- Page 1 ACS-11(P)-MF Access Control Reader User’s Manual www.icpdas.com ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 1...
- Page 2 Copyright 2016 by ICP DAS. All rights are reserved. Trademark The names used for identification only may be registered trademarks of their respective companies. Document Revision Version Date Description of changes 2016/04/18 First Release Revision ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 2...
-
Page 3: Table Of Contents
Card Number Inquiry ..............33 4.2.5 Add Password Number ..............34 4.2.6 Delete Password Number .............. 34 4.2.7 Delete All Passwords’ Number ............35 4.2.8 Inquire Access Record ..............35 4.2.9 Delete Access Record ..............36 ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 3... - Page 4 4.2.10 Configure System Time ..............36 4.2.11 Check Door Position............... 37 CRC Calculation (CCITT-16)............37 ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 4...
-
Page 5: Introduction
1. Introduction Access Control systems are one of the most important infrastructures for a safe, secure society. ACS-11-MF/ACS-11P-MF is an access control reader that supports keypad and RFID induction of access control. It integrates three functions of door access control, voice guidance and floor control all in one, suitable for use in community door access and elevator control. -
Page 6: Features
• Supports electronic lock control and door position detection • Provides access records • Max card capacity：8000 cards • Supports elevator floor control (max. 16F) Applications Specifications Table 1-1: System Specifications Models ACS-11-MF ACS-11P-MF CAN Bus Baud rate(bps) Specification ISO-11898-2, CAN 2.0A/B UART RS-485(D+, D-) - Page 7 Wall Mounting (Suitable for the outlet box in United States) Dimensions 83mm x 120mm x 28mm (W x L x H) Environment -20℃ ~ +60℃ Operating Temperature -30℃ ~ +80℃ Storage Temperature Humidity 10% ~ 90%, non-condensing ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 7...
-
Page 8: Hardware
Elevator control module 1 connection failed Blink per 2000 ms Elevator control module 2 connection failed Blink per 3000 ms Power failure RFID induction Blink Firmware update mode Blink per 500 ms Idle Data transmission Blink Idle ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 8... -
Page 9: Back Panel
2.2 Back Panel The back panel of the ACS-11(P)-MF module contains the Ethernet port and power, signal connectors. Figure 2-2: ACS-11-MF Connector Assignment Table 2-2: ACS-11-MF Pin Assignment Connector Type Pin Assignment Description Power (+10V~+30 VDC) DI0(Door position detection) DI1(Electric lock trigger) - Page 10 Parity: NONE Data Bits: 8 Stop Bits: 1 DI0(Door position detection) DI1(Electric lock trigger) (Digital Input, Dry Contact) Electronic lock control (Relay Output) Door position alarm output (Relay Output) Anti-sabotage detection (Relay Output) ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 10...
-
Page 11: Dimensions
2.4.1 Power and I/O wiring architecture ACS-11(P)-MF series modules provide a variety of communication interfaces to suit a range of applications. Below is a description of the configuration for simple applications using the ACS-11(P)-MF. ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 11... - Page 12 Figure 2-5: ACS-11-MF Power and I/O wiring architecture Figure 2-6: ACS-11P-MF Power and I/O wiring architecture ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 12...
-
Page 13: I/O Connection
Therefore, the ACS-11-MF module supplies a jumper for users to active the terminal resistor or not. If users want to use this terminal resistor, please open the ACS-11-MF cover and use the JP3 to activate the 120 Ω terminal resistor built in the module, as the Table 2-4. Note that the default setting is active. -
Page 14: Operation Mode Settings
Table 2-4: Terminal Resistor Jumper (ACS-11-MF) Jumper Position Enable (default) Disable 2.5.2 Operation Mode Settings ACS-11(P)-MF module supplies a jumper for users to select the firmware operation or firmware update mode of the module. Table 2-5: Operation Mode Setting Jumper (ACS-11(P)-MF) - Page 15 2. Set IP address as: IP 192.168.0.1 3. Click “Browser” button to choose firmware file (ACS-11-MF_vx.fw) 4. Click “Firmware Update” button to start firmware updating process 5. After firmware update is complete, please reset the power of ACS- 11(P)-MF ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 15...
- Page 16 Figure 2-10: Firmware update process ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 16...
-
Page 17: Software
3.1 Installing the eSearch Utility The eSearch Utility is a useful tool that provides a quick and easy way to configure the Ethernet settings to the ACS-11-MF from a PC. Step 1： Install the eSearch Utility tool The eSearch Utility can be obtained either from the companion CD at:... - Page 18 All ACS-11-MF series module are IP-based devices that may not be suitable for your network using the default IP address. Therefore, you must first assign a new IP address to the ACS-11-MF series module depending on your network settings. ACS-11-MF...
- Page 19 Contact your Network Administrator to obtain the correct network configuration information. Modify the network settings as necessary and then click the “OK” button. The ACS-11-MF series module will use the new settings immediately. (ACS-11-MF doesn’t support DHCP function) Step 5：After save the settings, ACS-11-MF will automatically reboot and then press the "Search Servers"...
-
Page 20: Web Configuration
Step 1：Open a browser Use a standard internet browser to view the ACS-11-MF web pages, such as Google Chrome, Mozilla Firefox and Internet Explorer are reliable and popular internet browsers that can be used to configure ACS-11-MF series module. -
Page 21: Ip Address Configuration
Step 4: Log in to the ACS-11-MF web server After logging into the ACS-11-MF web server, the "IP Config" page will be displayed. The first section provides basic information related to the ACS-11- MF series module hardware and software including the Firmware version, MAC Address and IP Address, etc. - Page 22 Close(Default): Static IP: If there is no DHCP server installed in your network, you can configure the network settings manually. Each ACS-11-MF device connected to the network must have its own unique IP address. This parameter is used to assign a specific IP address (Default:192.168.0.1)
-
Page 23: Reader Configuration
3.3.2 Reader Configuration Clicking the "Reader Configure" tab will display the settings page allowing you verify the current settings and configure the general parameters for the ACS-11-MF device, each of which will be described in more detail below. ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 23... - Page 24 (Default:TCP) The station Identifier in RS-485 connection type application. Host station (Default:1) number (Range:1~247) Communication port number of ACS-11-MF. Port number (Default:10001) (Range:1~65535) The module information indicates the name of the alias that Reader Name is used to identify the module.
-
Page 25: Rtc Configuration
3.3.3 RTC Configuration Clicking the "RTC Configure" tab will display the settings page allowing you verify the current system time settings of the ACS-11-MF device. Item Description Reference computer time to set the system time of the RTC Calibration module 3.3.4 Change Password Configuration... -
Page 26: Installation
Note. Windows XP or Windows 2003: Install version 1.8.2 of XAMPP that includes PHP version 5.4 or earlier. Installation includes: a. Apache web server b. MySQL database c. PHPMyAdmin web database management program 02. Select Components to install 03. Completing the XAMPP setup ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 26... - Page 27 04. Launch XAMPP control panel and start Apache and MySQL service 05. Entry MySQL management environment 06. Import database file of access control system – acs.sql ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 27...
- Page 28 Entry the IP address as "192.168.0.x", where "x" is a number between 1 and 254 except 1, Subnet mask as "255.255.0.0". Finally, press "OK" button. b. Establish a network connection between PC and ACS-11-MF Step 3: Install Door Access Control Communication Program ACS-11-MF...
- Page 29 Step 4: Configure Mifare card UID in the database 01. Launch Database Communication Program (RFIDCardReader_DB.exe) a. Fill and Add ACS-11-MF IP address: 192.168.0.1 a. Fill card UID: 2632528336 b. Fill voice number: 0 c. Select ACS-11-MF IP address: 192.168.0.1 d. Fill floor control selection: 1111111111111111(16F………………1F) e.
- Page 30 The program will automatically add the card UID to the ACS-11-MF a2. Place the Mifare card close to the ACS-11-MF a3. ACS-11-MF will read the card UID and return to database via Door Access Control Communication Program a4. Since the card UID is allowed, so ACS-11-MF will open the...
-
Page 31: Communication Command Example
Elevator Floor Open Time: 0x05 (5 Second) Voice Code: 0x30 0x31 (The 01 Voice Code) Response: Success Function Code Data Length Result CRCH CRCL 0xAF 0x01 0x01 Response: Fail Function Code Data Length Result CRCH CRCL 0xAE 0x01 0x01 ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 31... -
Page 32: Delete Card Number
Reserve CRCH CRCL (2 byte) 0x07 0x02 0x44 0x45 Response: Success Function Code Data Length Result CRCH CRCL 0xAF 0x01 0x01 Response: Fail Function Code Data Length Result CRCH CRCL 0xAE 0x01 0x01 ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 32... -
Page 33: Card Number Inquiry
EE 88 UID:9C E9 AE F2 00 00 00 00 Elevator Floor Selection: 01 00(1~8F, 9~16F) Voice Code: 30 34 Response (No such card) 01 01 00 01 80 01 80 A7 1C ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 33... -
Page 34: Add Password Number
4.2.6 Delete Password Number Function Data Password CRCH CRCL Code Length (8 byte) 0x43 0x08 Password: 0x01020304 (1234), the password data length is 4 byte, please fill the remaining data fields to zero ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 34... -
Page 35: Delete All Passwords' Number
UID: 0x9CEBA860 (2632689760), if the data length is less than 8 bytes, please fill the remaining data fields to zero. Access Time: 0x07 E0 04 12 0A 24 30 Year: 0x07 0xE0 (2016) ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 35... -
Page 36: Delete Access Record
Function Code Data Length System Time CRCH CRCL (7 Byte) 0x10 0x07 System Time: 0x07 E0 04 12 0A 24 30 Year: 0x07 0xE0 (2016) Month: 0x04 (4) Day: 0x12 (18) Hour: 0x0A (10) ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 36... - Page 37 (hexString.Length != 4) hexString = "0" + hexString; byte[] HexAsBytes = new byte[hexString.Length / 2]; for (int index = 0; index < HexAsBytes.Length; index++) string byteValue = hexString.Substring(index * 2, 2); HexAsBytes[index] = byte.Parse(byteValue, NumberStyles.HexNumber, CultureInfo.InvariantCulture); return HexAsBytes; ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 37...
- Page 38 (int j = 0; j < 8; j++) if (System.Convert.ToBoolean(CRC & 0x8000)) CRC_Init = (CRC_Init << 1) ^ CRC_Polynomial; else CRC_Init = (CRC_Init << 1); return HexStringToByteArray(Convert.ToString((UInt16)(CRC^ 0xFFFF), 16)); Example： Input: 0xAF, 0x01, 0x01 Data length: 3 Output：0xDE(CRCH), 0x81(CRCL) ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 38...
-
Page 39: Technical Support
2. Use eSearch Utility Step1. Launch eSearch.exe Step2. Press "Search Servers" button then find out IP address Technical Support If you have problems about using the ACS-11-MF series module, please contact ICP DAS Product Support. Email: service@icpdas.com ACS-11-MF User’s Manual (Ver.1.0, Apr./2016) ------------- 39...
