Summary of Contents for EMAC PPC-E5
-
Page 1: Ppc-E5
PPC-E5 486 DX5 Panel PC User Manual Rev 1.13... -
Page 2: Table Of Contents
LCD ...................................3 Touchscreen................................4 Ethernet interface...............................4 Mechanical and environmental..........................4 Standard Parts Inventory ............................4 PPC-E5 Configuration..............................5 Jumper & Connector Descriptions..........................5 Powering Up the PPC-E5 ............................5 Ethernet..................................6 Serial Ports.................................6 Sound and LCD Contrast Controller (SLCC)......................7 Keyboard/Mouse ...............................8 Disk-On-Chip Flash Disk ............................8 PPC-E5 BIOS Defaults..............................9 Appendix A .................................11... -
Page 3: General Information
General information Features • Ultra-compact size fully integrated Panel PC (6.1” x 4.5”) • On-board AMD DX5-133 (5x86-133) CPU • Up to 64 MB on-board EDO/Fast Page-mode DRAM • Local-bus SVGA display controller (LCD, EL and CRT displays). • On-board 16-bit Ethernet 10 BaseT interface •... -
Page 4: Touchscreen
Operating temperature: 32° F to 140° F (0° C to 60° C) • Weight: 1 lb. (approximate weight of total package) Standard Parts Inventory • PPC-E5 Assembly with 5.7” touchscreen • Touchscreen inverter attached to bottom of touchscreen • Installed 16 meg. EDO, 72 Pin SIMM RAM stick. -
Page 5: Ppc-E5 Configuration
1. Note: The PPC-E5 requires less than 2 amps typical which is not enough current to load the main switcher in some larger PC power supplies (this can be verified with a voltmeter measuring the 5 volt supply). -
Page 6: Ethernet
Serial Ports The PPC-E5 is equipped with four serial ports, two which are used for on-board functionality, and two which are available to the user. COM1 and COM2 are used on-board for the SLCC and the touchscreen controller respectively. -
Page 7: Sound And Lcd Contrast Controller (Slcc)
Sound and LCD Contrast Controller (SLCC) The contrast and on-board Speaker volume are software settable via the on-board Sound and LCD Contrast Controller (SLCC). Following is the description of the serial data strings that the SLCC accepts and returns. In the description, XX or xx represent valid hexadecimal numbers in the range 00 to FF and YYYY or yyyy represent valid hexadecimal words in the range 0000 to FFFF, and AA or aa represent a valid hexadecimal address from 00 to 3F. -
Page 8: Keyboard/Mouse
(CN3) through the use of the included Y cable. Disk-On-Chip Flash Disk The PPC-E5 comes with a 16 Meg. DOC and 16 Meg. of RAM. The DOC and RAM can be increased to 32 Meg. Optionally. The DOC is a solid state flash disk and as such is extremely rugged when compared to a conventional hard drive. -
Page 9: Ppc-E5 Bios Defaults
PPC-E5 BIOS Defaults The PPC-E5 uses a General Software BIOS. To enter the BIOS you must press the <Del> key when prompted. The following BIOS screen shots indicate the BIOS options and the default factory values of each option. Note: these factory set options should not require changing. - Page 10 +------------------------------------------------------------------------------+ System BIOS Setup - Custom Configuration (C) 1999 General Software, Inc. All rights reserved +---------------------------------------+--------------------------------------+ | L1 cache mode : All | DRAM burst mode : Normal | DRAM refresh timing : Test | Refresh the ISA bus : Disabled | | DRAM read timing : EDO X333 | DRAM write timing...
-
Page 11: Connector Pinouts
Appendix A Connector Pinouts Ethernet 10Base-T connector (CN2) Signal XMT+ XMT- RCV+ RCV- Keyboard/Mouse PS/2 connector (CN3) Signal MS CLOCK KB CLOCK VCC (5V) MS DATA KB DATA VGA connector (CN4) Signal Signal Red video Key (no pin) Green video Sync return (GND) Blue video Monitor ID (not used) -
Page 12: Main Power Connector(Cn8)
LCD connector (CN7) Signal Signal +12 V DC +12 V DC Vcc(+5V/+3.3V) Vcc(+5V/+3.3V) ENA VEE SHFCLK FLM (V SYS) LP (H SYS) ENABKL SHFCLK /ASHFCLK Main Power Connector(CN8) Signal +5 V +12 V Touch Screen (CN9) (Resistive Touch Screen) Singnal Horizontal Resistance Vertical Resistance Horizontal Resistance... -
Page 13: Com 3 Optional Rs-422/485 Serial Port (Cn11)
COM 3 Optional RS-422/485 serial port (CN11) Signal DB9 Pin # Tx+(A) Tx+(A) Tx-(B) Rx+(A) Tx-(B) Rx-(B) Rx+(A) Rx-(B) Speaker (CN13) Signal Speaker + Speaker - Floppy drive connector (CN12) Signal Signal DENSITY SELECT INDEX MOTOR 0 DRIVE SELECT 1 DRIVE SELECT 0 MOTOR 1 DIRECTION... -
Page 14: Jumper Settings
Appendix B Jumper Settings LCD Voltage Jumper Setting No Jumper Not Available Pins 1 & 2* 5v LCD output Pins 2 & 3 3V LCD output * Default setting, for Kyocera LCD. LCD Type Jumper Setting Pins 1 & 2 Special STN Pins 2 &... -
Page 15: Mechanical Drawing Of Pcb With Dimensions
Appendix C Mechanical drawing of PCB with dimensions...
