- Page 1 WINDOW HEAT PUMP USER MANUAL FOR MODELS: COOLING HEATING CAPACITY CAPACITY WHP49230R WHP49ZR 9,200/9,500 BTU 11,200/11,600 BTU WHP412230R WHP412ZR 8,100/8,400 BTU 10,000/10,300BTU 950-0190revD 02/19/2014...
-
Page 2: Table Of Contents
CONTENTS INSTALLATION REQUIREMENTS ........................2 Tools and Parts ............................2 Location Requirements ..........................3 Electrical Requirements ..........................4 INSTALLATION INSTRUCTIONS......................... 5 Unpacking ..............................5 Window Installation ............................5 Wall Installation ............................8 Complete Installation ........................... 9 AIR CONDITIONER USE ........................... 10 Air Conditioner Controls .......................... -
Page 3: Installation Requirements
INSTALLATION REQUIREMENTS Tools and Parts Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here. Tools Needed Flat-blade and Phillips head screwdriver Ruler or tape measure Drill and 3/16” or smaller bit Level Pencil Scissors or Utility knife... -
Page 4: Location Requirements
Location Requirements IMPORTANT: Observe all governing codes and ordinances. Check the location where air conditioner will be installed. Proper installation is your responsibility. Make sure you have everything necessary for correct installation. The location should provide: • Grounded electrical outlet within 4 ft (122 cm) of where the power cord exits the air conditioner. -
Page 5: Electrical Requirements
Electrical Requirements This room air conditioner is equipped with a power supply cord required by UL. This power supply cord contains state-of-the-art electronics that sense leakage current. If he cord is crushed, the electronics detect leakage current and power will be disconnected in a fraction of a second. -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Unpacking 3. Remove front panel by removing 2 Phillips screws on both sides. 4. Pull on handle to slide air conditioner out of cabinet. Place air conditioner on cardboard. 5. Remove any packing foam from inside of unit. Remove packaging materials. - Page 7 While the right hand curtain is still extended, insert #10 x ¼” pan-head Phillips screws into the top and bottom slots of curtain. Screw Curtain to the top and bottom holes in air conditioner cabinet. NOTE: Some curtains may have 2 slots on each end. You will be able to see a mounting hole through the correct slot.
- Page 8 Attach Side Curtains to Window Frame 1. Pull left-hand curtain out until it fits into window channel. Use a 3/32” drill bit to drill a starter hole through the hole in the curtain housing and into the lower window sash. Front View 4.
-
Page 9: Wall Installation
3. Use a 3/32” drill bit to drill a starter hole through the hole in the bracket and into the window sash. 4. Attach window-lock bracket to window sash with #10 x ¾” round-head screw to secure window place. Window lock bracket (2) Foam seal Upper window glass #10 x 1/2”... -
Page 10: Complete Installation
Complete Installation NOTE: Handle air conditioner gently. 2. Install ground screws on both sides of cabinet. 3. Insert front tabs of front panel into top of cabinet and swing front into place. 4. Attach bottom front of panel with front panel screws. 1. -
Page 11: Air Conditioner Use
AIR CONDITIONER USE ---------------------------------------------------------------------------------------------------------------------------------- Cool Mode Feature Use the Cool mode at Low, Med, High or Auto Fan NOTE: Speed for cooling. Use the Temperature Increase If the air conditioner is off and is then turned on while set /Decrease pads to set the desired temperature between to a Cool setting or if turned from a fan setting to a Cool 64°F and 86°F in 1°F increments. - Page 12 ---------------------------------------------------------------------------------------------------------------------------------- Auto Fan Speed Feature The Auto fan speed allows the speed to be automatically adjusted as needed to provide optimum NOTE: Auto Fan Speed cannot be used when in the Fan comfort. If the room needs more cooling, the fan speed Only Mode.
-
Page 13: Air Conditioner Controls
Air Conditioner Controls 1. Power button – Turns the air conditioner on and is satisfied. When the outdoor temperature is off. below 55°F the electric heat will be activated and the compressor will turn off. 2. Display – Indicates the set temperature when in Heat/Cool/Energy Saver mode. -
Page 14: Normal Sounds
Normal Sounds When your air conditioner is operating normally, you may hear sounds such as: • • Droplets of water hit the condenser, causing a Vibrations or noise due to poor wall or window pinging or clicking sound. The water droplets construction. -
Page 15: Air Conditioner Care
AIR CONDITIONER CARE Your new air conditioner is designed to give you many years of dependable service. This section tells you how to clean and care for your air conditioner properly. Call your local authorized dealer for an annual checkup. Remember, the cost of this service call is your responsibility. -
Page 16: Trouble Shooting
TROUBLE SHOOTING Before calling for service, try the suggestions below to see whether you can solve your problem without outside help. An extension cord is being used. Do not use an Air conditioner will not operate extension cord with this or any other appliance. You are trying to restart the air conditioner too soon after turning the unit off. - Page 17 Air Conditioner cycles on and off too Windows or doors to the outside are open. Close often, or does not cool room in cooling all windows and doors. mode The temperature set point or The air conditioner is not properly sized for your Thermostat control is not at a cool enough setting.
-
Page 18: Specifications
SPECIFICATIONS WHP49230R WHP412230R Model WHP49ZR WHP412ZR Cooling Capacity 9200/9500 11200/11600 Heating Capacity 8100/8400 10000/10300 Electric Heat Capacity 8500/10700 8500/10700 EER Rating COP Rating Dehumidification (pints/hr) 4.54 Air Flow Max (CFM) Rated Voltage 208-230 208-230 Operating Voltage Range 198-253 198-253 Frequency/Cycle Cooling Amps 4.8/4.6... -
Page 19: Warranty
WARRANTY International Refrigeration Products warrants that the product supplied is free from defects in material and workmanship. This warranty is valid as long as this product is properly handled, installed, operated and serviced in accordance with the Installation and Operating Instructions shipped with this unit, and the warranty card is completed and mailed no later than 30 days after date of purchase.
