Chapter 1: Introduction
TCG220‐Tdp is a Full Band Capture Front End Cable Voice and Wireless Gateway which has an
802.11 b/g/n access point that gives you wireless connection to the Internet with 2 Giga
Ethernet ports which further expand the Local Area Network (LAN) capabilities.
If you have subscribed to phone services from your cable operator then you will be able to
place normal phone calls using your analogue phone and/or fax machine. TCG220‐Tdp provides
one RJ‐11 connector for your phone or home phone system.
TCG220‐Tdp will give you broadband Internet access, telephone connection and wireless
networking all in one unit. Besides that, this residential cable gateway offers Firewall for
additional protection and security and VPN (virtual private network).
Package Contents
Package Contents
TCG220‐Tdp WiFi EMTA
Ethernet Cable
Power Adaptor
QIG
Warranty card
Residential VoIP Cable Modem
Quick Start Guide
x1
x1
x1
x1
x1
x1
Advertisement
Table of Contents
Related Manuals for Askey TCG220
Summary of Contents for Askey TCG220
- Page 1 If you have subscribed to phone services from your cable operator then you will be able to place normal phone calls using your analogue phone and/or fax machine. TCG220‐Tdp provides one RJ‐11 connector for your phone or home phone system. TCG220‐Tdp will give you broadband Internet access, telephone connection and wireless networking all in one unit. Besides that, this residential cable gateway offers Firewall for additional protection and security and VPN (virtual private network). ...
- Page 2 Chapter 2: Overview Front Panel The following illustration shows the front panel of the EMTA: Power Indicates the Power status. Indicates the status of Data reception by the cable modem from the Network (Downstream Traffic) Indicates the status of Data transmission by the cable modem to the Network (Upstream Traffic) Online Displays the status of your cable connection. The light is off when no cable connection is detected and fully lit when the modem has established a connection with the network and data can be transferred Ethernet Indicates the state of Ethernet ports WIFI Indicates the traffic on the wireless network Indicates the status of the WPS functionality Indicates the status of the telephone Phone ...
- Page 3 There will be 9 LEDs on PKE1320SW‐D112(US‐Tdp‐RoHS) / TCG220‐TdP, but DS and US are bi‐color LED. Looking at LED from top to bottom: Power, DS(bi‐color), US(bi‐color), Online, Ethernet 1,2, WiFi , WPS, TEL. DS DS1 US US1 Power Online Eth1 Eth2 Wifi TEL (green (blue (green (blue color) color) color) color) Power Up ON X X X X Indicate Power On or OFF If during this process, the FW isn't in the Firmware CPE or there is a FW error and the CPE ...
- Page 4 Rear Panel Connector Description Slot Description 12VDC 12V DC‐IN Power connector CABLE F‐Connector RESET Reset/Reboot this Cable modem ETHERNET 1 2 Ethernet 10/100/1000 BaseT RJ‐45 connector TEL Telephony RJ‐11 connector ...
- Page 5 Side Panel for WPS WPS – Indicates the status of the WPS (Wi‐Fi Protected Setup ) functionality. There is one WPS button on the Top Side Panel of TCG220‐Tdp and is designed to have multiple function. This button can be used to: Securely and Simply Get WiFi Client Connected: WPS button can be used to pairing WiFi client which also supports WPS function. A long press (press more than 5 seconds) on the WPS button will enable TCG220‐Tdp scan for any available WPS device. Note: You must ensure that the WiFi client device supports WPS function in order to use this WPS function on TCG220‐TdP. ...
- Page 6 3. Connecting the Residential VoIP cable modem to Your Computer Installation Procedure for Ethernet Interface Follow the steps below for proper installation: 1. Connect one end of the coaxial cable to the CABLE connection on the wall, and the other end to the CABLE jack on the TCG220‐Tdp. Note: To speed up the registration process of cable modem, the coaxial cable should be connected to the modem before the modem turned ON 2. Connect the plug from the power supply into the POWER jack on the TCG220‐Tdp, and plug the power supply into an AC outlet. Note: Use only the power supply that accompanied this unit. Using other adapters may damage the unit. 3. Connect one end of the Ethernet cable to the Ethernet port of your computer, and the other end to the ETHERNET port on the TCG220‐Tdp. 4. The TCG220‐Tdp will look for the proper cable modem signal in the Cable Television network and process the initial registration. The voice gateway is ready for data transfer after the LED “Cable Link” is lit solid green. Note: The REBOOT button at the rear panel is for maintenance purposes only. You don’t need to use it. Fig. How to set up your connection ...
- Page 7 CAUTION for UL North American Cable Installer: This reminder is provided to call your attention to Article 820.93 of the National Electrical Code (Section 54 of the Canadian Electrical Code, Part 1) which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical. This symbol on your set guarantees that your product complies with the European Directives 1999/5/EC and 2009/125/EC on Safety, Telecom, Electromagnetic Compatibility and Energy using Products. ...
- Page 8 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. ...
