- Page 1 Instruction Manual 2.4G Digital Wireless Four Channel Transmitter System RVS-554W Reverse With Confidence ™...
-
Page 2: Table Of Contents
Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Safety 2.4G Digital Wireless Four Channel Transmitter System! With this manual you will be able to properly install and operate the Introduction...... - Page 3 It does not display the entire pan- a metal case, cover the cable with did not have the Rear View Safety orama that is behind you. friction tape. A short circuit or 2.4G Digital Wireless Four Channel disconnected wire may cause a fire.
- Page 4 Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possi- Rear View Safety bility of them being damaged while vehicle is in use. Keep all cables 1797 Atlantic Avenue away from hot/moving parts and electrical noisy components.
-
Page 5: Introduction
6. If system does not pair, please check wiring. Also check that LED indicators confirm units are receiving power connection. Note: A "Pairing Failed" screen may display after performing a Backup Camera 60 second pairing synronization. Disregard this message. Transmitter Transmitter (Sold Seperately) Rear View Safety Reverse With Confidence ™... -
Page 6: To Alternate Between Channels
2. Alternate between single view of all four channels. 1. DC12-24V - Ground Connection 2. Yellow RCA - Audio Connection 3. Trigger #V1 - (Green) 4. Trigger #V2 - (Blue) 5. Trigger #V3 - (Purple) 6. Trigger #V4 - (Grey) Rear View Safety Reverse With Confidence ™... -
Page 7: System Specifications
Waterproof Rating IP69 Pixel Resolution 720 x 576 Video Input 4 Channel (4 Wireless) Transmitter Weight 2.66 KG Transmission Distance 70 ft Reciever Weight 2.54 KG Video Source 1Vp-p, 75 Ω Auto Pair Rear View Safety Reverse With Confidence ™... -
Page 8: Warranty
TO NORMAL WEAR AND TEAR, THIS DAMAGE IS DUE TO ABUSE, IMPROPER MAINTENANCE, REARWARD CLEARANCE AND THAT YOUR VEHICLE CAN MANEUVER SAFELY. REAR VIEW NEGLECT OR ACCIDENT; OR THE DAMAGE IS DUE TO USE OF THE REAR VIEW SAFETY, INC. SAFETY AND/OR ITS AFFILIATES SHALL HAVE NO RESPONSIBILITY OR LIABILITY SYSTEM AFTER PARTIAL FAILURE OR USE WITH IMPROPER ACCESSORIES. - Page 9 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. Rear View Safety...
