From Bicom Systems Wiki
Contents
1 Introduction
2 Requirements
3 Important Safeguards
4 Overview
5 Installation
Introduction
Installation guide takes you through the process of setting up your officeBOX™ appliance. This
is a simple task that does not require much time and after it is completed you will be able to use
full potential of your officeBOX™ appliance.
Requirements
Requirements for the usage of officeBOX™ are:
10/100Base TCP/IP – based local area network (LAN)
One of the following web browsers:
Firefox
Google Chrome
Safari
Internet explorer 9+
Network parameters which include officeBOX™ IP address, the subnet mask of your network
and a gateway or router address if communicating with other networks can be obtained by:
Obtaining IP address automatically from the DHCP server
Setting up a fixed IP on LAN port
Advertisement
Summary of Contents for Bicom Systems officeBOX M1000
- Page 1 PBXware SERVERware TELCOware SIPmon SIPProt Desktop & Mobile UADs Appliances From Bicom Systems Wiki Contents 1 Introduction 2 Requirements 3 Important Safeguards 4 Overview 5 Installation Introduction Installation guide takes you through the process of setting up your officeBOX™ appliance. This is a simple task that does not require much time and after it is completed you will be able to use full potential of your officeBOX™...
-
Page 2: Important Safeguards
Equipment modifications Do not make any hardware modifications to the equipment. Bicom Systems is not responsible for any damage or injury as a result of the equipment modification. - Page 3 CAUTION: Do not put the appliance near a radiator or any other heat emitting device. Failing to do so can cause your appliance to overheat and malfunction. i. Regulations and information This device complies with the CE and FCC Rules and Regulations which can be obtained from the supplier.
- Page 4 NOTE: As OfficeBOX™ M1000 will come with PCI card(s) already installed for you and back plate of an enclosure will be specifically designed to fit your selection of hardware, your OfficeBOX™ M1000 back side view of might look somewhat different from the one shown in picture.
- Page 5 Depending on PCI card(s) you selected with purchase of OfficeBOX™ M1000, you will have to connect telephony cables accordingly. Although, M1000 should come with preinstalled Bicom Systems software and you should be able to reach the system once it is online on your network, console port is also available in case you prefer direct connection for monitoring or to access the system through the console connection.
- Page 6 Select interface you would like to configure and simply go through configuration wizard, selecting preferred settings. To set up LAN (eth0) interface to use static IP, select it from the list and click Next.
- Page 7 Select option Specify IP address manually, select Next and press enter. Enter IP address you would like to use on LAN interface, along with matching netmask, broadcast, default gateway, GW metric (if you only have one default gateway, leave default...
- Page 8 PBXware IP address followed by port 81 in your browser address bar, for example: https://192.168.20.1:81 For additional information on how to complete PBXware Setup Wizard please check our Setup Wizard user guide. http://wiki.bicomsystems.com/PBXware_4.0_Startup_User_Guide_Setup_Wizard Retrieved from "http://wiki.bicomsystems.com/Appliances_OfficeBOX_M1000_Installation_Guide" Disclaimers - About Bicom Systems Wiki...
