elero VariEco S3/30-K Operating And Installation Instructions

VariEco S-K
Drive for roller shutters
and textile sun protection

Table Of Contents

1 Operating and installation instructions
2 General for instructions
2.1 Standards and Directives
2.2 Intended use
2.3 Foreseeable misuse
2.4 Warranty and liability
2.5 Customer service of the manufacturer
3 Safety
3.1 General safety instructions
3.2 Layout of the safety guidelines
4 Product description
5 Assembly
5.1 Mechanical fastening
5.2 Electrical connection
5.3 Connection example VariEco 230 V / 50 Hz
5.4 Commissioning
5.5 Setting the end positions
5.6 Checking the end positions
6 Troubleshooting
7 Maintenance
8 Repair
9 Manufacturer's address
10 Disassembly and disposal
11 Notes on the EU declaration of conformity
12 Technical data and dimensions
VariEco S-K
1
Drive for roller shutters
and textile sun protection
1
1 Operating and installation instructions
1
Please keep these operating instructions for later use, to be
1
available throughout the life of the product!
The German manual is the original version.
2
All other documents represent the language translations of
2
the original text.
All rights in the case of a patent, utility model or ornamental
2
design registration are reserved.
2
2 General for instructions
2
The content structure is based on the life cycles of the elec-
tric motor drive (hereinafter referred to as "Product").
2
The manufacturer reserves the right to make changes to
the Specifications stated in these Operating Instructions
3
at any time. These may, in individual cases, be different
from the respective product version, however the functional
3
information will not undergo significant changes or become
invalid. The current version of the Specifications may be
3
requested from the manufacturer at any time. No claims
may be asserted against the manufacturer as a result of the
4
preceding sentence. Deviations from text or picture state-
4 ments are possible and depend on the technical develop-
ment, features, and accessories of the products. Deviating
5
information on special versions will be explained by the
manufacturer in the sales documentation. Other information
5
shall remain unaffected by these provisions.
2.1 Standards and Directives
5
During the design process, the basic health and safety
5
requirements of the applicable laws, Standards and Direc-
tives were complied with. The safety is confirmed by the
5
declaration of conformity (see "Declaration of Conformity").
All safety information in these Operating Instructions refer
6
to the laws and regulations currently applicable in Germany.
All instructions in the Operating Instructions shall be ob-
6
served without limitation and at any time. Beside the safety
instructions contained in these Operating Instructions, the
6
provisions for accident prevention, environmental protection
and occupational safety, which are applicable for the op-
6
erating site, must be observed. Provisions and Standards
for the safety rating can be found in the EC Declaration of
7
Conformity
2.2 Intended use
The product is intended for electrically powering roller shut-
ters and textile sun protection.
The determining factor for the drive is the elero
drive computation program (http://elero.de/
antriebsberechnungsprogramm).
Further fields of application have to be arranged with the
manufacturer, elero GmbH Antriebstechnik (see Address).
The operator will be solely responsible for damages result-
ing from improper use of the product. The manufacturer
cannot be held liable for personal or material damages
caused by misuse or procedural errors, and by improper
operation and commissioning.
The product may be operated only by authorized or trained
personnel under observance of all safety.
138195501_EN_0116
