Wireless LAN
JRL-710AP3R
Manual
G l o b a l C o m m u n i c a t i o n s
http://www.jrc.co.jp

Advertisement

   Related Manuals for JRC JRL-710AP3R

No related manuals

   Summary of Contents for JRC JRL-710AP3R

  • Page 1: Wireless Lan

    Wireless LAN JRL-710AP3R Manual G l o b a l C o m m u n i c a t i o n s http://www.jrc.co.jp...

  • Page 2

    Please read a user's manual about the command for setting change, display, and examination of this equipment. 2/12...

  • Page 3

    <FCC / IC> Declaration of Conformity Product Name: Wireless Lan Model Number: JRL-710AP3R This device complies with Part 15 of FCC Rules and RSS-Gen of IC Rules. Operation subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.

  • Page 4

    < FCC > NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 5

    Please describe the following sentences to the label or the user manual of the product in each language in the sales country: Hereby, Japan Radio CO., Ltd. declares that this JRL-710AP3R is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

  • Page 6: Back Side

    1.The name of each part ● Front side ① P W R ② T X /R X ③ W -L I N K ④ E -L I N K Name Remarks If a power supply is supplied to this equipment, the light will be ①...

  • Page 7

    Name Remarks It is a connector which connects an antenna.(Main) ⑤ ANT1 It is a connector which connects an antenna.(Sub) ⑥ ANT2 ⑦ CONSOLE It is a connector which connects maintenance PC. ⑧ 10/100BASE-T It is a connector which connects Ethernet. A power supply is connected and a power supply is supplied to equipment.

  • Page 8

    Login (2) It logs in to this equipment using a WEB browser. If "http://192.168.1.1" is inputted into the address of a WEB browser, it will connect with this equipment and will display the following login windows. A user name is inputted. ,...

  • Page 9

    【Specification】 1. General 1) Input Power : DC IN; DC 5V+/-5% IEEE802.3af; DC48V (36 to 57V) 2) Frequency Range : 2.4GHz ISM band (2412 to 24 2MHz) 5GHz band(W52)(5150 to 5250MHz) 3) Radio Communication Standard : IEEE802.11a/b/g 4) Operating Temperature : -30 to +65 degree C 5) Power Consumption : Less than 5W...

  • Page 10

    7) Band Width : Less than 26MHz(2.4GHz band) Less than 19MHz(5GHz band(W52)) 8) Wire connection interface : IEEE802.3 (CSMA/CD), 10/100Base-T 9) Antenna Impedance : 50ohms 10) Number of Terminal Capacity a. Wireless Terminal : 127 terminals b. Wired Terminal : 1024 terminals 3.

  • Page 11

    5. Security 1) 32 Characters ESSID (Extended Service Set ID) 2) Any ID Cancellation 3) SSID Stealth (Mask in Beacon) 4) MAC Address Filtering 5) Access Filter 6) WEP (Wired Equivalent Privacy) RC4 Algorithm (40/104/128bits) 7) WPA (Wi-Fi Protected Access)-PSK i) TKIP ii) AES 8) Packet Filter...

  • Page 12

    2.4 GHz/5.2GHz band wireless LAN module JRL-710AP3R Manual Do not copy February 1, 2013 Japan Radio Co., Ltd. Mobile communication group 1-1 SHIMORENJAKU 5 CHOME, MITAKA-SHI, TOKYO, JAPAN Tel +81-422-45-9236,Fax +81-422-45-9880 12/12...
