Summary of Contents for NPG DHT 602 AP
- Page 1 DHT 602 AP uSER mANUAL mANUAL DE uSUARIO manual d'usuari Manual de instruções eNGLISH eSPAÑOL cATALà pORTUGuês...
-
Page 2: Table Of Contents
CONTENTS GENERAL INFORMATION Main Features For your Safety Unpacking General Operation INSTALLATION WELCOME PAGE MAIN MENU 1. Edit Channel 2. Installation 3. System Setup 4. Tools 5.Game 6. REC 7. Hot key TROUBLE SHOOTING English... -
Page 3: General Information
GENERAL INFORMATION This Digital Terrestrial Receiver (DTR) will take you to the new and exciting world of Digital Television. A world of crystal clear widescreen pictures, digital sound, more information and new services. All this and more on "Free to Air" Digital Television. To make full use of your new DTR please take the time to familiarize yourself with the extensive features of the unit detailed in this User's Guide. -
Page 4: For Your Safety
GENERAL INFORMATION For Your Safety • • To avoid electric-shock hazards, do not open Keep the receiver away from flower vases, tubs, the cabinet, refer servicing to qualified person- sinks, etc., in order to avoid damaging the equip- nel only. ment.. -
Page 5: Unpacking
GENERAL INFORMATION Unpacking (optional) • • • Remote Control Batteries User’s manual • AV cable General Operation • Throughout this manual you will notice that the everyday operation of the receiver is based on a series of user friendly on screen display and menus. These menus will help you get the most from your receiver, guiding you through installation, channel organizing, viewing and many other functions. -
Page 6: Rcu
GENERAL INFORMATION Function Turns power ON/OFF When watching a channel, mute the sound Enter number of the required menu item or select a channel number to watch TV/RADIO Switches between TV and Radio mode Switches back to previous channel Displays the favorite group list SHIFT Timeshift function key FIND... -
Page 7: Installation
INSTALLATION Rear Panel CONNECT TO DIGITAL AMPLIFIER POWER CABLE CONNECT TO TV USING A SCART CABLE CONNECT TO TV SET HDMI-OUT INPUT LOOP: CONNECT TO ANOTHER RECEIVER Connecting to TV using SCART support Antenna The picture is only for reference, please make the object as the standard. English... -
Page 8: Connecting To Digital Amplifier
INSTALLATION Connecting to Digital Amplifier Antenna DIGITAL AUDIO CONVERTOR OR AMPLIFIER SPEAKER The picture is only for reference, please make the object as the standard. English... -
Page 9: Welcome Page
WELCOME PAGE • When power on first time, it will show welcome page like below. • Press PR+,PR- keys to move highlight to select Region, Display Mode, Aspect Mode and language . Press keys to move the cursor to choose your choice. •Move highlight to [OK] option and press OK key to enter “... - Page 10 MAIN MENU 1. 1 TV Channel List 1. Press PR+, PR- keys to select the program that you want to play, and then press OK key to view it in the small window. If move the ye- llow cursor to select up or down, you will see a gray line which indi- cates the playing program in the small window.
- Page 11 MAIN MENU 6. Press blue colour key to enter into the Edit channel window. i . Sort (red colour key) Press red colour key to pop up the Sort drop-down list. Name(A-Z): The ascending order, omitting the $ character, the num- ber is ahead, then the capital letter, at last the lowercase.
-
Page 12: Installation
MAIN MENU If the name is empty, system will pop up a dialogue informing "Name" once yellow colour key is pressed. Press OK key to close this dialogue. iii. Delete (blue colour key) In Delete window, press blue colour key to move the Delete button upward. - Page 13 MAIN MENU 2. 1 Auto Scan When you enter Auto Scan menu, the screen will display as below. In FTA Only, press [Left/Right] key to choose Yes or No. Move the highlight on the search option, and press [OK] key to start scanning.
-
Page 14: System Setup
MAIN MENU 3. System Setup When you enter the System Setup menu, you will see the screen like besides. It contains 7 sub-menus such as: Language, TV System, Local Timer Setting, Timer Setting, Parental Lock, OSD Setting and Favorite . Press [Up/Down] key to select menu among all the items. - Page 15 MAIN MENU 3.3 Local Time Setting 1. Region: Select the region. 2. GMT Usage: Select between On and Off. If select "Off", the GMT Offset and Summer Time item will turned gray. 3. GMT Offset: When select "ON" in GMT Usage item, system will get the date and time information from the screen automatically.
-
Page 16: Tools
MAIN MENU 3. New Password: User numeric key (0-9) to input the new password. 4. Confirm Password: Input the new password once again. Confirm password must be the same as the New password. System will inform you "Change password successfully!" while they are the same, or in- form you to input the password of Confirm password once again when they are not the same. - Page 17 MAIN MENU 4. 1 Information When you enter Information menu, you should see the screen like it displays on the right. This screen displays receiver information. You should press [EXIT] key to cancel this menu. 4.2 Load Factory Setting When you choose the option of Load Factory Setting and press [OK] key, there will be a dialogue for you to input the password.
- Page 18 MAIN MENU 4.4 S/W Upgrade by OTA 1. Frequency: Use numeric keys to input the proper value. 2. Bandwidth: Select among 6, 7, 8MHz. 3. Down load PID: Use numeric keys to input the proper value. 4. Start: Press OK key to start upgrading. If no correct searching information, system will inform "Collecting information".
- Page 19 MAIN MENU 4.6 Media Player Media Player menu will be automatically shown when insert U disk to USB port except auto scan, multi picture, upgrade. Or open USB menu according to Menu -> Tools-> USB. Press OK to enter into this window.
-
Page 20: Game
MAIN MENU Image List Press PR+,PR- key to select the iamge you want, and press FAV key to added it to the image list, or you can press number key 1 to add all the images to image list. Press yellow key and select the image button in the window, you can see the iamge you selected and in this list you can play and delete them. -
Page 21: Rec
MAIN MENU 6. REC 6. 1 . Record Manager 1. Press PR+, PR- keys to select up or down, 2. Press green color key to lock the file you selected, the lock symbol will be marked behind the file. Before you lock the file you must input the correct password, the default password is 0000. -
Page 22: Hot Key
MAIN MENU 7. Hot Key 7. 1 Number Use the numeric keys (0-9) to input the number of the desired channel. If the inputted number is beyond the valid channel number, system will "Invalid number” and press OK key to close this message. 7.2 TV/RADIO In normal mode, press TV/RADIO key to switch between TV mode and Radio mode. - Page 23 MAIN MENU 7.9 Audio 1. Press key to enter into the Audio window. 2. Press keys to select between Left, Right, Mono and Stereo. 3. Changing the audio mode is only connected with the current channel, not all the channels. 4.
- Page 24 MAIN MENU MAIN MENU :Press OK key at this button to move the cursor to the current time line. :Press OK key to push the time forward or backward by half an hour. :Press OK key to push the time forward or backward by 2 hours.
-
Page 25: Trouble Shooting
TROUBLE SHOOTING Problem Possible causes What to do The display on the front Check that the main cable is Main cable is not connected. panel does not light up. plugged into the power socket. No sound or picture, but the front panel The receiver is in standby mode. - Page 26 pERSONAL GRAND TECHNOLOGY, S.A. C/ Tormes, 9 28840 Mejorada del Campo-Madrid Telf. 902 501 406 sat@npgtech.com www.npgtech.com English...
