ONWOTE 720P HD Quick User Manual

355 pan 120 tilt wireless ip security camera with night vision, 1.0 mp two way audio indoor home surveillance wifi camera with motion alert
Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 720P HD and is the answer not in the manual?

Questions and answers

Related Manuals for ONWOTE 720P HD

Summary of Contents for ONWOTE 720P HD

  • Page 2: Table Of Contents

    Content How to get support Before installation Connect device View on mobile via App Steps to view on mobile 3 options to add camera to mobile app System setting on mobile app Wifi setting for flexible placement SD card setting for storage View records on mobile app Motion alert setting View on PC via PC client software...

  • Page 3: How To Get Support

    Dear Valued Customer, Thanks for your business! For any question about your order, please email us support@onwote.com or go to www.onwote.com to get customer support; more screen-shots of your connection or settings will help us figure out your problem. We will reply you within 1 business day!

  • Page 4: Connect Device

    Packing List: * 1x HD IP Network Camera with an Antenna *1x Power Adapter for Camera *1x Network Cable * 1x Bracket for Camera * 1x 2 Packs of Screws for Installing Cameras * 1x Quick User Guide Please check whether there is a sticker like below on the body of the camera.

  • Page 5: View On Mobile Via App

    2. If there is no sticker, please power on the camera directly and using the included 1 meter network cable to connect your camera to the WiFi Router. 1. Download App Please make sure your smart phone has been connected to your WiFi router first.
  • Page 6 2. Register an account Install the Eye4 app; register an account and login your account.
  • Page 7 3. Add Camera to your app account. Click “Add Device” or “+” to add device. 4. Pease choose “IP Camera”.

  • Page 8: Options To Add Camera To Mobile App

    5. Three options to add camera to mobile app. Option 1: Wireless Installation Pair the camera with your Wi-Fi network wireless (No Ethernet cable required, only works with 2.4g Wi-Fi router configurations.) ① Check whether there is a “One key WiFi configuration” sticker on the body of the camera.
  • Page 9 ② Power on the camera, then wait until the camera speaks “Wireless configuration is waiting”. ③ Place your phone near to the camera pickup as closer as possible, click send button, type WiFi password, wait your camera speaks “config success”.
  • Page 10 ④ When the app find one camera, click 【Add it】 and input the default password (888888)
  • Page 11 After you added the camera successfully you will see a warming icon on the upper right corner of the video image. Please click it to change your password. The camera will restart automatically after the password was changed. Option 2: Search in LAN Search and add a camera in the local area network.
  • Page 13 Option 3: Manually add Please make sure using the included Ethernet cable to connect your camera to your local WiFi router first, then tap 【Add Cameras】---【IP Camera】--- 【Search in LAN】. ① You can choose to type UID and password to add a camera or scan QR Code to add a camera manually.
  • Page 14 Option 2: Scan QR Code to add a camera manually. QR Code is on the bottom of camera 5. View live video. When you add one camera successfully, the app will show online camera information as below, click on【Video】to live view.
  • Page 15 Note: if you failed to add your camera to mobile app, please reset camera; Use a pin to hold the rest button for 5-10 seconds to complete reset; then add your camera again.

  • Page 16: System Setting On Mobile App

    Click to do other setting. a. Wifi setting for flexible placement Note：If you choose 【Option 1: Wireless installation】 and add camera successful, you are able to place camera flexibly; if you choose【Option 2： Search in LAN】 or 【Option 3： Manually add】 , you need to do WiFi setting first to plug out the Ethernet cable from WiFi router.

  • Page 17: Sd Card Setting For Storage

    b. SD card setting for storage Insert a SD Card (support up to 64GB) to the SD card slot at the back panel of camera. Then your camera will record video to your SD card. Be aware, 【Format SD card】will delete all records.

  • Page 18: View Records On Mobile App

    c. View records on mobile app --> click on 【SD card playback】 click on Select the specific date and time to view records.

  • Page 19: Motion Alert Setting

    d. Motion alert setting To set up motion alert, click on 【Settings】 , turn on the 【Motion Detection Alarm】, set motion detection sensitivity.
  • Page 20 Then click “Add time period” , choose a time period & date you need to record and click “Save” to save the changes. Go to your mobile phone 【Settings】 and go to 【Notification】, click on Eye4...
  • Page 21 Turn on 【Allow Notification】, make very sure to turn on 【Show on Lock Screen】 ； Make very sure to select the right alert style (banners or alerts), if you choose none, you will not receive notification. When motion is detected, the app will send you a notification like below.

  • Page 22: View On Pc Via Pc Client Software

    1. Download PC Client Software Please go to http://www.onwote.com/download_category.php?id=11 or visit http://www.onwote.com (Support—Download—Software—Pan Tilt IP Camera) to download the PC Client Software. 2. Login the account. Please use the same account information for mobile app to login.

  • Page 23: Pc Client Software Function Illustration

    3. Click on【Start All】, wait for seconds to view live video.

  • Page 24: Alarm Setting & Motion Detected Recording Setting

    a. Alarm Setting & Motion Detected Recording Setting Set up alarm alert and do alarm video management. ① Click on to enter into settings; Click on 【Alarming】and 【Enable Alarm】, then click 【Add】to set alarm mode. ② For alarm time schedule, you are able to select days from Monday to Sunday, and specify start and end time for a day;...
  • Page 25 ③ Make a sound when motion detected. ④ Start to record video when motion detected.

  • Page 26: Continuous/ Scheduled Recording Setting

    ⑤ Take a snapshot on alarm. b. Continuous/ Scheduled Recording Setting...
  • Page 27 ① Enable continuous recording ② Or set scheduled recording. Select 【scheduled recording】 , then click on 【Add】.

  • Page 28: Set Recording Path On Pc

    ③ Set specific days and time for recording according to your needs. c. Set Recording Path on PC ① Click on 【Video】to pop up a window as below.
  • Page 29 ② Click on 【Options】to pop up a window like below. ③ Click on【Add】to set path to save recordings.

  • Page 30: Search Video Records Or Alarm Records

    d. Search Video Records or Alarm Records ① Click on 【Video】to view common video records; Click on 【Alarm】 to view motion detected video records. ② Click 【Search】to show records list.

  • Page 31: Modify Password

    ③ Click on specific records to play; it will show records type under 【Action】, like sound, picture or video records. e. Modify Password ① Click on 【Setup】, then click on 【Modify Password】...

  • Page 32: Faq: Camera Is Offline, How To Do

    1. Please make sure your Wi-Fi router is 2.4G (the IP camera does not work with 5G Wi-Fi router) and the Wi-Fi password doesn’t include any special characters like: “-, +, / ,*,etc.”.
  • Page 33 2. Please delete the camera from your app account first. , then 【Settings】---【Delete】 Step1: Open your app account, click Step2: Log out your app first then login in again. 3. Please reset your camera Please power on the camera first, then the camera will pan and tilt for several seconds before it is ready for wireless configuration.
  • Page 34 There are three options to add a camera, you can go through them all and select one to have a try! Option1: Attention: Make sure you type the right password for your wifi network.  . When you have done reset, wait the camera speaks “One key WiFi configuration is waiting”.
  • Page 35  . When the app find one camera, type 【Add it】, then enter the default password 【888888】.
  • Page 36 Option2: Search camera in the LAN Search and add a camera in the local area network. Please make sure using the included Ethernet cable to connect your camera to your local WiFi router first, then tap【Add Cameras】 Option3: Manually add a camera ...
  • Page 37  You can choose to type UID and password to add a camera or scan QR Code to add a camera manually. Option 1: Type UID and password to add a camera manually. UID is on the bottom of the camera, the default password is 888888.
  • Page 38 Option 2: Scan QR Code to add a camera manually. QR Code is on the bottom of camera...
  • Page 39 5. Slide down to refresh your device information.
  • Page 40 6. View live video. When you add one camera successfully, the app will show online camera information as below; click on it, then click on【Video】to live view...
