Plantronics Voyager PRO User Manual

Plantronics Voyager PRO User Manual

Hd bluetooth headset
Hide thumbs Also See for Voyager PRO:
Table of Contents

Advertisement

Quick Links

Download this manual
Plantronics Voyager
PRO
®
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Plantronics Voyager PRO

Summary of Contents for Plantronics Voyager PRO

  • Page 1 Plantronics Voyager ® User Guide...

  • Page 2: Getting Assistance

    Registering Your Product Thank you for purchasing the Plantronics Visit www.plantronics.com/productregistration to Voyager PRO headset. This guide contains register your product online so we can provide instructions for setting up and using your new you with the best service and technical support.

  • Page 3: Table Of Contents

    Contents Package Contents and Accessories ........... iv Charging Your Headset ..............2 Checking the Battery Status ..........3 Automatic Battery Status Alerts .........3 Pairing Your Headset ..............4 How to Pair Your Headset for the First Time ......4 Adjusting the Fit ................6 Changing Ear Tips ..............7 Headset Controls and Indicators..........8 Product Specifications...

  • Page 4: Package Contents And Accessories

    Package Contents and Accessories Volume Up (+) and Down (-) Buttons Mute (press +/- buttons simultaneously) Call Control Button Status Indicator (LED) Power On/Off Button Micro USB Charging Jack Microphones...
  • Page 5 Package Contents and Accessories Soft Gel (S, M, L) Eartips and Foam Eartip Cover Call Control Button Charging Case Status Indicator (LED) Power On/Off Button AC Charger Eartip For a complete list of accessories available for purchase, go to www.plantronics.com.

  • Page 6: Charging Your Headset

    Charging Your Headset Using the AC Charger Your new headset performs best when fully charged. Plug the AC charger into a power outlet. Connect the AC charger to the charging jack on the headset. CHArgIng STATUS IndICATOr LIgHT Charge Level Indicator Light Fast charge Solid red LEd during charge...

  • Page 7: Checking The Battery Status

    Charging Your Headset Checking the Battery Status Automatic Battery Status Alerts Your headset is equipped with an embedded, When the battery charge is very low, a vocal non-replaceable battery that can be recharged. warning and tone will automatically occur. To check the status, the headset must be powered LOW BATTErY WArnIngS on.

  • Page 8: Pairing Your Headset

    Bluetooth enabled phone. Your ® For most phones, select Settings/Tools > new headset includes Plantronics QuickPair Connections > Bluetooth > On. See your Technology to simplify the Bluetooth setup phone’s user guide for more information. process. The first time you turn your earpiece on, your earpiece automatically enters pairing Turn the headset on.
  • Page 9 Pairing Your Headset SSP, your phone will automatically locate and pair with this headset. SETTINGS SETTINGS Time and Date Phone Settings Bluetooth Sound Settings Use the commands on your phone to Network Services Security Reset Settings locate your headset. For most phones, select Settings/Tools > Connections >...

  • Page 10: Adjusting The Fit

    Adjusting the Fit Place the earloop behind your ear and rotate the headset so that the speaker rests comfortably in your ear. Align the microphone with the corner of your mouth. For optimal voice clarity, pivot the boom toward the corner of your mouth. The headset can be worn on either ear by swiveling the speaker housing and closed boom.

  • Page 11: Changing Ear Tips

    Adjusting the Fit Changing Ear Tips The headset comes with the medium eartip installed, but you can replace it with the optional small or large eartip provided. To remove the eartip, grip the eartip with your thumb and forefinger. Gently push it down and rotate it a quarter turn to the left to align with slots on the eartip with the speaker housing.

  • Page 12: Headset Controls And Indicators

    Double tone when min/max volume level reached. WARNING Do not use headsets at high volumes for an extended period of time. Doing so can cause hearing loss. Always listen at moderate levels. See www.plantronics.com/healthandsafety for more information on headsets and hearing.
  • Page 13 Headset Controls and Indicators Action Indicator Light Tone Redial Double-tap call None Double low tone control button Voice-activated Press call control None Single low note (phone dialing button for 1 second may then prompt you to say a name) Transfer a call from While on a call, press None Single followed by double...

  • Page 14: Product Specifications

    Product Specifications Talk time* Up to 6 hours Power 5V DC – 180 mA requirements Standby time* Up to 5 days or 120 hours Storage/operating 50F – 104F (10C-40C) temperature Range* Up to 33 feet (10 meters) Charging 32F - 104F (0-40C) Headset weight 17.5 grams temperature...

  • Page 15: Using More Than One Bluetooth Phone

    Using More Than One Bluetooth Phone Plantronics Voyager PRO supports multipoint How to Answer a Call While Talking on the Other Phone technology, which allows you to use one headset with two different Bluetooth mobile To answer the second call, the first call must be phones.

  • Page 16: Troubleshooting

    Troubleshooting My phone did not Turn both your phone and headset off and on, and then repeat the pairing process locate the headset. on page 4. I could not enter Turn both your phone and headset off and on, and then repeat the pairing process my PIN code/Passkey.

  • Page 17: Limited Warranty

    4. Turn the volume down if the sound from the earpiece prevents you from hearing people speaking near you. See www.plantronics.com/healthandsafety for more information on earpiece and hearing. • Use of a earpiece that covers both ears will impair your ability to hear other sounds.
  • Page 18 • To reduce the risk of electric shock, explosion or fire, use only the charger supplied by Plantronics to charge the product. Do not use the chargers with other products or for any other purpose. Ensure that the voltage rating corre- sponds to the local mains or power supply you intend to use.
  • Page 19 • If your product has a replaceable battery, use only the battery type supplied by Plantronics. Observe the correct polarity when installing the battery. Remove the battery if it will not be used for an extended period; remove a spent battery promptly.

  • Page 21: Regulatory Notices

    regulatory notices INDUSTRY CANADA RADIO EQUIPMENT The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 22 We will, at our option, repair or replace the products that do not conform to the warranty. We may use func- tionally equivalent reconditioned/refurbished/remanufactured/pre-owned or new products or parts. To obtain service in the U.S., contact Plantronics at 1-866-363-BLUE (2583). To obtain service in Canada call (800) 540-8363.
  • Page 23 Plantronics, Inc. The Bluetooth word mark and logos are owned by ® the Bluetooth SIG, Inc. and any use of such marks by Plantronics, Inc. is under license. All other trademarks are the property of their respective owners. US Patents Pending.
