- Page 1 DTR 1002S PRO DIGITAL TERRESTRIAL RECEIVER User´s Manual...
-
Page 2: Table Of Contents
NPG DTR 1002S PRO V2.3 ………………………………… ………………………………………¡ERROR! CONTENTS……………………………… … …. MARCADOR NO DEFINIDO. …………..2 1. IMPORTANT SAFETY INSTRUCTIONS…………………………………………………………… ..………….4 2. CONTENTS AND EQUIPMENT……………………………………………………………………… … …………… ……………… 2.1 REMOTE CONTROL…………………………………………………….… …. …. 2.2 CONNECTIONS AND PREPARATION ....................7 3. BASIC FUNCTIONS……………………………………………………………………………………………..…..9 ……………………………... -
Page 3: Important Safety Instructions
NPG DTR 1002S PRO V2.3 1. IMPORTANT SAFETY INSTRUCTIONS WARNING TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE WITH AN EXTENSION CORD, ● RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PRESENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS APPLIANCE TO RAIN OR ●... - Page 4 NPG DTR 1002S PRO V2.3 operated. 2. Retain Instructions-The safety and operating instructions should be retained for future reference 3. Heed Warnings-All warnings on the appliance and in the operating instructions should be adhered to . 4. Follow Instructions-All operating and use instructions should be followed .
-
Page 5: Contents And Equipment
DTR 1002S PRO Operation manual X1 Remote control X1 2 batteries 1.5V "AAA" 1. DVB Product DTR 1002S PRO 2. Remote control DVB RECEIVER ( include 2 batteries Remote control x 1) 3. 2 batteries,1.5V ,"AAA" type 4. Operation manual Using the remote control Unless stated otherwise , the remote control can operate all features of the DVB Product. - Page 6 NPG DTR 1002S PRO V2.3 Front Panel Real Panel Decoder 1. ANT IN Income marks them of antenna. 2. Exited LOOP OUT passing marks them of antenna towards the TV. 3. SPDIF Digital audio optical output. 4. Taken VCR SCART audio/video SCART for the videoregistrazione.
-
Page 7: Remote Control
NPG DTR 1002S PRO V2.3 2.1 REMOTE CONTROL 1. POWER Switches the DVB -T between operation and standby mode. 2. MUTE Enables/disables the audio. 3. 0-9 (Numeric Keys) Selects the TV or Radio service channels and individual menu option 4. FAV To shows favorite channels list. -
Page 8: Connections And Preparation
NPG DTR 1002S PRO V2.3 2.2 CONECTIONS - 7 -... - Page 9 NPG DTR 1002S PRO V2.3 Connecting the power cable Insert the plug of the power cable into the power socket. Caution: The unit is completely disconnected from the mains supply if the power plug is pulled out of the socket or with power button on OFF.
-
Page 10: Basic Functions
NPG DTR 1002S PRO V2.3 3. BASIC FUNCTIONS TV Program List Music Program List By Name Program List By Service ID Sort Channel No. Automatic Search Program Search Manual Search Channel Lock Parental Control Parental Setting Change PIN NTSC TV Standard... -
Page 11: Enter Into System And Power On-Off
NPG DTR 1002S PRO V2.3 3.1 Enter into system and power on-off It will continue to play the latest program before previous power off if the database having any TV or RADIO program. 1. Power on When it is in “standby” mode, press “power” to power on. -
Page 12: Display Information Of Programs
NPG DTR 1002S PRO V2.3 3.4 Display information of programs Press key “INFO” twice to show the information of current programs when it is in normal palying state. 3.5 Program return Press “RECALL” under state of full-screen to return to the previous program palyed. -
Page 13: Electronic Programs Guide (Epg)
NPG DTR 1002S PRO V2.3 3.7 Electronic programs guide (EPG) 1. You can press key “EPG” on the remote control to enter into the EPG page to know more about the programs to be played. As shown in the figure below: (3).Tab 3 shows particular date list;... -
Page 14: Teletext
NPG DTR 1002S PRO V2.3 3.8 Teletext 1. If you want to watch teletext, please press “Teletext” on the remote control to enter into teletext page. 2. Input three digits to go to corresponding page you want; 4. Press “CH+” to go to the previous page, while press “CH-” to go to the next page;... -
Page 15: Digital Tv
NPG DTR 1002S PRO V2.3 4. Digital TV In the main menu of the system, under Digital TV, there are such as options as Channel manager , installation , configuration , software upgrade , factory default , version press MENU key firstly to enter the main menu In Main Menu, press “CH+/CH-“... -
Page 16: Manual Search
NPG DTR 1002S PRO V2.3 4.1.1 Manual Search If you understand much about digital TV and know the frequency of the program or if you want to scan the program at any frequency required, you can select manual scaning, whitch can save your much time. -
Page 17: Channel Sorting
NPG DTR 1002S PRO V2.3 enter into, and it will not enter into channel organizer page. 3. Channel Organizer menu includes: Favorite Channel, Delete Channel, Mov Channel, Lock Channel. Press “UP/DOWN” key to choose the line where Favorite Channel is, then press the 4-color key on the remote controller: press the red key to set and cancel Favorite Channel, the green key to set or cancel “Delete Channel”, the yellow... -
Page 18: Edit Channel
NPG DTR 1002S PRO V2.3 1. You can enter the page As shown in the figure below via “MENU->Digita TV-> Channel Manager -> Channel Grouping”: 2. It will pop up and dialogue box prompting that “Channel not available” when there are no programs in database to enter into, and it will not enter into channel grouping page. -
Page 19: Delete All
NPG DTR 1002S PRO V2.3 the right, then press “CH+/CH-“ key to choose area name, press OK key to confirm; (2).Carrier: Press “VOL+/VOL-“ key to choose; (3).Channel Name: Press “VOL+/VOL-“ key to enter Rename Channel page as shown (4).Audio PID, Video PID, PCR PID, Press 0-9 number key to revise values;... -
Page 20: Configuration
NPG DTR 1002S PRO V2.3 4.3 Configuration Configuration provides individualized system setup function, you can configure the system according to your own hobby and demand. You can enter Configuration menu via the menu(MENU->Digita TV->Configuration), as shown in below 4.3.1 OSD Via OSD option setup, you can set the user interface display mode according to your own demand. -
Page 21: Display Mode
NPG DTR 1002S PRO V2.3 4.3.2 TV TV setup provides convenient TV input mode, you can via menu ( MENU->Digita TV->Configuration -> TV) enter TV set, as shown in below All options are listed on the left of the menu, when the cursor moves to the option on the left of the TV menu, the values corresponding to this option can be displayed on the right of the menu. -
Page 22: Brightness
NPG DTR 1002S PRO V2.3 4.3.2.4 Brightness If the brightness is not proper during watching, you can adjust the current brightness to be a proper one. 1. Move the cursor to Brightness option, press “VOL+” key to move the cursor into the Properties list on the right, as shown in below 2. -
Page 23: Saturation
NPG DTR 1002S PRO V2.3 4.3.2.7 Saturation Adjust system saturation. 1. Move the cursor to Saturation option, Press “VOL+” key to move the cursor into the Properties list on the right, as shown in below 2. Press “CH+/CH-“ key to move upward and downward the cursor to choose and press “OK” key to confirm, in this moment, move the cursor onto the options on the left, and then values will become the ones you want. -
Page 24: Time
NPG DTR 1002S PRO V2.3 4.3.4 Time Via menu ( MENU->Digita TV->Configuration -> Time), entertimeset, as shown in below: In Time menu, there are two time modes, one is Auto setting, the other is Manual setting, Press “VOL+/VOL-“ key to choose time mode. -
Page 25: Software Upgrade
NPG DTR 1002S PRO V2.3 4.4 Software Upgrade 4.5 Version Via menu ( MENU->Digita TV-> Version), enter the page as shown in below: You can be provided with system software information, including H/W Version, S/W Version, Tuner Type, Date, Time, Press “EXIT” key to return previous menu. -
Page 26: Troubleshooting
NPG DTR 1002S PRO V2.3 6. Troubleshooting There may be various reasons for the abnormal operation of the receiver. Check the receiver according to the procedures shown below. If the receiver does not work properly after checking it ,please contact the dealer. Don't open the receiver cover .It may cause a dangerous situation . -
Page 27: Glosary Of Terms
NPG DTR 1002S PRO V2.3 7. GLOSSARY OF TERMS Electronic Program Guide. A software that viewers to navigate easily among the large number of channels provided by digital technology, in order to select the service the desire. Free To Air Greenwich Mean Time. -
Page 28: Caracteristic
NPG DTR 1002S PRO V2.3 8. CARACTERISTIC VHF:174MHz to 230MHz Input Frequency UHF:470 MHz to 862MHz Standard DVB-T (ETSI 300 744) Channel Bandwidth Terrestrial 6MHz, 7MHz, 8MHz OFDM Spectrum Tuner/Demodulator 2k/8k-carrier hierarchical Modulation Mode Guard QPSK, 16QAM, 64QAM Interval Modes...
