Congratulations on the purchase of your new A2B Pedelecs! At A2B we have set ourselves the goal of redefining your daily mobility and bringing you from A to B in style. With an A2B, you'll have more fun than with a car, avoid the frustrating search for a parking space, save fuel costs and at the same time protect the environment.
Page 3
3.2 Adjusting the brake levers Can you operate the brake levers comfortably? If this is not the case, take your A2B to a dealer and ask them to adjust the angle of the brake levers. Otherwise, you can adjust the angle of the brake levers yourself as follows: Loosen the screw under the brake lever with a suitable Allen key.
Page 4
At the end of your first journey If you have any questions or have the impression that your A2B is not yet optimally adjusted and tuned to you, we recommend that you consult your dealer before continuing to use your A2B.
Page 5
5. operating instructions drive system 5.1.1 Important information - please observe! Please observe all the documents enclosed with your A2B and all the instructions in this manual and on the vehicle with stickers. 5.1.2 Intended use of the engine components Equipped with an A2B by Bafang drive system, the A2B is a Pedelec (pedal electric cycle) for the normal passenger transport of a person on public roads.
Page 6
Technical changes to the engine components Changes to the software of the drive components Unauthorized mounting or use of the engine components on bicycles or other than the A2B Pedelec supplied to you. 5.1.3 Permissible operating conditions / locations A2B pedelecs can be operated at temperatures between -10°C and +45°C.
Page 7
By pressing and holding the "-" button (S4) for more than 3 seconds, the pushing aid is activated. The pedelec now moves forward at 3-5km/h as long as the push button is held down. This mode is not designed for mounted operation.
Page 8
socket. Now connect the charging plug of the supplied charger to the charging socket of the battery. Then connect the charger's mains plug to an earth contact socket. The LED on the charger will now turn red. As soon as the charging process is completed, this LED switches to green. First disconnect the charger from the earth contact socket and then disconnect the charging plug from the battery socket.
Page 9
5.1.4.3.2 Safety and Warnings for Storage of the Battery Protect the battery immediately after disconnecting the charger or motor. Neither moisture nor foreign particles (e. g. metal splinters, small nails, chips or other conductive metals) may penetrate the battery. Do not expose the battery to any moisture (water, rainwater, snow, etc.) during storage! Store the battery in a cool, dry place where it is protected from damage and unauthorized access.
6.1.3 Rims The rims should not show any cracks, dents or flat spots. If necessary, take your A2B to a dealer for repair and/or adjustment of the wheels.
Driving in wet conditions: You should always remember that your A2B has a longer braking distance. Slow down, keep a longer distance between yourself and other road users and slow down sooner than usual. Failure to observe these safety precautions could result in accidents with serious or even fatal injuries and/or damage to property.
Battery Act can be found on the website of the Federal Ministry for the Environment. 11 Maintenance schedule Your A2B pedelec should be serviced at regular intervals. At least once a year or every 2500 km the...
Page 13
most important points should be checked and wear parts replaced. We recommend using the following maintenance plan. Not regular maintenance can void the warranty on components. We also recommend an initial inspection.
15 Manufacturer Data Hero Eco Ltd Unit 16 Bessemer Industrial Park 250 Milkwood Road London SE24 0HG www.wearea2b.com Versionsstand: A2B_2017_GW_01_ENG...
