Telcel MAXX User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
Preface
Please read the following guidelines before using your new phone. Utmost
compliance with the following is highly recommended for your safety.
Non-compliance may pose danger to you and your mobile phone, and may be
illegal.
The phone is packed with features to satisfy your needs such as Phonebook, Music
Player, Video Player, Digital Camera, among others. It is Wi-Fi and Bluetooth and
also meets the GSM/GPRS technical criteria. It is certified by both local and
international authorities.
We reserves the right to modify technical specifications without prior notice.Some
TELCEL
content in this manual, i.e. software, images, accessories and more, may vary from
that in the actual device. Please refer to your unit for accuracy.
This guide aims to help you get started on your new phone. you will find the
following icons periodically present to help you make better use of your device.
- indicates sequence of processes
MAXX
- presents additional notes on a topic or alternative options for a feature
- shows further cautionary measures to prevent damage to your mobile phone
User Manual
1
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAXX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Telcel MAXX

Summary of Contents for Telcel MAXX

  • Page 1 - indicates sequence of processes MAXX - presents additional notes on a topic or alternative options for a feature - shows further cautionary measures to prevent damage to your mobile phone...

  • Page 2: Getting Started

    1. Getting Started Install / Remove the SIM Card and Battery Make sure to switch off the device and disconnect from charger before installing and removing the SIM card and battery. To install / remove the SIM card and battery, perform the following: Turn the mobile phone OFF.
  • Page 3 Install / Remove the Memory Card Charge the Battery The Memory Card is a handy mobile storage device that expands the mobile Plug the charger into the electrical outlet. phone’s storage capacity. To install/remove the memory card, perform the Connect the small end of the charger connector into the mobile following: phone’s charging slot.
  • Page 4 Switch to Sleep Mode / Wake Up Pattern lets you draw a simple pattern with your finger to unlock the tablet. This is The Sleep Mode suspends your device to a low power consumption state in order slightly more secure than Face Unlock. to prolong battery life.
  • Page 5 2. Overview Personal Identification Number (PIN) Local network service providers furnish each SIM card with a unique set of codes Functions of Main Keys including the PIN, PIN2 and PUK. If the PIN is incorrectly entered for three Menu Key – Allows you to change wallpaper/widgets manage apps, access successive times, the SIM card will be locked.
  • Page 6 SWIPE OR SLIDE - lets you scroll the screen up, down, left or right. It is also used Auto-Rotate Screen when unlocking the screen. Lightly and quickly touch and slide your finger across With the Auto-Rotate Screen turned on, you will be able to view items on the the screen without pausing to avoid dragging an item instead.

  • Page 7: Magnification Gestures

    To remove applications out of a folder back to the Home Screen Found on the top part of the screen, swipe the notifications panel (also known as Touch and hold the item in a folder, and then drag it out of the folder. the status bar) downwards.

  • Page 8: Basic Functions

    : The triple-tap magnification gesture works on any screen except the keyboard and navigation bar. Dial an Emergency Call To activate, go to Settings Accessibility  Magnification Gestures  ON. This phone operates using radio signals, wireless and landline networks, but cannot guarantee connection in all locations at all conditions.
  • Page 9 Adjust the Volume During a call, press the Volume keys to adjust the volume. Options During a Call - Launch/Hide Dial Pad - Turn speakerphone on/off - Mute - Put a call on hold - add current call’s details to contacts. Messaging To create and send message from home screen, People...
  • Page 10 Connect to the Internet : To send MMS, add an attachment to the text message by tapping and the SMS will automatically be sent as an MMS. Likewise, if the user removes the Connect to a wireless network to browse Internet. attachment, the message is reverted back to being sent as SMS.
  • Page 11 4. Main Menu Capturing an Image The Main Menu displays all the applications your phone has. You may access the Aim the phone at the subject, and then tap to take a shot. - view recently captured image Main menu by tapping on the Menu icon [ ] from the Home Screen.
  • Page 12 Camera File Manager Please see “Capture and View Photo or Video” The File Manager lets you view, open and manage the data saved in your phone and Memory card. Go to   choose from Phone Storage / SD Card. Clock This function shows the current time and date, and gives you access to the alarm - New folder...
  • Page 13 Gallery Music To view captured images, recorded video clips, and downloaded images, go to Use the Music to play music and audio files. Go to  The songs are categorized into tabs: Artists, Albums and Songs. To create a  Click on a thumbnail to open an album.

  • Page 14: Tap  Import/Export

    store, locate and view your saved contacts. Aside from these, People also allows  Received call you to copy, edit and delete a contact.  Outgoing call : You can also send SMS / MMS or call a contact directly from People, as well ...
  • Page 15 The features of your STK are offered by your service provider. If your SIM card to share on Youtube,Picasa, Messaging, Bluetooth, Google+, Email supports the STK feature, you will see the STK menu. You may contact your and Gmail. network service provider for more information regarding the STK. To access, tap Settings ...

  • Page 16: Security Screen

    distance of about 10 meters. The Bluetooth devices must be paired before the function, when turned ON, disables all wireless connection to any network. communication is performed. However, with the airplane mode, you can make use other functions of your device such as playing music, watching videos and capturing images and videos.

  • Page 17: Audio Profiles

    you cannot use your phone’s W-Fi capability when it is working as a hotspot. Go to In this sub-menu, you can change the settings for the phone’s Lock screen notifications,Wallpaper,Brightness,Auto-RotateScreen,Sleep,Daydream,Font  More  Tethering and Portable Hotspot.  size ,Fonts, Cast screen. : For further information, go to Tethering and Portable Hotspot ...
  • Page 18 Location Note: Encryption takes an hour to accomplish. For more info, tap   Your device supports Global Positioning System. The settings related to the Security  Encrypt your phone. location, EPO and AGPS can be configured using this sub-menu. This allows apps to determine your location and use this to speed up process Set up SIM Card Lock when searching for places using GPS and improving Google search results.
  • Page 19 The Factory Data Reset erases all data in your phone’s internal storage including  Large text  your accounts, system and app data, downloaded apps. Power button ends call  To access this, go to   Backup & Reset DRM reset /Factory Data Auto-rotate screen Reset Reset Phone ...
  • Page 20 Window animation scale – Animation scale 1x Applications for telcel. Transition animation scale –Animation scale 1x TELCEL You can access the TELCEL SIM tool kit via this menu. Animator duration scale –Animation scale 1x Portal Claroideas Disable HW overlays – Always use GPU for screen compositing You can access the internet webpage via Portal ideas directly.

  • Page 21: Important Safety Precautions

     Use only authorized accessories and batteries by the manufacturer. The You can access the TELCEL music service via this menu use of incompatible batteries and accessories may cause battery leaks, overheating, rupture or fire. This may also nullify your warranty.
  • Page 22 dangerous as it may cause interference in the operation of electrical and  Do not use a damaged battery or charger. If battery life becomes medical equipment. noticeably shorter than usual, it is recommended to replace it with a new ...

  • Page 23: Troubleshooting

    Cleaning and Maintenance  Remove and insert the battery, and switch your phone on again.  The handset, battery and charger are not water-resistant and should The phone switches off by itself always be kept dry. Avoid using them in excessively moist areas. ...
  • Page 24   Make sure that SIM card is properly inserted in its intended spot. Check if the Phonebook is full. If so, you may have to delete some  Make sure that the chip in the SIM card is not damaged or the SIM records in order to accommodate new ones.

  • Page 25: Body-Worn Operation

    § 15.105 Information to the user. averaged over one gram of tissue. Device types: MAXX(FCCC ID:YPVITALCOMMAXX) Note: This equipment has been tested and found to comply with the limits for a Class B has also been tested against this SAR limit. The highest SAR value reported under this digital device, pursuant to part 15 of the FCC Rules.
  • Page 26 Body-worn accessories that do not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna.
