Model: PSJ-1812
Jump Starter and DC Power Source
OWNER'S MANUAL
READ THE ENTIRE MANUAL BEFORE USING THIS PRODUCT.
FAILURE TO DO SO CAN RESULT IN SERIOUS INJURY OR DEATH.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSJ-1812 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Schumacher Electric PSJ-1812

  • Page 1 Model: PSJ-1812 Jump Starter and DC Power Source • OWNER’S MANUAL • READ THE ENTIRE MANUAL BEFORE USING THIS PRODUCT. FAILURE TO DO SO CAN RESULT IN SERIOUS INJURY OR DEATH.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION PAGE IMPORTANT SAFETY INSTRUCTIONS PERSONAL PRECAUTIONS FEATURES CONTROL PANEL ChARgINg ThE INTERNAL bATTERY OF ThE JUMP STARTER OPERATINg INSTRUCTIONS STORAgE TROUbLEShOOTINg SPECIFICATIONS REPLACEMENT PARTS...
  • Page 3 IMPORTANT: READ AND SAVE THIS SAFETY AND INSTRUCTION MANUAL. SAVE THESE INSTRUCTIONS – Charge the Jump starter internal bat- tery immediately after purchase, after every use and every 30 days. This manual will show you how to use your Jump starter safely and effectively. Please read, understand and follow these instructions and precautions carefully, as this manual contains important safety and operating instruc- tions.
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Risk of electric shock or fire. Use only recommended attachments. Use of an attachment not recom- mended or sold by Schumacher® Electric Corporation may result in a risk of fire, electric shock or injury to persons or damage to property. To reduce the risk of electric shock, unplug the Jump starter from the out- let before attempting any maintenance or cleaning.
  • Page 5 Risk of contact with battery acid. Battery acid is a highly corrosive sulfuric acid. Consider having someone close enough by to come to your aid when you work near a lead-acid battery. have plenty of fresh water and soap nearby in case battery acid contacts your skin, clothing or eyes.
  • Page 6: Features

    FEATURES Professional grade, high Output AgM battery built-In, Automatic 3 Amp Charger Charging Status LED’s Internal battery Status Switch Internal battery Status LED’s 12 Volt DC Power Outlet heavy Duty, battery Clips Durable Polyporpylene Case CONTROL PANEL • •...
  • Page 7: Charging The Internal Battery Of The Jump Starter

    CHARGING THE INTERNAL BATTERY OF THE JUMP STARTER IMPORTANT: CHARGE IMMEDIATELY AFTER PURCHASE, AFTER EACH USE AND EVERY 30 DAYS TO kEEP THE JUMP STARTER INTERNAL BATTERY FULLY CHARGED. LED Indicators: TO ChECk ThE INTERNAL bATTERY’S ChARgE STATUS, PRESS ThE bATTERY STATUS bUTTON ON ThE FRONT OF ThE JUMP STARTER.
  • Page 8: Operating Instructions

    OPERATING INSTRUCTIONS Jump Starting a Vehicle Engine Turn vehicle’s ignition OFF before making cable connections. If the jump starter is plugged into a 120V AC wall outlet, disconnect it. Never use the jump starter while the charger is connected or you may damage the jump starter or cause property damage.
  • Page 9: Storage

    The DC power outlet is wired directly to the internal battery. Extended operation of a 12V DC device may result in excessive battery drain. Re- charge immediately after unplugging the 12V DC device. Appliance Type Estimated Wattage Estimated Usage Time Cell Phone 4 watts 54 hours...
  • Page 10: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE REASON/SOLUTION The jump starter won’t Clips are not making a Check for poor connection jump start my car. good connection to the to battery and frame. Make battery. sure connection points are clean. Rock clips back and forth for a better connection.
  • Page 11: Specifications

    SPECIFICATIONS Model PSJ-1812 Internal battery Type Sealed, Maintenance Free, AgM, Lead Acid Nominal Voltage 12V DC Capacity 18Ah DC Power Output (Maximum Continuous Load) Peak Amps 1800 Cranking Amps Cold Cranking Amps battery hookup Cables 4 gauge, AWG, 28” (17.12 cm) Long Dimensions (H x W x D) 11” x 12” x 3.5” (27.94 cm x 30.48 cm x 8.89 cm) Weight 17.5 lbs (7.94 kg) REPLACEMENT PARTS Male-To-Male Accessory Cable-------------------------------------38-99-001564 •...
