Elecro Engineering Spectrum Hybrid SH-55 Installation & Operating Manual

Uv + hydroxyl radical pool sanitiser

Advertisement

Quick Links

Spectrum Hybrid
UV + Hydroxyl Radical Pool Sanitiser
Installation & Operating Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spectrum Hybrid SH-55 and is the answer not in the manual?

Questions and answers

Summary of Contents for Elecro Engineering Spectrum Hybrid SH-55

  • Page 1 Spectrum Hybrid UV + Hydroxyl Radical Pool Sanitiser Installation & Operating Manual...
  • Page 2 www.elecro.co.uk...
  • Page 3: Important Notes

    Important Notes Congratulations on purchasing the Spectrum Hybrid UV + HO pool sanitising system, the latest in UV technology, manufactured in England to the highest standards. To ensure your new product will give years of trouble free service please carefully read the following instructions. Incorrect installation will affect your warranty.
  • Page 4: Product Overview

    Product Overview The Spectrum Hybrid is available in 55W single tube and 110W double tube formats, supplied complete with flow switch and either an analogue lamp life indicator and reset switch, or digital lamp life countdown with intelligent dosing pump. 55W Single Tube Unit BULB RETAINING BULB CAP...
  • Page 5 110W Double Tube Unit UV LAMP RETAINING CLIP UV LAMP CAP LOCKING NUT ‘O’ RING UV LAMP QUARTZ GLASS SLEEVE ELECTRONIC CONTROLLER ASSEMBLY FLOWTUBE COVER CONTROL BALLAST ASSEMBLY BRACKET MANIFOLD ASSEMBLY Fig 2. Note: Digital Model Shown www.elecro.co.uk...
  • Page 6: Positioning The Unit

    Positioning the Unit CAUTION: To prevent this unit falling into water, do not install above or alongside your pool. The Spectrum Hybrid unit is weatherproof but not waterproof; it must be installed in a dry weatherproof enclosure. The unit must be mounted on a flat vertical surface horizontally or vertically.
  • Page 7 110W POOL FILTER ELECRO HEATER PUMP Fig 4. Mounting the UV Unit The unit may be mounted on a wall or other suitable vertical surface that is structurally strong enough (for example: when full of water the unit is too heavy to mount onto a conventional wooden fence panel). The unit is supplied with a fixing kit.
  • Page 8 55W Single Tube Unit Raw plug x5 RAW PLUG x 4 Washer x5 WASHER x 4 Screw x5 SCREW x 4 Fig 5. www.elecro.co.uk...
  • Page 9 110W Double Tube Unit RAW PLUG x 5 SCREW x 5 Fig 6. WASHER x 5 www.elecro.co.uk...
  • Page 10 Mounting Continued 110W Double Tube Unit Fig 7. Horizontal mounting Water must enter low and exit high Vertical mounting Factory Default Optional reverse flow explained on page 10 55W Single Tube Unit Vertical mounting Factory Default Optional reverse flow explained on page 10 Horizontal mounting Water must enter low and exit high...
  • Page 11: Connection To The Water Supply

    Connection to the water supply The unit is supplied with unions to allow connection to 2" or 63-mm rigid pipe. Reducers are also supplied to allow connection to 50-mm or 1½" rigid pipe - see fig. 8. For connection to 63mm or 2" diameter pipe Fig 8.
  • Page 12: Flow Requirements

    Flow Requirements Minimum flow rate: 55W (single tube) and 110W (double tube) = 4m3/hour (4,000 litres per hour) Maximum flow rate: 55W (single tube) = 12m3/hour (12,000 litres per hour) 110W (double tube) = 24m3/hour (24,000 litres per hour) Your Spectrum Hybrid is factory set to accept input water flow entering on the left and exiting on the right, this can be reversed by rotating the flow switch 180 degrees (i.e ½...
  • Page 13 be carried out by a qualified electrician, who will provide a certificate of conformity upon completion of the work. The power supply must be fitted with a RCD with a rated residual operating current not exceeding 30mA. This unit must be installed inside a dry, weatherproof enclosure.
  • Page 14 RESET SWITCH LAMP LIFE INDICATOR Fig 9. www.elecro.co.uk...
  • Page 15 Lamp Life Indicator + Intelligent Dosing Pump (Digital) How to connect the suction tube to the dosing pump: This is how the completed assembly will look STEP ONE Components required: Foot Valve Strainer Tubing STEP TWO Unscrew securing cap anti-clockwise www.elecro.co.uk...
  • Page 16 STEP THREE Thread tube through the securing cap (1) and component (2), then push the pipe onto component (3) STEP FOUR Once all components are looped through the tubing tighten securing cap Connection point STEP FIVE Lastly unscrew the retaining gland and insert tube over Retaining the connection point.
  • Page 17 DIGITAL DISPLAY LED INDICATOR Fig 11. BUTTONS Language English OK ? Fig 12. The factory default setting for the language is English. To change to another language, press the buttons until the de- sired language appears, press OK to select and save. www.elecro.co.uk...
  • Page 18 The digital controller has three modes ie: • UV LAMP LIFE • DOSAGE Adjust Dose • TIMER Fig 13. To select a mode press the buttons until the desired mode is displayed then press the OK button to select that mode. Operation: When the unit is powered on the UV lamp is switched on, the UV lamp will switch off under the following conditions ie:...
  • Page 19 When the UV lamp(s) are replaced the lamp life timer must be reset to 9,000 hours. In the UV lamp life Reset UV Lamp To 9000 Hours mode select ‘Reset UV Lamp’ by pressing and releasing the O.K. but- ton, then immediately press and hold the O.K.
  • Page 20 Adjust Dose Fig 15. Adjust the dosage in 10ml steps using the buttons, when the required dosage is displayed press the O.K. button and the display will im- mediately show ‘SAVED’ indicating that the new value has been stored in the memory.
  • Page 21 EXAMPLE: Start time is set to 1 hour 5 minutes when the actual time is 10:10am therefore dosing will start at 11:15am on subsequent days. PLEASE NOTE that the time selected for dosing must be at a time when the main circulation pump is running. In the event of a power failure (and at every power on) the 24 hour timer will default to 2 minutes, when power is restored the start time will there- fore almost certainly be incorrect and will need to be reset by the user.
  • Page 22 STEP THREE Cut the two black securing ties at either end of the pipe. This will then release the tube, which can be discarded. STEP FOUR Take the replacement tube and re-attach connection points. Loop secur- ing ties in place in order to seal to the connection points. Once securely in place cut the excess tie and dispose of.
  • Page 23: Frost Protection

    Frost Protection It is essential that the unit is protected from frost during the winter months, or disconnected from the water and electricity supply and stored inside a dry weather proof enclosure. Lamp Replacement & Quartz Glass Cleaning (all models) Isolate from the electrical and water supplies before carrying out any maintenance.
  • Page 24 Wipe a little silicone grease or Vaseline (not silicone sealant) onto these threads. As these threads are only serviced periodically, this lubrication will help to prevent them binding together. Then refit and firmly hand tighten the compression fittings. Refit or replace the UV lamp(s) with a new one. Relocate the lamp holders and blue lamp holder shrouds ensuring that you match the correctly numbered lamp holder.
  • Page 25: Rohs Compliance Statement

    RoHS Compliance Statement Elecro Engineering Limited certify that our UV Pool sanitiser range complies in accordance with RoHS Directive 2011/65/EU on the restriction of hazardous substances. Waste of Electrical / Electronic Equipment This product complies with EU directive 2012/19/EU Do Not dispose of this product as unsorted municipal waste.
  • Page 26 Calculating Pool Volumes The following pages will show you how to calculate the volume of your pool. NB For pools with different depths: D1 + D2 = Average Depth If your pool has a sloping bottom, then take the deepest measurement (D2) and the shallowest (D1).
  • Page 27 Ellipses Depth (D) Volume = π (3.142) x A x B x Average Depth Irregular Shapes For irregular shapes, calculating the area is less accurate. You will need to draw up the pool accurately to scale on graph paper using a square on the paper to represent a metre (or foot) square of pool.
  • Page 28 Useful Conversions Cubic Metres to Litres = Multiply by 1000 Cubic Feet to Cubic Metres = Multiply by 0.0283168 UK Gallons to Litres = Multiply by 4.54609 Litres to Cubic Metres = Multiply by 0.001 Cubic Metres to UK Gallons = Multiply by 219.969 www.elecro.co.uk...
  • Page 29 11 Gunnels Wood Park Stevenage Hertfordshire SG1 2BH United Kingdom +44 (0) 1438 749 474 +44 (0) 1438 361 329 sales@elecro.co.uk | f: | e: www.elecro.co.uk © Copyright 2016 Z-INS-SH...
