODY BY USING AN AWL. 2) SEPARATE THE COVER DUST ASSEMBLY FROM THE COVER BODY. 3) UNSCREW THE 6 SCREWS(2) THEN LIFT THE COVER BODY UP FROM THE BODY ASSEMBLY. 4) SEPARATE THE TWO BUTTONS FROM THE COVER BODY. -
Page 9: Motor Assembly
DISASSEMBLING AND TREATMENT 2. MOTOR ASSEMBLY 1) TAKE THE MOTOR ASSEMBLY OUT OF THE BODY. 2) CHECK THE MOTOR(1) (WHETHER THE MOTOR IS BURNT OUT OR NOT). -
Page 10: Cord Reel Assembly
DISASSEMBLING AND TREATMENT 3. CORD FREEL ASSEMBLY 1) TAKE THE CORD REEL OUT OF THE BODY. 2) UNSCREW THE SCREW(18) AND SEPARATE THE BOBBIN(1) FROM THE BRACKET(10) AND CHECK THE CONTACTS BETWEEN THE Y TYPE TERMINALS AND THE RING TYPE TERMINALS(3, 4). 4) CHECK THE LEVER SPRING(17). -
Page 11: Cover Dust Assembly
DISASSEMBLING AND TREATMENT 4. COVER DUST ASSEMBLY 1) UNSCREW THE 6 SCREW(10) AND SEPARATE THE PLATE COVER(1) FROM THE COVER DUST(7). 2) UNSCREW THE 2 SCREW(4) AND SEPARATE THE SOCKET(3) FROM THE PLATE COVER(1). -
Page 12: Cover Body Assemly
DISASSEMBLING AND TREATMENT 5. COVER BODY ASSEMBLY 1) MODEL : A2161, RC-507 1) CHECK THE CONNECTIONS BETWEEN THE PCB ASSY(3) AND THE WIRE. 2) CHECK THE PCB ASSY(3) 3) CHECK THE SWITCH(5) - Page 13 DISASSEMBLING AND TREATMENT 2) RC-408F 1) CHECK THE CONNECTIONS BETWEEN THE C/R ASSY AND HARNESS(3). 2) CHECK THE SWITCH(4).
-
Page 14: Exploded View And Parts List
6. EXPLODED VIEW AND PARTS LIST 1. CLEANER ASSEMBLY 1) A2161, RE-507 PART NAME PART CODE SPECS. BODY AS 3620408900 ASSY ASSY MOTOR 3962511400 230V 1100W VH111CA010 CORD REEL AS 3629507200 ASSY COVER AS 3621426000 ASSY FILTER BOX AS 4569C21000... - Page 15 EXPLODED VIEW AND PARTS LIST 2) RC-408F PART NAME PART CODE SPECS. BODY AS 3620408900 ASSY ASSY MOTOR 3962511400 230V 1100W VH111CA010 CORD REEL AS 3629507300 ASSY PCB AS 3624304710 ON/OFF PCB COVER AS 3621426100 ASSY FILTER BOX AS 4569C21000 ASSY HOLDER FILTER AS 3623001700...
-
Page 16: Motor Assembly
EXPLODED VIEW AND PARTS LIST 2. MOTOR ASSEMBLY (A2161, RC-507, RC-408F) PART NAME PART CODE SPECS. MOTOR UNIVERSAL 3962511400 230V 1100W VH111CA010 ABSORBER MOTOR 4569C10071 PU FOAM CAP MOTOR F 4565T20040 NR FORM MOUNT MOTOR 3627900201 Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the... -
Page 17: Cord Reel Assembly
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) 3. CORD REEL ASSEMBLY 1) MODEL : A2161, RC-507 (3629501200) PART NAME PART CODE SPECS. - Page 18 EXPLODED VIEW AND PARTS LIST Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) 2) RC-408F (36295077300) PART NAME PART CODE...
-
Page 19: Cover Dust Assembly
EXPLODED VIEW AND PARTS LIST 4.COVER DUST ASSEMBLY (3612423600) PART NAME PART CODE SPECS. PLATE COVER 3624502000 PACKING PLATE 3624006400 SOCKET 3629800800 SCREW TAPPING 7121401211 T2S PAN 4 X 12 MFZN DUST METER AS 3629703000 ASSY SPRING 4569C52031 HSW3 COVER DUST 3621403800 CLAMP COVER 3621202500... -
Page 20: Cover Bldy Assembly
EXPLODED VIEW AND PARTS LIST 5. COVER BODY ASSEMBLY 1) A2161 / RC-507 (3621426000) PART NAME PART CODE SPECS. COVER BODY 3621423700 COVER DUST AS 3621423600 ASSY POWER CONTROL PCB 3624309800 ASSY(200KΩ) SCREW TAPPING 7121401011 T2S PAN 4X10 MZN PUSH SWITCH... - Page 21 EXPLODED VIEW AND PARTS LIST 2) RC-408F (3621426100) PART NAME PART CODE SPECS. COVER BODY 3621423700 COVER DUST AS 3621423600 ASSY HARNESS 3622711700 3P HOUSING + 187RE PUSH SWITCH 3629002000 DPC 1114 SPRING BUTTON 3625108400 HSW3 BUTTON SWITCH 3626605000 BUTTON CR 3626605100 COVER TOP(F) 3621424100...
-
Page 22: Hose Assembly
EXPLODED VIEW AND PARTS LIST 6. HOSE ASSEMBLY (3623207400) PART NAME PART CODE SPECS. PIPE ADAPTER 3629102000 HOSE 3623207500 EVA, 1.6m HOLDER HOSE 4569A71021 PIPE HOSE 3624408200 VALVE AIR 3625400400 CUFF HOSE 3620800200 LDPE PACKING HOSE 3624005900 SPONGE Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) -
Page 23: Pipe Assembly
EXPLODED VIEW AND PARTS LIST 7. PIPE ASSEMBLY 1) A2161, RC-408 F (3624412220) PART NAME PART CODE SPECS. PIPE EXTENSION 3624408500 HOLDER PIPE 3623001900 SCREW TAPPING 7121401411 T2S PAN 4 X 14 MFZN 2) RC-507 PART NAME PART CODE SPECS. -
Page 24: Brush Assembly
EXPLODED VIEW AND PARTS LIST 8. BRUSH ASSEMBLY (3629307300) - Page 25 EXPLODED VIEW AND PARTS LISTf PART NAME PART CODE SPECS. BODY BRUSH 4560F90010 COVER BRUSH 4560F90080 ROLLER BRUSH 4560F90020 PIN BRUSH 4560F90110 SWRM ROLLER BRUSH 4560F90090 PIN ROLLER 4560F90120 SWRM HOLDER BRUSH AS 4568B91001 ASSY LEVER BRUSH 4560F90040 SPRING 4568B90050 HSW 3 PIPE BRUSH 3624408300...
