Quick Links
Technical Support
(949) 429-3303
Smartenit.com
Quick Start Guide
USB ZigBee HA Network Coordinator
Installation
1) Simply plug the IOT-ZBCID into an available USB port.
Set-up
The IOT-ZBCID will send ZigBee commands via serial communication.
This interface is intended for use with applications that can handle serial communication. Docklight Scripting is one
application that can be used to set up a ZigBee network and control individual ZigBee devices with the IOT-ZBCID. An
understanding of the ZBCID API will be required to modify Docklight scripts.
For a brief tutorial on how to use Docklight with the pre-loaded scripts visit our Wiki
- http://wiki.smartenit.com/index.php?title=Using_Docklight
Downloads
•
Docklight pre-loaded scripts are available - http://smartenit.com/downloads/Sample_Scripts.zip
•
The Docklight Scripting application is available at - http://www.docklight.de/download/Docklight_Scripting.zip
•
The ZBCID API is available at - http://smartenit.com/downloads/ZBPCID_API.pdf
Monitor and Control Anything from Anywhere!! See our products in action at http://video.Smartenit.com
2016 Compacta International, Ltd. - Rev.
IOT-ZBCID
and Smartenit are trademarks of Compacta International, Ltd.
ZigBee is a registered trademark of the ZigBee Alliance
- IOT-ZBCID
Product Brief
Certifications
FCC ID: AFZ-2011D IC ID: 10174A-2011D
9/2016
Model # 2011D
The IOT-ZBCID serves as a ZigBee Pro network coordinator
to set up and manage a home automation network.
The easy-to-install USB interface ensures compatibility with
any PC with an available USB port.
Advertisement
Related Manuals for Smartenit 2011D
Summary of Contents for Smartenit 2011D
- Page 1 • The ZBCID API is available at - http://smartenit.com/downloads/ZBPCID_API.pdf Certifications FCC ID: AFZ-2011D IC ID: 10174A-2011D Monitor and Control Anything from Anywhere!! See our products in action at http://video.Smartenit.com 2016 Compacta International, Ltd. - Rev. 9/2016 IOT-ZBCID and Smartenit are trademarks of Compacta International, Ltd.
-
Page 2: Cluster Name
Client 0x0202 Fan Control Client An interface for controlling a fan in a heading/cooling system 2016 Compacta International, Ltd. - Rev. 9/2016 IOT-ZBCID and Smartenit are trademarks of Compacta International, Ltd. ZigBee is a registered trademark of the ZigBee Alliance... - Page 3 Attributes and commands for IAS Warning Devices. 0x0702 Simple Metering Client Provides mechanism to retrieve electric power usage 2016 Compacta International, Ltd. - Rev. 9/2016 IOT-ZBCID and Smartenit are trademarks of Compacta International, Ltd. ZigBee is a registered trademark of the ZigBee Alliance...
- Page 4 AFZ-2011D FCC ID: Notice: Any changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Notice: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device was tested for typical lap held operations with the device contacted directly to the human body to the back side of the notebook computer. To maintain compliance with FCC RF exposure compliance requirements, avoid direct contact to the transmitting antenna during transmitting. SAR information ...
- Page 5 This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
