wePresent
SharePod
User's Manual
Model : WHE-100
Version: 0.5
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SharePod WHE-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WePresent SharePod WHE-100

Summary of Contents for WePresent SharePod WHE-100

  • Page 1 SharePod User's Manual Model : WHE-100 Version: 0.5...

  • Page 2: Table Of Contents

    Table of Contents ............................3 VERVIEW ..........................4 ACKAGE ONTENTS ..........................4 HYSICAL ETAILS ..........................5 ......................-5 RESENT HARE OD PAIRING ..........................5 AIRING ..........................6 ANUAL PAIRING ......................7 RESENT HARE IRRORING ........................7 HARE IRRORING ..................8 DVANCED OLLABORATION WITH WE RESENT...

  • Page 3: Overview

    HDMI sources to a display or projector, without any software installation or other configuration required. Furthermore, you can utilize the advance features on the wePresent device such as the 4-to-1 projection, Annotation, WebSlides and Conference Control for better meeting room or classroom collaboration.

  • Page 4: Package Contents

    Package Contents wePresent SharePod device  Power Adapter (DC +5V, 1.2A)  Setup Guide  Warranty Card  CE DoC  Physical Details...

  • Page 5: What You Need

    SharePod pairing 5.1 Auto Pairing Plug in the micro USB cable from SharePod to the wePresent device, and pairing will begin automatically. The SharePod LED will show a long flashing red light while pairing is in process. Please wait until you can see the “Pairing successful” message on the wePresent start screen, and then remove the USB cable to complete the pairing.

  • Page 6: Manual Pairing

    USB storage, and then begin configuring the pairing information manually as below. Receiver  • IP Address: the IP address of target wePresent device • Login Code: the login code of target wePresent device WiFi  • Name：the WiFi name of target WiFi Access Point device •...

  • Page 7: Wepresent Sharepod Mirroring

    2) Plug in the HDMI cable to the supported HDMI source, and mirroring will begin automatically if the wePresent device is in standby mode, or you can press the PLAY button to manually begin mirroring. The blue LED indicates that the system is ready for mirroring and it will switch to red LED when mirroring.

  • Page 8: Advanced Collaboration With Wepresent

    (2 sec) 6.2 Advanced Collaboration with wePresent 1) Conference Control: Choose the SharePod screen from wePresent Web Conference Control page or OSD to start the full screen/4-to-1 projection. The meeting host or teacher can moderate the meeting in an efficient way.

  • Page 9: Web Admin

    Web Admin 7.1 Login Admin Page 1) Connect the SharePod to the same network of your laptop, then open a browser window to visit the SharePod web admin page. 2) Enter the password to login the admin page. (default password: admin) 7.2 System Status 1) Click on “System Status”...

  • Page 10: Device Setup

    7.3 Device Setup 1) Click on “Device Setup” option, it will show the device setting items. <Receiver IP Address>: The IP address of target wePresent device.  <Login Code>: The login code of target wePresent device.  <Sender Name>: The name of the connected SharePod ...

  • Page 11: Network Setup

    7.4 Network Setup 1) Click on “Network Setup” option, it will show the network setting items. < IP Setup> You can select “obtain IP address automatically” or “Use the following IP  address” to manually enter the IP address. The default setting is as follows: IP Address: 192.168.100.10.

  • Page 12: Change Passwords

    Note: 1. The WiFi 5G DFS band is not supported. 7.6 Change Passwords 1) Click on “Change Password” option, you can change the password setting for “Admin”. <Enter New Password> (Length: up to 8 characters)  <Confirm New Password>  <Apply>: Confirm and Save modifications.

  • Page 13: Reset To Default

    2. Click <Browse> to specify firmware file you want to upgrade to. 3. Click <Upgrade> to start. 4. A warning message and count down counter will appear on the screen. 5. After a few minutes, a complete message will show on the screen. 6. Restart wePresent SharePod to take effect.
  • Page 14 Warning: Do not power off wePresent SharePod while firmware upgrade in progress, otherwise your SharePod will be damaged and must be returned to the vendor for service and repair.

  • Page 15: Reboot System

    7.9 Reboot System ♦ Click on “Reboot System” option to restart the SharePod. ♦ Click on <Reboot >button: reboot system automatically. 7.10 Logout 1) Click on “logout” on the upper right corner to logout of the administration webpage and return back to the web management home page.
  • Page 16 FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
