AMC PRO DAB radio Music Player User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User
DAB radio
Manual
Music Player

Advertisement

Table of Contents
loading

Related Manuals for AMC AMC PRO DAB radio Music Player

Summary of Contents for AMC AMC PRO DAB radio Music Player

  • Page 1 User DAB radio Manual Music Player...

  • Page 2: Safety Instructions

    Safety instructions When using this electronic device, basic precautions The power supply should be undamaged and never share an outlet or extension cord with other devices. Never leave device plugged should always be taken, including the following: into the outlet when it is not being used for a long period of time. Care should be taken that objects do not fall into liquids and liquids would not be spilled on the device.

  • Page 3: Table Of Contents

    Table of contents Before you start Introduction ..............................2 Features ................................2 Operation Front panel ................................3 Rear panel................................3 IR remote control ............................4 Front panel operation ..........................5 Rear panel operation ..........................6 IR remote control operation ........................7 Specifications General specifications ..........................8 USER MANUAL DAB radio Music player...

  • Page 4: Before You Start

    Before you start Rack mount professional music player with built-in DAB and FM tuners. These professional player can be used 24 hours a day 7 days a week. They are carefully assembled with high quality components. Radio tuner with 20 radio station presets, RDS.

  • Page 5: Operation

    Operation Front Panel 1. Power switch 2. Preset buttons 3. SHIFT 4. Mute | 5. LCD display | 6. Mode 7. IR receiver 8. Down 9. Menu 10. Up 11. Info 12. Enter 13. Sleep 14. FM list 15. Navigation selector Rear Panel 1. Antenna connector 2.

  • Page 6: Ir Remote Control

    Operation IR remote control 1. Preset buttons 2. SHIFT 3. Mute 4. Sleep 5. FM list 6. Scan Mode 8. Menu 9. Info 10. Enter 11. Preset 12. Up 13. Down USER MANUAL DAB radio Music player...

  • Page 7: Front Panel Operation

    Operation Front panel operation LCD DISPLAY Display main receivers information. Radio station frequency, RDS information and menu. POWER SWITCH Press power switch to turn on/off the main power. MODE This buttons allows to change receivers working mode. DAB or FM tuner. PRESET BUTTONS These buttons are designed to recall or save radio station to the presets 1-10.

  • Page 8: Rear Panel Operation

    Operation Front panel operation SLEEP This button is designed for sleep time setting. Press SLEEP, then use Down or UP key to select SLEEP OFF or set sleep timer. In Order to confirm setting press Enter. INFO FM LIST Pressing this button in DAB mode, will change the content of the information Displays FM sation list. display such as signal strength, signal error rate, program type, time and date, channel frequency, and transfer rate.

  • Page 9: Ir Remote Control Operation

    Operation IR remote control operation MENU Press this button to enable menu. PRESET BUTTONS INFO These buttons are designed to recall radio station from the presets 1-10. Pressing this button in DAB mode, will change the content of the information display such as signal strength, signal error rate, program type, time and date, SHIFT BUTTON channel frequency, and transfer rate.

  • Page 10: General Specifications

    General Specifications Power supply ~230V/ 50Hz Power consumption 50 VA Output connector Stereo RCA FM frequency range 87.5 MHz –108 MHz DAB frequency range 174.928 MHz - 239.2 MHz Radio station presets Audio output level -6 dBu 0.3 % Antenna 75 Ω...
