FORESIGHT CD102 Manual

Coaxial Cabling : Video Distributor & Video Amplifier Series
ITEM NO.: CD102, CD104, CD108, CD408, CD816, CD116, CD1664, CD102A, CD408A,
CD816A, CD1632A, CA101, CA101A, CA404, CA101VH
CD102, CD104, CD108, CD408, CD816, CD116, CD1664 are video distributors with one or
multi video input to multi output. CD102A, CD408A, CD816A, CD1632A, CA101, CA101A,
CA404, CA101VH are amplifiers for long- range video transmission up to 1000 meters over
RG59 coaxial cable. They are suitable for far distance, different floor in a building or
different electrical field.
Features:
Video Distributor
CD102 1 Input to 2 Output,
CD108 1 Input to 8 Output,
CD116 1 Input to 16 Output,
Red LED: power on/off.
It can be connected video camera, multiplexer, VCR, DVR...etc.
Power supply included.
CD816 8 Input to 16 Output
Automatic gain control (±6dB range), normalizes output signals to standard video level 1Vp-p.
Blue LED: video signal on/off detection at each channel.
50Hz/60Hz input rejection of 60dB.
Built in out-of-band noise filter.
Power supply included.
Video Distribution Amplifier
CD102A 1 Input to 2 Output,
CD816A 8 Input to 16 Output,
Wide bandwidth, video gain compensation amplification.
HF compensation.
10dB adjustable image gain.
Sharpness and Brightness adjustment.
Transmission range: 1000 meters (RG59 coaxial cable)
Red LED: power on/off.
It can be connected video camera, multiplexer, VCR, DVR...etc.
Power supply included.
Video Amplifier
CA101 1 Input to 1 Output,
CA404 4 Input to 4 Output
Wide bandwidth, video gain compensation amplification.
Video and Audio level adjustment. (CA101A)
HF compensation.
10dB adjustable image gain.
Sharpness and Brightness adjustment.
Transmission range: 1000 meters (RG59 coaxial cable)
Red LED: power on/off.
It can be connected video camera, multiplexer, VCR, DVR...etc.
Power supply included.
FORESIGHT CCTV INC. | 5863 Leslie Street, Unit#713, North York, Ontario,Canada, M2H 1J8 | http://www.foresight-cctv.com | 1-888-GO2-CCTV 416-512-6288
CD104 1 Input to 4 Output
CD408 4 Input to 8 Output
CD1664 16 Input to 64 Output,
CD408A 4 Input to 8 Output
CD1632A 16 Input to 32 Output
CA101A 1 Input to 1 Output with Audio
