  • Page 1 owner’s manual...
  • Page 2 Mesa Ethernet Dock The Mesa Ethernet Dock is an optional accessory that provides an ethernet port for networking, power input jack, USB client port, and a mounting station for the Mesa Rugged Notepad. Ethernet Features and Specifications: 10/100 Mbps twisted pair ethernet „...
  • Page 3 Using the Ethernet Dock Secure the ethernet dock to a wall or select another mounting option (see the next section for details). Connect a 12V power supply to provide power and charge the Mesa batteries. Options: Mesa Ethernet Dock User’s Manual...

  • Page 4: Mounting Options

    Computers/support/Knowledge-Base). Mounting Options Accessories are available for using the ethernet dock as a desktop base, mounting it onto a vehicle, and mounting it onto a pole. You can also attach it directly to a wall. Mesa Ethernet Dock User’s Manual...

  • Page 5: Wall Mount

    Desktop Base The desktop base (optional accessory) allows the ethernet dock to be used on a desktop or other flat, stationary surface. A metal base and four screws are included. Mesa Ethernet Dock User’s Manual...
  • Page 6 Align the holes, place screws into the holes, screw them in all the way, and tighten them. The desktop base is now ready to use. Mesa Ethernet Dock User’s Manual...
  • Page 7 Hold the Mesa so the connector protector is at the bottom. Align the Mesa with the lower mounting points on the ethernet dock. Press the Mesa back to secure it to ethernet Dock. The top latch snaps into place. Mesa Ethernet Dock User’s Manual...
  • Page 8 Do not drop items on the dock that can damage the pins. Keep debris off of the docking pins and the connectors to maintain the best performance. Mesa Ethernet Dock User’s Manual...

  • Page 9: Battery Warnings

    Use of an unqualified battery may present a risk of fire, explosion, leakage or other hazard. Promptly dispose of used batteries in accordance with local regulations Battery usage by children should be supervised. Mesa Ethernet Dock User’s Manual...
  • Page 10 Do not pull on a cord or cable. When unplugging the wall charger from the electrical outlet, pull on the plug, not the cord. Use only wall chargers intended for the Mesa. Using any other external power source can damage your product and void your warranty. Mesa Ethernet Dock User’s Manual...

  • Page 11: Regulatory Information

    In general, all cables must be high quality, shielded, correctly terminated, and normally restricted to two meters in length. Wall chargers approved for this product employ special provisions to avoid radio interference and should not be altered or substituted. Mesa Ethernet Dock User’s Manual...
  • Page 12 EN 55022 Electromagnetic Interference EN 55024 Electromagnetic Immunity P/N 24096-00 Copyright 12-2013 Juniper Systems, Inc. Mesa Rugged Notepad is a trademark of Juniper Systems, Inc. Information is subject to change without notice. Mesa Ethernet Dock User’s Manual...
