Summary of Contents for SZICS NIS-886
- Page 1 User Manual Ver0.2 NIS-886 Fanless Embedded Box PC Intel® Atom™ processor Intel CG82NM10 PCH Onboard 2GB DDR3 memory Intel® integrated graphic media accelerator 3600 VGA/HDMI Display 1 x Intel®82583 GbE LAN 1 x RS232,6 x USB 12V~24V Wide range voltage input...
- Page 2 The documentation and the software included with this product are copyrighted 2013 By SZICS Co., Ltd. All rights are reserved. SZICS Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice.
-
Page 3: Declaration Of Conformity
Because of SZICS’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an SZICS product is defective, it will be repaired or replaced at no charge during the warranty period. For out of warranty repairs, you will be billed according to the cost of replacement materials, service time and freight. -
Page 4: Technical Support And Assistance
– The exact wording of any error messages Warnings, Cautions and Notes Warning! Warnings indicate conditions, which if not observed, can cause personal injury! Caution! Cautions are included to help you avoid damaging hardware or losing data. Note! Notes provide optional additional information. NIS-886 User Manual... -
Page 5: Safety Instructions
18. Caution: The computer is provided with a battery-powered real-time clock cir-cuit. There is a danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by the manufacture. Discardused batteries according to the manufacturers instructions. NIS-886 User Manual... -
Page 6: Packing List
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). Disclaimer: This set of instructions is given according to IEC 704-1. SZICS disclaims all responsibility for the accuracy of any statements contained herein. -
Page 7: Table Of Contents
..............24 ONFIGURATION ETTING 3.3.4 SATA C ................25 ONFIGURATION 3.3.5 USB C ................26 ONFIGURATION 3.3.6 S I/O C ..............27 UPER ONFIGURATION 3.3.7 PC H ................. 29 EALTH TATUS 3.3.8 PPM C ................31 ONFIGURATION NIS-886 User Manual... - Page 8 ............53 PGRADE NSTRUCTION 4.6.2 BIOS LOGO R ........53 EPLACEMENT NSTRUCTION Chapter 5 Appendix: A............54 SYSTEM I/O PORTS ..................57 1ST MB MEMORY MAP .................. 57 DMA CHANNEL ASSIGNMENTS ..............58 INTERRUPT ASSIGNMENTS ................58 NIS-886 User Manual viii...
-
Page 9: Chapter 1 General Introduction
General Introduction This chapter gives background information on NIS-886 series. NIS-H886 User Manual... -
Page 10: Introduction
EMI, shock/vibration, cold and heat, but also passive cooling for quiet, fanless operation. NIS-886 meets demands by offering up to 1 x VGA, 1x HDMI,1 x Giga LAN, 6 x USB 2.0 ports, and 1 x COM ports all packed into a compact rugged unit and powered by an Intel®... -
Page 11: Electrical Specifications
Power requirement: +12V-24V DC Wide range voltage input. Support power input reverse direction protection, recoverable fuse. Power Adapter: AC to DC 12 V/5A, 60W Power consumption: D2600(Fanless) Voltage Current Power Idle mode +12V 0.74 8.88 Power on +12V 1.09 13.08 Max load +12V 0.88 10.56 NIS-886 User Manual... -
Page 12: Environmental Specifications
Vibration loading during operation: – With SSD: 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis Shock during operation: – With SSD: 30 G, IEC 60068-2-64, half sine, 11 ms duration Safety: UL,CB,CCC EMC: CE, FCC Class A,GB9254 NIS-886 User Manual... -
Page 13: Mechanical Specifications
1.7 Mechanical Specifications NIS-886 User Manual... - Page 14 Figure 1.7 NIS-886 mechanical dimension drawing NIS-886 User Manual...
-
Page 15: Chapter 2 H/W Installation
H/W Installation This chapter explains the setup procedures of the NIS-886 hardware, including instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all safety precautions before you begin the installation procedure. NIS-886 User Manual... -
Page 16: Jumpers
1. Please check the M/B carefully, where there is a mark of “1” or white thick line, there is Pin1. 2. Look into the pad on the back side of the M/B, generally the square side of the pad is Pin1. NIS-886 User Manual... -
Page 17: Jumper Setting
1-2 On (Default) 2-3 On Sclect AT or ATX model JCMOS CMOS Clear/AT & ATX Power Mode Select Part Number Description Pin Header 1x3Pin 2.54mm DIP & Jumper 2.54mm Setting Function 1-2 On (Default) Normal 2-3 On Clear BIOS NIS-886 User Manual... - Page 18 BIOS setting menu once the system reboot. 5. Set the CPU operating speed to default value or a reasonable value; 6. Save & Exit the BIOS menu. Power Mode Select: AT power mode: Boot-up automatically when power-on. NIS-886 User Manual...
- Page 19 2.1.3 NIS-886 I/O Indication NIS-886 User Manual...
- Page 20 Figure 1.7 NIS-886 mechanical dimension drawing NIS-886 User Manual...
-
Page 21: Pin
Part Number Description DC-Jack HXSDC-S-R-01-120U"-10.0*9.1-J-B-C-Sn 5Pin DIP Signal Signal NIS-886 comes with a DC-Jack header that carries 12-24VDC external power input.The bracket makes the power connector very secure. VGA Port with Back I/O Panel Part Number Description VGA Port D-Sub 15Pin Female DIP... - Page 22 LAN1TCT(LAN21V9) LAN1TCTG NIS-886 provides one RJ45 LAN interface connector which is fully compliant with IEEE 802.3u 10/100/1000 Mbps CSMA/CD standards. It is equipped with 82583V and support Wake on LAN. The Ethernet port uses a standard RJ-45 jack connector with LED indicators on the front side to show Active/Link status and Speed status Intel 82583V PCI-E 10/100/1000 Mb/s Ethernet, suporting wake on LAN and PXE.
- Page 23 To better meet our clients’ application, +5V doesn’t do limited 500mA current protection, so every USB output can satisfy max. 1A current demand. SIM Card Socket Part Number Description SIM Card Socket Push 7+2Pin SMD Signal Signal SIM_PWR SIM_RST# SIM_CLK NIS-886 User Manual...
- Page 24 AUDIO Jack Green Vertical 5Pin DIP Signal Signal NIS-886 offers stereo audio ports by two 3.5 ear phone jack connectors of Line_out and Line_in. The audio chip controller is ALC662 which is compliant with the Azalea standard. MIC (MIC1) MIC Connector...
-
Page 25: Peripheral Installation
CND10 CND6 USB_D- RSVD5 USB_D+ RSVD6 CND11 RSVD7 LED_WWAN# RSVD8 LED_WLAN# RSVD9 LED_WPAN# RSVD10 +1.5V_3 RSVD11 CND12 RSVD12 +3.3V_2 Support PCI Express x1 bus Mini PCIE and USB device. 2.3 Peripheral Installation 2.3.1 HDD Installation (NIS-886 only) NIS-886 User Manual... -
Page 26: Chapter 3 Bios Settings
BIOS Settings NIS-886 User Manual... -
Page 27: Entering Setup
BIOS supports your CPU. If there is no number assigned to the patch code, please contact an SZICS application engineer to obtain an up-to-date patch code file. This will ensure that your CPU's system status is valid. After ensuring that you have a number assigned to the patch code, press <DEL>... -
Page 28: Main Setup
<Arrow> keys. Enter new values through the keyboard. Press the <Tab> key or the <Arrow> keys to move between fields. The date must be entered in MM/DD/YY format. The time must be entered in HH:MM:SS format. NIS-886 User Manual... -
Page 29: Advanced Bios Features Setup
3.3 Advanced BIOS Features Setup Select the Advanced tab from the NIS-886 setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>... -
Page 30: Pci Subsystem Setting
3.3.1 PCI Subsystem Setting Figure 3.4 PCI Subsystem Configuration Setting NIS-886 User Manual... -
Page 31: Acpi Setting
3.3.2 ACPI Setting Figure 3.5 ACPI Configuration Setting NIS-886 User Manual... -
Page 32: Cpu Configuration Setting
3.3.3 CPU Configuration Setting Figure 3.6 CPU Configuration Setting Max CPUID Value Limit This item allows you to limit CPUID maximum value. Execute-Disable Bit Capability NIS-886 User Manual... -
Page 33: Sata Configuration
This item allows you to enable or disable the No-Execution page protection technology. Hyper Threading Technology This item allows you to enable or disable Intel Hyper Threading technology. 3.3.4 SATA Configuration Figure 3.7 SATA Configuration NIS-886 User Manual... -
Page 34: Usb Configuration
SATA E Configuration This item allows you to select Disabled / IDE / AHCI 3.3.5 USB Configuration Figure 3.8 USB Configuration NIS-886 User Manual... -
Page 35: Super I/O Configuration
3.3.6 Super I/O Configuration NIS-886 User Manual... - Page 36 Figure 3.9 Super I/O Configuration Serial Port1- Port2 address This item allows you to select serial port1 ~ port2 of base addresses. Serial Port1- Port2 IRQ This item allows you to select serial port1 ~ port2 of IRQ. NIS-886 User Manual...
-
Page 37: Pc Health Status
GPIO Setting These 6bit GPIO are extracted from SIO, but the M/B NIS-886 does NOT lead out this function, so this configuration is invalid. 3.3.7 PC Health Status Figure 4.0 PC Health status NIS-886 User Manual... - Page 38 NIS-886 User Manual...
-
Page 39: Ppm Configuration
3.3.8 PPM Configuration Figure 4.1 PPM Configuration EIST NIS-886 User Manual... - Page 40 When configuration is “Enabled”, the M/B will auto-adjust operation frequency according to current CPU operation status, for power saving consideration. This selection item also support the configuration of CPU sleep state, support max. Intel C6 mode. NIS-886 User Manual...
-
Page 41: Chipset Settings/Host Bridge
3.4 Chipset Settings/HOST Bridge Figure 4.2 Advanced Chipset Settings NIS-886 User Manual... -
Page 42: Intel Igd Configuration
3.4.1 Intel IGD Configuration Figure 4.3 PPM Configuration NIS-886 User Manual... -
Page 43: Chipset Settings/South Bridge
During POST process and DOS mode, only one display device can be chosen for display, otherwise, it won’t work; And only after entering to Windows or Linux OS, it can support dual display (simultaneously or asynchronous display). 3.5 Chipset Settings/SOUTH Bridge Figure 4.4 Advanced Chipset Settings NIS-886 User Manual... -
Page 44: Nm10 Chip Configuration
3.5.1 NM10 Chip Configuration Figure 4.5 NM10 Chip Settings NIS-886 User Manual... - Page 45 This selection item is for Audio/NM10 Chip integrated network card /SMBus configuration. LAN controller NIS-886 does Not apply Intel NM10 chipset built-in Intel 82567V LAN controller, so the default setting is “Disabled”. SMBUS Controller Enables or disables the SMBUS controller.
-
Page 46: Pci Expresss Port 0-Port 4 Configuration
3.5.2 PCI Expresss Port 0-Port 4 Configuration NIS-886 User Manual... - Page 47 NIS-886 User Manual...
- Page 48 NIS-886 User Manual...
- Page 49 Figure 4.6 PCI Expresss Port Settings NIS-886 User Manual...
-
Page 50: Restore Ac Power Loss Configuration
If the former state is "Power On", then the device will automatically boot-up when power-on again; if the former state is "Power off", then the device will remai n power-off when the power- on again. NIS-886 User Manual... -
Page 51: Boot Configuration
3.5.3 BOOT Configuration NIS-886 User Manual... -
Page 52: Exit Option
3.6 Exit Option Figure 3.27 Exit Option NIS-886 User Manual... -
Page 53: Discard Changes And Exit
2. Select Discard Changes from the Exit menu and press <Enter>. 3.6.3. Load Optimal Defaults The NIS-886 automatically configures all setup items to optimal settings when you select this option. Optimal Defaults are designed for maximum system performance, but may not work best for all computer applications. -
Page 54: Chapter 4 S/W Introduction & Installation
S/W Introduction & Installation NIS-886 User Manual... -
Page 55: S/W Introduction
BIOS upgrade burning and curing service 4.2 Driver Install There is a driver CD with the NIS-886 accessory, and all the driver programs are in it, please install the drivers and application programs after the OS installation to ensure the M/B can fully play the great performance. If you are using the upgraded version, we suggest to remove all the drivers and application programs of the old version before installing the new version. -
Page 56: Linux Driver Install
4.2.4 Linux Driver Install NIS-886 provides 2line onboard Intel82583 Giga LAN, since the kernel of Linux OS has not loaded Intel82583 Driver, so when we run Linux OS, we need set PCIE Port 0 and PCIE Port 1 as Disabled, and enter Linux OS to install Intel82583 Driver, then restart OS and set PCIE Port 0 and PCIE Port 1 as Enabled, only after that the LAN can work normally. -
Page 57: Watchdog Program Example
WDT will start to count down from this value. If both of the bit7 and bit6 are set as “1”, then the interrupt from mouse or keyboard would result to re-countdown from this nonzero value. The value in reading register is the present count down value, not NIS-886 User Manual... -
Page 58: Pen Mount Resistive Touch Controller Drivers
; Enter configuration mode by double writing (unlock SuperIO chip) DX, 2eh AL, 87h DX, AL DX, AL ; select wdt，disable GP50 DX, 2eh DX, AL DX, 2fh AL, DX AL, 11111110b Clear bit0 DX, AL ; Access logical device 8 DX, 2eh AL, 07h NIS-886 User Manual... -
Page 59: Gpio Program Example
AL, 0aah DX, AL 4.5 GPIO program example General Purpose Input/Output is a flexible parallel interface that allows a variety of custom connections. It allows users to monitor the level of signal input or set the out- NIS-886 User Manual... -
Page 60: Overview
Configure GPIO Input: Running application “GPIOIN.EXE” to set these 8 GPIO as “Input”. Please refer to “GPIOIN.CPP” for reference code. Remark: During the configuration process of setting “Input High/Low”, we can check the status by running GETIO. NIS-886 User Manual... -
Page 61: Bios Service
The BIOS Flash utility also provides a command line version for fast implementation into customized applications. SZICS also provides BIOS curing service for clients. 4.6.1 BIOS Upgrade Tool Instruction The burner can be only applied to DOS environment, the user should prepare a boot disk with DOS system before BIOS burning process;... - Page 62 “save logo” to save the logo under a specified directory. During the Logo replacement operation, please click “Browse” to select Logo which is to be adopted in the BIOS, and the image size must be 800x600 or 640x480 with BMP format: NIS-886 User Manual...
- Page 63 Click “Save Image AS”, to save the new BIOS under a specified directory. If it doesn’t display the new BIOS Logo after system reboot, please check if the setting as bellow is Enable: Boot-->Quiet Boot-->Enable NIS-886 User Manual...
-
Page 64: Chapter 5
Appendix: A NIS-886 User Manual... -
Page 65: System I/O Ports
PCI bus FEC00000h - FEC00FFFh Motherboard resources FED00000h - FED003FFh High precision event timer FED14000h - FED19FFFh System board FED1C000h - FEE00FFFh Motherboard resources FF000000h - FFFFFFFFh Intel 82802 firmware Hub Device Table 5.2: 1st MB Memory Map NIS-886 User Manual... -
Page 66: Dma Channel Assignments
Standard 101/102-Key or Microsoft Natural PS/2 Keyboard IRQ3 COM2 IRQ4 COM1 IRQ8 System CMOS/real time clock IRQ9 Microsoft ACPI-Compliant System IRQ11 SMBUS Controller IRQ16 Network /USB IRQ17 Network IRQ18 IRQ19 SATA IRQ22 IRQ23 Table 5.4: Interrupt Assignments NIS-886 User Manual... - Page 67 Distributor for The Netherlands, Belgium, Luxemburg: Delmation Products BV Wattstraat 28m 2723RC Zoetermeer Tel: +31 (0)79 342 2041 www.delmation.nl sales@delmation.nl NIS-886 User Manual...
Need help?
