- Page 1 Installation Manual MODEL ANE-42...
- Page 2 GET TO KNOW YOUR UNIT 1. CROSS BRACES 2. SIDE BRACKETS Supplied Parts: Tools Needed: Recessed Mounting: - Stud Finder - 1/4” Nut Driver (optional) - Two #10 x 1 1/2” wood screws for top - 12-14” Level portion of cabinet - Safety Glasses - Tape Measure - Two #14 x 2 1/2”...
-
Page 3: Pre-Installation
PRE-INSTALLATION Mounting 1. DETERMINE MOUNTING HEIGHT Desired Ironing Height Above Board Height Using the charts provided, determine Floor the mounting height above floor (the 29” 36” distance between the floor and the 28” 35” bottom of the cabinet). First choose 27”... - Page 4 3. ENSURE ADEQUATE SPACE Refer to the chart provided below to ensure adequate clearance for ironing. The cabinet door opens at 180 degrees; allow 16” from side of cabinet for door to fully open. ANE42 1. Distance needed on either side of unit to fully swivel the board ”...
-
Page 5: Recessed Installation
RECESSED INSTALLATION Note: Instructions based on installation between 16” on-center studs. 3. PRE-DRILL HOLES 1. CUT WALL OPENING Your unit will be attached to the studs by Cut an opening into the wall based screws in the upper and lower sides of on unit dimensions given below. - Page 6 4. INSTALL UNIT IN WALL 6. REMOVE BRACKET SCREW Locate side ironing board brackets Begin installation by carefully lifting unit that are secured to cabinet with into the wall opening. Make sure the three screws. Then remove the cabinet is plumb and level. If needed, top screw from each bracket.
-
Page 7: Surface Mount Installation
SURFACE MOUNT INSTALLATION 3. LOCATE & MARK STUD 1. PREPARE CABINET Using a stud finder, locate stud in wall Screws will be drilled through the and mark the wall according to the upper and lower cross braces inside pre-drilled holes in cabinet. Setting the cabinet. -
Page 8: Installation Complete
8. REMOVE BRACKET SCREW Locate side ironing board brackets that are secured to cabinet with three screws. Then remove the top screw from each bracket. Replace with a #14 x 3/4” Phillips screw. This will add stability long-term. 9. INSTALLATION COMPLETE Cabinet is now fully installed!
