Summary of Contents for Lexus ROIK 2017
- Page 1 Lexus ROIK...
-
Page 2: Table Of Contents
1. Specification Contents 2. External Appearance 3. Connector Pin Assignment 4. DIP S/W Information 5. Components 6. Cable diagram 7. Connect CAN/Power diagram 8. Connect CAN/Power connector 9. Connect LVDS In/Out 10. OEM Buttons usage 11. DVB-T Connection Diagram for AV Input 12. -
Page 3: Specification
Specification Android • OS : Android 5.1.1(Lollipop) CPU : NXP5430Q - Cortex-A53 Octa Core @1.6Ghz Mali-400 MP4 GPU Memory : 2GB DDR3 @800Mhz SD Card : 16GB (SDHC Class10, Max 32GB support, FAT32) USB : USB2.0 High Speed Port x 2 Telecommunication : 802.11 b/g/n Wi-Fi, Bluetooth 4.0 GPS : Ublox7 Speaker : 2W... -
Page 4: External Appearance
External Appearance Power/Can Calbe Wifi / BT Antenna DEBUG - main DEBUG - tw88 DEBUG - sub SD Card Slot K-PAD HDMI Input GVIF In/Out 5V Power AV IN Dip Switch (AV Cable) AV IN/OUT USB 2.0 x 2 (Universal Cable) GPS Antenna... -
Page 5: Connector Pin Assignment
Connector Pin Assignment ※ POWER CABLE ※ AV CABLE ※ UNIVERSAL CABLE ※ POWER CABLE ※ UNIVERSAL CABLE BATTERY N.C. N.C. 12V_OUT N.C. N.C. REAR_12V BUTTON_KEY OMNI_KEY ECU_CAN_H ECU_CAN_L TOYOTA_BUS_L TOYOTA_BUS_H SPK_P SPK_N MON_CAN_L MON_CAN_H AUX_OUT_R AUX_GND AUX_OUT_L AUX_GND DVBT_IN_V MIC_P MIC_N ※... -
Page 6: Dip S/W Information
DIP S/W Information ON 1 No. 1 No. 2 No. 3 No. 4 No. 5 No. 6 Car Model Lexus RX Lexus LX... -
Page 7: Components
Components LEXUS Power/ CAN Cable Universal Cable AV Cable Android Interface GPS Antenna GVIF In/Out Cable Speaker SD Card reader (5M) Key Pad Wifi/BT Antenna SD Card... -
Page 8: Cable Diagram
Cable diagram Display type FRONT IN RES-TOUCH CAP-TOUCH Use the AUX connector using a Use it after connecting to a connector To use the front camera, use it cable compatible with the AUX compatible with the display when resistive after connecting the power supply connector. -
Page 9: Connect Can/Power Diagram
Connect CAN/Power diagram Original cable GIVF-LEXUS-A50 POWER CAN 12V OUT REAR 12V REVERSE 12V IN OMNI KEY ECU_CAN_H ECU_CAN_L... -
Page 10: Connect Can/Power Connector
Connect CAN/Power connector • Remove original connector. • Connect supplied connector to audio and original connector. • Connect ‘CAN High/Low" to the original connector from supplied connector CAN High CAN Low... -
Page 11: Connect Lvds In/Out
Connect LVDS In/Out Need to cut plastic Need to cut plastic Need to cut plastic • Remove white connector on behind of monitor. • Cut plastic of white connector and supplied connector • Connect white connector to supplied connector and supplied connector to behind of monitor. -
Page 12: Oem Buttons Usage
OEM Buttons usage no Button Press Mode Function MENU Short Press Roik To Oem Screen Short Press Roik To Oem Screen Long Press (2sec) To Roik Screen BACK Short Press Roik Back key for Android Short Press Roik Seek up down 5 DOWN Short Press Short Press... -
Page 13: Dvb-T Connection Diagram For Av Input
DVB-T Connection Diagram for AV Input Open the cover of DVB-T. Connect ‘DVBT-IR’ provided to ‘A’ on picture DVB-T UI AV CABLE UNIVERSAL CABLE... -
Page 14: Android Interface
Android Interface ① ⑥ Navigation File Manager ② ⑦ YouTube HDMI Screen (for Interface) ③ ⑧ Player Setting ④ ⑨ Online TV Wifi setting ⑤ ⑩ Internet Apps list... -
Page 15: Calibration - Resistive Touch
Calibration – Resistive touch Push button 2~3 sec after booting Calibration mode After calibration, push screen few second * Capacitive touch panel no need set calibration... -
Page 16: Firmware Upgrade
Firmware Upgrade Copy ‘system_roik_lexus’ folder to SD Card root and insert to GPS. Push hold this button and turn on (re-connect power cable), it will start upgrade *‘/sdcard/system_roik_lexus’ Folder have ‘partmap.txt / boot.img / root.img’ files...
