NIS-H896 User Manual
1
NIS-H892
Fanless Embedded Box PC
Intel®Haswell™4
SODIMM DDR3 Socket
Intel® HD Graphics Integrated Graphic Card
DVI-I/VGA Display
4 x Intel®I210 GbE LAN
2 x RS232/ IsolationRS485,4X RS232
4 x USB2.0, 2 x USB3.0
+9V~+30V Extended Voltage Input
User Manual
th
Gen. U-series Processor
Ver0.2
Advertisement
Table of Contents
Related Manuals for SZICS NIS-H892
Summary of Contents for SZICS NIS-H892
- Page 1 User Manual Ver0.2 NIS-H892 Fanless Embedded Box PC Intel®Haswell™4 Gen. U-series Processor SODIMM DDR3 Socket Intel® HD Graphics Integrated Graphic Card DVI-I/VGA Display 4 x Intel®I210 GbE LAN 2 x RS232/ IsolationRS485,4X RS232 4 x USB2.0, 2 x USB3.0 +9V~+30V Extended Voltage Input...
- Page 2 The documentation and the software included with this product are copyrighted 2013 By SZICS Co., Ltd. All rights are reserved. SZICS Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice.
-
Page 3: Declaration Of Conformity
Because of SZICS’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an SZICS product is defective, it will be repaired or replaced at no charge during the warranty period. For out of warranty repairs, you will be billed according to the cost of replacement materials, service time and freight. -
Page 4: Technical Support And Assistance
Technical Support and Assistance 1. Visit the SZICS web site at www.SZICS.com/support where you can find the latest information about the product. 2. Contact your distributor, sales representative, or SZICS's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –... -
Page 5: Safety Instructions
18. Caution: The computer is provided with a battery-powered real-time clock cir-cuit. There is a danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by the manufacture. Discard used batteries according to the manufacturers’ instructions. NIS-H892 User Manual v ... -
Page 6: Packing List
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). Disclaimer: This set of instructions is given according to IEC 704-1. SZICS disclaims all responsibility for the accuracy of any statements contained herein. -
Page 7: Table Of Contents
........................5 NSTALLATION XPLAIN 2.1.3 J .......................... 6 UMPER ETTING 2.1.4 NIS-H892 I/O I ......................7 NDICATION 2.2 I/O & PIN DEFINITION ........................8 Chapter 3 BIOS settings ..........15 BIOS OVERVIEW ......................... - Page 8 Indexes: A ............42 SYSTEM I/O ADDRESS ....................... 36 A.2 1ST MB MEMORY MAP ......................36 A.3 DMA CHANNEL ........................... 37 A.4 INTERRUPT ..........................37 NIS-H892 User Manual viii ...
-
Page 9: General Introduction
Chapter 1 Chapter 1 General Introduction NIS-H896 User Manual... -
Page 10: Chapter 1 Product Introduction
NIS-H892 is designed as a palm-size fanless embedded system and occupies only 260 x 176 x 49 mm 260*176, The rugged, cast aluminum case not only provides great protection from EMI, shock/vibration, cold and heat, but also provides passive cooling for quiet, fanless operation. -
Page 11: Specifications
System Memory: SODIMM socket, DDR3L-1600, Support Max. 16GB Watchdog Timer: 255-level interval timer, setup by software Serial Port: - 2 x RS232/RS485 jumper setting, RS485 supports 3000V magnetic isolation, automatic flow control; - 4 x RS232，Support 4000V Surge protection; USB： NIS-H892 User Manual 3 ... -
Page 12: Display
Chipset: Intel® I210 GbE LAN, support 4000V lightning surge protection Speed: 10/100/1000 Mbps, suppot Wake-on-Lan & Link/Speed LED indicator Connector: 4* RJ45, support 48V@500mA POE 1500Vrms isolated power supply Standard: In compliance with IEEE 802.3、IEEE 802.3u、IEEE 802.3x、IEEE 8023y、IEEE 802.ab NIS-H892 User Manual 4 ... -
Page 13: Power Supply & Consumptions
1.3.5 Power Supply & Consumptions Power Input: DC +9V ~ +30 V Adaptor: AC ~ DC 19V/4.7A，90W Power On Type: AT / ATX Jumper selection APM : ACPI 3.0, APM NIS-H892 User Manual 5 ... -
Page 14: Environment
-20 ~ 70° C（extended temp. SSD/mSATA device,I3 CPU） 0 ~ 50° C（HDD） Relative Humidity: 95% @ 40°C（Non-condensing） Storage Temp.: -40 ~ 85°C (-40 ~ 185°F) n Operating Anti-vibration: – With SSD/mSATA：3Grms, IEC60068-2-64, random, 5 ~ 500Hz, 1 hr/axis NIS-H892 User Manual 6 ... - Page 15 Operating Anti-Shock: – With SSD/mSATA：30G, IEC60068-2-64, half-sine,11ms duration time. Safety: In compliance with UL,CCC EMC/ROSH：CE, FCC A, ROSH certificate NIS-H892 User Manual 7 ...
-
Page 16: Other Functions
1.5 OS Support Win7, Win8,WES7, Win CE 7.0, and Linux 1.6 Other Functions n Power switch, power indicator n 1-255 sec. watchdog n 12 bits, support routine, self-define I/O, 3.3V@24mA NIS-H896 User Manual... -
Page 17: Mechanical Dimensions
1.7 Mechanical Dimensions Figure 1.7 NIS-H892 mechanical dimension drawing NIS-H892 User Manual 2 ... -
Page 18: Chapter 2 Hardware Installation
Chapter 2 Chapter 2 Hardware Installation NIS-H892 User Manual 3 ... -
Page 19: Jumper And Installation
Sometimes a jumper will have three pins, labeled as pin1, pin2 and pin3. In this case the user can connect either pins 1 and pin2, or pin2 and pin3. Please refer to bellow: NIS-H892 User Manual 4 ... -
Page 20: Installation Explain
Unscrew pan head fixed chassis around 8 M2.5, remove the lower cover of the computer case can be carried out from the bottom, hard disk, M-SATA, memory, Mini-PCIe equipment installation. And can be set up to the corresponding functional jumper. NIS-H892 User Manual 5 ... -
Page 21: Jumper Setting
Function 1-2 On (Default) Normal 2-3 On Clear BIOS Note: Please turn-off the power supply before jumper setting or CMOS clear in case any damage caused. Setting battery power as 3.0V before connecting power again. NIS-H892 User Manual 6 ... -
Page 22: Nis-H892 I/O Indication
2.1.4 NIS-H892 I/O Indication Figure 2.1.3 NIS-H892 mechanical dimension drawing NIS-H892 User Manual 7 ... -
Page 23: I/O & Pin Definition
This interface also supports the connection of external switch, +12V/5V@2A power output is connected to the supply of external equipment COM1 Part Number Description COM Port D-Sub 9Pin Male DIP Signal Signal 9 Wire RS232 Interface，Support a maximum 115200bps Rate，Support 4000V Surge protection. NIS-H892 User Manual 8 ... - Page 24 GPIO6 GPIO7 GPIO8 GPIO9 GPIO10 GPIO11 GPIO12 V3.3S Free programming is defined as the input or output, the driving power of 3.3V@24mA DVI Port Part Number Description DVI-D 24Pin Fe male DIP NIS-H892 User Manual 9 ...
- Page 25 VGA PortD-SUB 15Pin Female DIP Signal Signal GREEN BLUE DATA_DDC HSYNC VSYNC CLK_DDC Convert from DP to CH7517, support VGA display, Max. 1920 x 1080 resolution. Power Input connector (DC_IN1) Part Number Description DC-Jack 3Pin DIP NIS-H892 User Manual 10 ...
- Page 26 Signal Signal NIS-H892 with a 9-30V support DC external power input of the phoenix head jack. The ACC signal is connected with a vehicle ACC signal support. Power Switch Part Number Description Power Button LED PTCT-07-A 5P 7Pin DIP NIS-H892 has a power button with LED indicator.
- Page 27 Bi-directional Data- Receive Data- Bi-directional Data+ Bi-directional Data- NIS-H892 Provides 4 POE RJ45 LAN port, in full compliance with the IEEE 802.3u 10/100/1000 Base-T CSMA/CD standard. RJ-45 connector using standard Ethernet port, 1500Vrms isolation. support 48V@500mA POE power output, Link/Speed LED lights, for indicating transmission / connection state and speed condition NIS-H892 User Manual 12 ...
- Page 28 Audio Part Number Description AUDIO Jack Green Vertical 5Pin DIP Signal Signal Provide two 3.5 stereo audio input & output. Audio chip controller is ALC662, in compliance with Azalea standard. NIS-H892 User Manual 13 ...
-
Page 29: Chapter 3 Bios Settings
Chapter 3 Chapter 3 BIOS Settings NIS-H892 User Manual 14 ... -
Page 30: Bios Overview
Please use internal default value of BIOS to restore the system. Our company is constantly updating BIOS, so the setup interface may varies sometimes. The default options bellow are just for reference only. NIS-H892 User Manual 15 ... -
Page 31: Main Menu
BIOS Information (read only): To display BIOS info, including Project Name, Build Date ect. Processor Information: To display the basic Processor Information Total Memory: To display the Total Memory Memory Frequency: To display the Frequency Memory is running NIS-H892 User Manual 16 ... -
Page 32: Advanced Menu
3.3 Advanced Menu ACPI Settings. CPU Configuration. SATA Configuration. USB Configuration. Super IO Configuration. H/W Monitor. NIS-H892 User Manual 17 ... -
Page 33: Acpi Settings
3.3.1 ACPI Settings Enable Hibernation: Enables or Disables System ability to Hibernate (OS/S4 Sleep State). This option may be not effective with some OS.. ACPI Sleep State: Select the ACPI state used for system suspend.(S3 state) . NIS-H892 User Manual 18 ... -
Page 34: Cpu Configuration
3.3.2 CPU Configuration Show the detail information of the processor and setting for it. NIS-H892 User Manual 19 ... -
Page 35: Sata Configuration
SATA Mode Selection: Determines how SATA controller(s) operate. SATA Controller Speed: Indicates the maximum speed the SATA controller can support. Serial ATA Port X(0-3): Show the sata device information detected on this port Port X(0-3) : Enable or Disable this sata port NIS-H892 User Manual 20 ... -
Page 36: Usb Configuration
2. The XHCI ownership change should be claimed by XHCI driver. EHCI Hand-off: 1. This is a workaround for OSes without EHCI hand-off support. 2. The EHCI ownership change should claim by EHCI driver. USB Mass Storage Driver Support: Enable/Disable USB Mass Storage Driver Support. NIS-H892 User Manual 21 ... -
Page 37: Super Io Configuration
1. Power on: System will always power on when restore AC power 2. Power Off: System will not power on when restore AC power 3. Last State: whether power on depend on the state when Power Loss NIS-H892 User Manual 22 ... -
Page 38: H/W Monitor
3.3.6 H/W Monitor PC Health Status: read only, including CPU/System temperature, Fan Speed, VCORE, VDIMM, +3.3V , +5V , +12V, VBAT. NIS-H892 User Manual 23 ... -
Page 39: Chipset
3.4 Chipset PCH-IO Configuration: PCH Parameters System Agent (SA) Configuration: System Agent (SA) Parameters NIS-H892 User Manual 24 ... -
Page 40: Pch-Io Configuration
3.4.1 PCH-IO Configuration PCI Express configuration: PCI Express Root Port 1-6 Setting NIS-H892 User Manual 25 ... - Page 41 NIS-H892 User Manual 26 ...
- Page 42 NIS-H892 User Manual 27 ...
-
Page 43: System Agent (Sa) Configuration
3.4.2 System Agent (SA) Configuration Graphics Configuration : Graphics Device Settings. NIS-H892 User Manual 28 ... - Page 44 DVMT Pre-Allocated: Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device. DVMT Total Gfx Mem: Select DVMT5.0 Total Graphic Memory size used by the Internal Graphics Device. NIS-H892 User Manual 29 ...
-
Page 45: Boot Menu
Quiet Boot: Configure whether to display the content of customized Logo. 1. Disabled: Displays normal POST messages; 2. Enabled: Displays OEM Logo (no POST messages); Launch PXE OpROM policy: Enable or Disable Lan PXE Boot Function; NIS-H892 User Manual 30 ... -
Page 46: Boot Option Priorities
1. Boot Option #1: Setting first boot device. 2. Boot Option #2: Setting second boot device. 3. Hard Drive BBS Priorities: Setting the boot priority of Hard Disk 3.6 Security Menu Change Administrator / User Password: NIS-H892 User Manual 31 ... -
Page 47: Save & Exit
Save as User Defaults This item allows you to save the changes done so far as user defaults. Restore User Defaults This item allows you to restore the user defaults to all the options. Boot Override NIS-H892 User Manual 32 ... -
Page 48: Software Service Introduction
You can use the tool GPIO.exe under DOS to test whether the pin can be used as a GPIO. Usage: GPIO : Show help screen GPIO Gpio Num : Set GPIO Port as input GPIO Gpio Num : Set GPIO Port output high GPIO Gpio Num : Set GPIO Port output Low NIS-H892 User Manual 33 ... - Page 49 Example: GPIO : Set GPIO 1 as input GPIO : Set GPIO 1 output high GPIO : Set GPIO 1 output Low NIS-H892 User Manual 34 ...
-
Page 50: Indexes: A
Chapter 5 Chapter 5 Index: A NIS-H892 User Manual 35 ... -
Page 51: System I/O Address
FEC00000h - FEC00FFFh Motherboard resources FED00000h - FED003FFh High precision event timer FED14000h - FED19FFFh System board FED1C000h - FEE00FFFh Motherboard resources FF000000h - FFFFFFFFh Intel 82802 firmware Hub Device Table 5.2: 1st MB Memory Map NIS-H892 User Manual 36 ... -
Page 52: Dma Channel
Standard 101/102-Key or Microsoft Natural PS/2 Keyboard IRQ3 COM2 IRQ4 COM1 IRQ8 System CMOS/real time clock IRQ9 Microsoft ACPI-Compliant System IRQ11 SMBUS Controller IRQ16 Network /USB IRQ17 Network IRQ18 IRQ19 SATA IRQ22 IRQ23 Table 5.4: Interrupt Assignments NIS-H892 User Manual 37 ... - Page 53 Contact Us www.szics.com Shenzhen Industrial Computer System Co.,Ltd. Tel.: 400-6566-510 / 0755-61887555 Add.: 5th Floor, Building C1, Hua Tongyuan Logistic Centre, Minzhi Av. No.2, Longhua Town,Shenzhen City,P.R.China. NIS-H892 User Manual 38 ...
