Art.-Nr.
li 300.0592.xx
Magic Corner II
re 300.0593.xx
Montageanleitung
Vollauszug
Assembly instruction
Full-extension pull-out
max
22 lbs
max
22 lbs
Frame inset
This mounting instruction is for a left swivel pull out, Art.-No. 300.0592.xx.
The right swivel pull out instruction is mirror-inverted, Art.-No. 300.0593.xx.
Frame overlay
max
17 lbs
Frameless
6295 Mosen
Switzerland
T +41 41 919 94 00
www.peka-system.ch
max
max
=
22 lbs
10 kg
max
max
=
17 lbs
8 kg
Dimensions in mm
Inches are approximate
950.0359.MA
Rev. c
10.12.2008 hrm
24.11.2010 hrm
1/8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Peka Magic Corner II
Summary of Contents for Peka Magic Corner II
- Page 1 Art.-Nr. li 300.0592.xx Magic Corner II re 300.0593.xx Montageanleitung Vollauszug 6295 Mosen Assembly instruction Full-extension pull-out Switzerland T +41 41 919 94 00 www.peka-system.ch Frame overlay 22 lbs 10 kg 17 lbs 8 kg 17 lbs 22 lbs 22 lbs...
- Page 2 Before starting the installation Furniture make sure that the cabinet is level and secured to the wall Frameless Frame inset (red line is behind face frame) Dimensions in mm Inches are approximate 950.0359.MA Rev. c 10.12.2008 hrm 24.11.2010 hrm...
- Page 3 Frame overlay Spacer for frame inset Spacer for frame overlay Dimensions in mm Inches are approximate 950.0359.MA Rev. c 10.12.2008 hrm 24.11.2010 hrm...
- Page 4 Mounting of rack for rearpanel frame Traverse oben im Korb- / ARENA -Set enthalten Upper traverse included in basket- / ARENA-Set Traverse en haut inclus dans le set de panier ou ARENA A=290 = 900.2592.xx A=390 = 900.2594.xx Schrauben erst nach der Korbbefestigung definitiv anziehen.
- Page 5 Mounting of basket Schrauben definitiv anziehen. Definite fastening of the screws. Visser les vis définitivement. 8 x M4x6 90° 90° Türabweiser am Korb montieren Install door deflector at the basket Butoirs de porte installer au panier Klick Türabweiser im Korb- / ARENA-Set enthalten. Door deflector clip included in basket- / ARENA-Set.
- Page 6 Mounting of rearpanel frame, guide plate, endstop bracket, follower Step 1: Loosen hex-nuts of rearpanel frame Step 2: Screw on rearpanel frame to cabinet sides Step 3: Tighten hex-nuts of rearpanel frame Spacer for: Frame inset Frame overlay Frame overlay Frame inset SW 10 Frameless...
- Page 7 Install pull-out frame click Don’t squeeze fingers Right Swivel Version, Don’t squeeze fingers change the rubber element click Left Swivel Version Dimensions in mm Inches are approximate 950.0359.MA Rev. c 10.12.2008 hrm 24.11.2010 hrm...
- Page 8 Place shelfs Place shelfs on hooks 950.0359.MA Rev. c 10.12.2008 hrm 24.11.2010 hrm...
