- Page 1 GuidePort – EMP System Manual Version 1.0 of 27 July 2000 Sennheiser electronic GmbH & Co. KG Am Labor 1 30900 Wedemark Germany...
- Page 2 GuidePort Wireless Audio Transmission GuidePort is a local area broadcast system for use in museums, visitor centers and at exhibitions. GuidePort features a characteristic cell structure, the so-called cells being defined areas of information and entertainment. These areas are supplied by Cell Transmitters which send digitally coded information via an Active Antenna Unit to portable Receivers.
-
Page 3: Table Of Contents
Event 3 Cell Transmitters Event 5 Event 6 One cell transmitter Event can handle up to 4 mono audio channels and transmit them on one RF channel GuidePort System Hierarchy GuidePort: System Manual 27. November 2000 Seite 3... -
Page 4: Cell
Exhibition RF CH 1 RF CH 4 (opt.) Exhibition room 6 room 3 Event Event Receiver Event Event Exhibition room 4 Exhibition room 5 Technical equipment required for an exhibition with GuidePort GuidePort: System Manual 27. November 2000 Seite 4... -
Page 5: Cell
Hardware Components of the System Central Unit PC The Central Unit PC with its Central Unit Software is at the heart of the GuidePort system. It serves to configure the entire GuidePort installation with its cells, transmitters, events and identifiers. Via a network, the Central Unit PC is connected with all Base Station PCs of the GuidePort installation. -
Page 6: Cell
1 & 2 and/or 3 & 4. Connect the left audio channel to socket No. 1 or 3, the right audio channel to No. 2 or 4, respectively. The following table shows how to connect your audio sources to the GuidePort Cell Transmitter: Number and kind of audio Input No. -
Page 7: Cell
2.3.3 User Interface (Display and Controls) Menu layout of the GuidePort Cell Transmitter: TX OK N.B.: If there is no input for about 90 secs the display will show “TX OK” CCU ID xxx 1...95 AAU SETTINGS AAU 01 RF CHxx... -
Page 8: November
AF IN 1&2 or 3&4 (stereo); remaining inputs for mono sources USB IN AAU OUT DC output Data rate 1,024 Mbit/s Output level LVDS standard Headphone Output Output level AF input level 350mV Ω Output impedance GuidePort: System Manual 27. November 2000 Seite 8... - Page 9 LVDS interface. The data stream is then FSK modulated onto an RF carrier in the 2.4 GHz ISM Band and transmitted to the GuidePort receivers. Settings for transmission frequency, RF output power and the antenna to be used (internal or external antenna) are controlled by the Cell Transmitter.
- Page 10 2476.224 2420.064 2448.576 2477.088 2420.928 2449.440 2477.952 2421.792 2450.304 2478.816 2422.656 2451.168 2479.680 2423.520 2452.032 2480.544 2424.384 2452.896 2481.408 2425.248 2453.760 2482.272 2426.112 2454.624 2426.976 2455.488 2427.840 2456.352 2428.704 2457.216 2429.568 2458.080 GuidePort: System Manual 27. November 2000 Seite 10...
- Page 11 Spurious frequencies outside the ISM in compliance with ETS/FCC band Modulation type 2-FSK binary frequency shift keying µ = 2* ∆f/f Modulation index µ 0.5 ... 0.7 Modulated data rate f /channel 1024 kbit/s GuidePort: System Manual 27. November 2000 Seite 11...
-
Page 12: Event
When receiving this number, the receiver will transfer the corresponding audio information to the Mollie System. Mollie then decides on the action to be taken, for example to play the audio information. The GuidePort Receiver uses a prestored assignment table for translating the numbers into the correct action. - Page 13 7, MSB Read/Write Frame Clock Interrupt_2 Reset Interrupt_1 digital ground for digital interface 3.3 volts digital power, from Mollie digital ground from Mollie analog ground from Mollie 5 volts analog power from Mollie GuidePort: System Manual 27. November 2000 Seite 13...
- Page 14 Identifier coil Connectors for RF antennas 'Reset': reset is active when 'low', internal connection on GuidePort receiver PCB: MR of MAX811 (pin 3) 'Interrupt_1 ': Interrupt_1 is active when 'low'. Mollie’s read or write procedures always start with the interrupt request. The first interrupt tells the GP receiver that Mollie has put an address word on the bus.
- Page 15 Specification for the Reset Procedure between GuidePort/EMP and Mollie Simplified hardware diagram: Mollie Reset for DSP56303 Reset line Reset IC from Mollie Max 811 Master Reset Interrupt_1 IRQA of DSP 3.3 VDC for digital circuit Remark: Other lines of the GP/Mollie interface are not of interest for this subject.
- Page 16 Digital 10% tolerance Max. current AF output Ω Headphones Max. AF output level U = 1 kHz, U 350 mV = 32 Ω at Cell Transmitter, R Frequency response 40 ... 14,000 GuidePort: System Manual 27. November 2000 Seite 16...
-
Page 17: Event
2.4.1 Description The Identifier transmits a binary code, which enables the GuidePort receivers to identify the audio event belonging to it. The identifier transmitter is programmable via a palmtop with the necessary GuidePort software. The parameters to be programmed are identifier number, transmission power, and the times for switching the identifier transmission on and off. - Page 18 (a) no data will get lost in case of a mains power failure; (b) you can conveniently program the battery-powered identifiers before they are mounted in their final position and connected to an external DC supply. GuidePort: System Manual 27. November 2000 Seite 18...
-
Page 19: Event
Central Unit Software The Central Unit Software runs on the Central Unit PC. It serves to configure the entire GuidePort installation with its cells, transmitters, events and identifiers. Cell Transmitter Loader Software The Cell Transmitter Loader Software runs on the Base Stations. Via a USB, the software detects the IDs of all Cell Transmitters connected to a Base Station.
