OWNER'S MANUAL
DUAL FUEL RANGE
Read this owner's manual thoroughly before operating the appliance
and keep it handy for reference at all times.
WARNING
If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or death.
% Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
% WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance.
- Do not touch any electrical switch.
- Do not use any phone in your building.
- Immediately call your gas supplier from a neighbor's phone. Follow the
gas supplier's instructions.
- If you cannot reach your gas supplier, call the fire department.
% Installation and service must be performed by a qualified installer, service
agency, or the gas supplier.
SKSDR480SIS
MFL68920520_00
www.thesignaturekitchen.com
Copyright © 2017 Signature Kitchen Suite. All Rights Reserved.
