Technical specifications Pro-Ject Phono Box DS2

Typical for low output MC cartridges,
A
* Input capacitance is irrelevant for low-output MC cartridges
Input impedance:
Input capacitance /impedance:
Input gain:
Noise floor:
THD:
RIAA-equalisation curve accuracy:
Subsonic filter:
Input:
Line-level output:
Outboard power supply:
Power consumption:
Dimensions W x H x D / weight:

Potential incorrect use and fault conditions

No signal on one or both channels:
No connection between player and phono amplifier or amplifier. This could be due to a faulty plug,
broken wire or solder joint or simply loose plug/socket connection.
Strong hum:
No earth connection from cartridge or arm, or arm cable to phono amplifier, or earth loop.
Output too quiet or too loud, or distorted:
Input gain incorrectly set - input overloading or insufficiently amplified.

Service

Should you encounter a problem which you are not able to alleviate or identify, please contact your dealer for
further advice. Only if the problem cannot be resolved there, the unit should be sent to the responsible
distributor in your country.

Warranty

The manufacturer accepts no responsibility for damage caused by not adhering to these instructions
for use. Modification or changes to any part of the product by unauthorized persons release the
manufacturer from any liability over and above the lawful rights of the customer.

Copyright, trademarks

Pro-Ject Audio Systems is a registered Trademark of
H. Lichtenegger.
This guide was produced by: Pro-Ject Audio Systems
Copyright © 2017. All rights reserved.
4
© Pro-Ject Audio Systems · Pro-Ject Phono Box DS2 · Revision 2017.9.06
typical for MM or high output MC cartridges
B
10, 50, 100, 1k, 47kohms
47pF, 147pF, 267pF and 367pF */47kohms
40, 45 / 50, 60 and 65dB
B
80dB (A weighted) at 40dB input gain
<0,02%
20Hz - 20kHz / max. 0,3dB
at 20Hz with 12dB/octave
1 pair RCA/phono sockets
1 pair RCA/phono sockets
18V/500mA DC, suitable for your country's mains supply
100mA DC, <1W in standby
aluminium 206 x 71 x 194 / 1320g
wood 240 x 72 x 194 / 1770g
The information was correct at the time of going to
press. The manufacturer reserves the right to make
changes to the technical specification without prior
notice as deemed necessary to uphold the ongoing
process of technical development.
