Summary of Contents for John Lewis JLBIFF1809
- Page 1 Fridge Freezer JLBIFF1809 User Manual...
-
Page 2: Table Of Contents
Contents Freezing fresh food Safety information Storage of frozen food Children and vulnerable people safety Thawing General Safety Cold accumulators Safety instructions Ice-cube production Installation Hints and tips Electrical connection Normal operating sounds Hints for energy saving Internal light Hints for fresh food refrigeration Care and cleaning Hints for refrigeration Disposal... -
Page 3: Safety Information
Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. - Page 4 Do not use mechanical devices or other means to accelerate the • defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. • Do not use electrical appliances inside the food storage • compartments of the appliance, unless they are of the type recommended by the manufacturer.
-
Page 5: Safety Instructions
Safety instructions • Make sure that the parameters on the rating Installation plate are compatible with the electrical ratings of the mains power supply. Warning! Only a qualified • Always use a correctly installed shockproof person must install this socket. appliance. -
Page 6: Internal Light
• Do not put soft drinks in the freezer • The insulation foam contains flammable gas. compartment. This will create pressure on the Contact your municipal authority for drink container. information on how to discard the appliance • Do not store flammable gas and liquid in the correctly. -
Page 7: Operation
Operation Control panel On/Off Freezer ˚C Mode Fridge 1. ON/OFF switch 5. MODE and Alarm reset switch 2. Freezer temperature regulator 6. Fridge temperature regulator 3. Fridge-Freezer temperature indicator button 4. Display Display A. Fridge compartment indicator B. Freezer compartment indicator C. -
Page 8: Switching Off The Fridge Compartment
Switching off the fridge The temperature of the freezer compartment may be regulated by rotating the Freezer compartment temperature regulator, and may vary between more or less -15°C and -24°C. To switch off the refrigerator compartment, rotate For a correct storage of the food the following the Fridge temperature setting regulator counter- clockwise till position "O". -
Page 9: Fan Function
• freezer compartment flashing (Freezer The fan inside the refrigerator compartment indicator/Door open alarm compartment is automatically indicator) activated also when the room • sounding of buzzer temperature is high (over 32°C) or • red illumination of display for a quick temperature recovering When normal conditions are restored: after door opening, even though •... -
Page 10: Daily Use
Daily use Warning! Refer to Safety chapters. Cleaning the interior Before using the appliance for the first time, the interior and all internal accessories should be washed with lukewarm water and some neutral soap to remove the typical smell of a brand-new product, then dried thoroughly. -
Page 11: Movable Shelves
corresponding icon appears. 2. To deactivate the function, repeat the procedure until the until the icon disappears. Movable shelves The Fan device stops when the The walls of the refrigerator are equipped with a door is open and restarts series of runners so that the shelves can be immediately after the door positioned as desired. -
Page 12: Storage Of Frozen Food
Ice-cube production about 24 Introducing the maximum quantity of This appliance is equipped with one or more hours before food (see rating plate) trays for the production of ice-cubes. Fill these not needed Introducing frozen food trays with water, then put them in the freezer compartment. -
Page 13: Hints And Tips
Hints and tips Normal operating sounds Hints for refrigeration The following sounds are normal during Useful hints: operation: • Meat (all types): wrap in a suitable packaging and place it on the glass shelf above the • A faint gurgling and bubbling sound from coils vegetable drawer. -
Page 14: Hints For Storage Of Frozen Food
• water ices, if consumed immediately after removal from the freezer compartment, can possibly cause the skin to be freeze burnt; • it is advisable to show the freezing in date on each individual pack to enable you to keep tab of the storage time. -
Page 15: Care And Cleaning
Care and cleaning Warning! Refer to Safety chapters. Periodic cleaning The equipment has to be cleaned regularly: • clean the inside and accessories with lukewarm water and some neutral soap. • regularly check the door seals and wipe clean to ensure they are clean and free from debris. -
Page 16: Troubleshooting
Troubleshooting Warning! Refer to Safety chapters. What to do if... Problem Possible cause Solution The appliance does not operate. The appliance is switched off. Switch on the appliance. The mains plug is not connected Connect the mains plug to the mains to the mains socket correctly. - Page 17 Problem Possible cause Solution The compressor operates continu- Temperature is set incorrectly. Refer to "Operation". ally. Many food products were put in Wait some hours and then check the at the same time. temperature again. The room temperature is too Refer to climate class chart on the rat- high.
-
Page 18: Closing The Door
Problem Possible cause Solution The temperature in the appliance is The temperature regulator is not Set a higher/lower temperature. too low/too high. set correctly. The door is not closed correctly. Refer to "Closing the door". The food products' temperature Let the food products temperature is too high. -
Page 19: Installation
Installation Electrical Connection Warning! Refer to Safety chapters. Caution! Any electrical work required to install this Positioning appliance should be carried out by a qualified electrician Install the appliance in a dry, well ventilated or competent person. indoors where the ambient temperature corresponds to the climate class indicated on Warning! This appliance must the rating plate of the appliance. -
Page 20: Ventilation Requirements
1. Connect the wire coloured green and yellow to the terminal marked either with the letter “E“ or by the earth symbol or coloured green and yellow. 2. Connect the wire coloured blue to the terminal either marked with the letter “N“ or coloured black. -
Page 21: Technical Data
Technical data Technical data Dimensions of the recess Height 1850 Width Depth Rising time Hours Voltage Volts 230-240 Frequency The technical information is situated in the rating plate, on the external or internal side of the appliance and in the energy label. Fridge Freezer User Manual... -
Page 22: Repairs - After Sales Service
John Lewis, Liverpool 0151 709 7070 them here: John Lewis, Milton Keynes 01908 679 171 • Mod........John Lewis, Newcastle upon Tyne 0191 232 5000 • P.N.C........John Lewis, Norwich 01603 660 021 • S.N......... John Lewis, Nottingham 0115 941 8282... - Page 23 John Lewis, Stratford 020 8532 3500 John Lewis, Croydon 020 8662 4730 John Lewis, The Trafford Centre 0161 491 4040 John Lewis, Horsham 01403 214 740 John Lewis, Watford 01923 244 266 John Lewis, Ipswich 01473 275 850 John Lewis, Welwyn 01707 323 456...
-
Page 24: Environmental Concerns
ENVIRONMENTAL CONCERNS marked with the symbol with the household Recycle the materials with the symbol . Put waste. Return the product to your local the packaging in applicable containers to recycle recycling facility or contact your municipal office. it. Help protect the environment and human health and to recycle waste of electrical and electronic appliances. - Page 25 Fridge Freezer User Manual...
- Page 26 Fridge Freezer User Manual...
- Page 27 Fridge Freezer User Manual...
- Page 28 222373150-A-462016 ( Subject to change without notice. )
