- Page 1 GDR67088B Instructions for use GDR67102B GSR27178B GDR67122B GDR66122BZ GDR67122FB...
-
Page 3: Table Of Contents
Refrigerator-freezer Thank you for your confi dence in buying our appliance and congratulations on the excellent choice. We hope it will successfully serve its purpose for many years. The appliance is intended solely for household use. The lower part is the refrigerator intended for storage of fresh food at temperatures higher than 0°C. -
Page 4: Before Fi Rst Operation
Before fi rst operation • The appliance is manufactured in compliance with all relevant safety standards; however, it is recommended that persons with impaired physical, motional, or mental abilities, or persons with inadequate experience and knowledge, do not use the appliance without due supervision. The same recommendation applies to minors using the appliance. -
Page 5: A Few Tips On How To Save Power With Your Refrigerator-Freezer Combo
• Warning: To prevent any pollution be careful not to damage the insulation or refrigeration tubes at the rear wall during the installation, cleaning and disposal of the appliance. • Warning: Do not use any electrical devices inside the appliance, except for those explicitly recommended by the manufacturer. -
Page 6: Appliance Description
Appliance description Appliance interior equipment may change according to the appliance model. - Page 7 A. Refrigerator B. Freezer 1. Fan 2. Control unit 3. Folding egg tray (closed for 6, open for 12 eggs) 4. Bottle rack 5. Pull-out glass shelf – short 6. Pull-out glass shelf (height adjustable) 7. Snack+ pull-out drawer for snacks 8.
-
Page 8: Installation And Connections
Installation and connections Selecting the location • Place the appliance in dry and well aired room. The appliance operates best at temperature ranges indicated in the chart below. Relevant class of the appliance is indicated on the rating plate. Class Ambient temperature SN (subnormal) from + 10°C to + 32°C... -
Page 9: Changing The Door Opening Direction
Changing the door opening direction Changing the direction 1. Undo the latch A and door hinge B of the low temperature of low temperature compartment and remove the door C. compartment door 2. Rotate the door by 180°, mount them on the other side of the opening low temperature compartment, and attach the latch A and door hinge B to the other side of the cell. -
Page 10: Appliance With Electronic Control
Appliance with electronic control CONTROL UNIT I A Temperature setting and on/off knob B Signal light: on when the appliance is in operation C Fan boost key D Signal light: on when the fan boost is activated E Super freeze key F Signal light: on when Super freeze is activated G Digital refrigerator temperature display indicates actual temperature in the appliance in the range from +1°C to +9°C (or +3°C to +8°C for appliances equipped with the Zero+ drawer) - Page 11 CONTROL UNIT II Max 25W A Temperature setting and on/off knob B Signal light: on when the appliance is in operation C Acoustic alarm off key D Signal light: fl ashes when high temperature alarm is activated E Super freeze key F Signal light: on when Super freeze is activated G Digital refrigerator temperature display indicates actual temperature in the appliance in the range from +1°C to +9°C...
- Page 12 Switching the appliance Switch on the appliance by rotating the A knob towards the max. on/off position. To switch off the appliance, align the recess on the knob with the sign (appliance is still powered - there is still electric current in the appliance).
- Page 13 Super freeze function • Use this setting after switching on the appliance for the fi rst time, before cleaning, or when inserting a large amount of food. Press the E key (signal light F will light up). The setting will be switched off automatically after approximately two days. Open refrigerator door If refrigerator door is open for more than one minute, an acoustic alarm...
-
Page 14: Refrigerator Interior Equipment
Refrigerator interior equipment Shelf (Equipment depends on the model) • The shelves may be adjusted as you like using the guides in the refrigerator interior. • Each shelf is fi tted with a locking device at the back, which prevents it from being pulled out unintentionally. If you wish to pull out a shelf (to move to another position or for cleaning), please proceed as follows: 1. - Page 15 Interior side of the • Mounted on the refrigerator door are compartments (shelves refrigerator door or bins) intended fro storing cheese, butter, eggs, yoghurt and other smaller packages, tubes, cans, etc. There is a bottle shelf at the lower end of the door. •...
-
Page 16: Storage Of Food In The Refrigerator
Storage of food in the refrigerator Important precautions • Proper use of the appliance, adequately packed food, correct and hints temperature and hygienic precautions produce substantial impact on the quality of stored food. • Always respect the best before date, printed on the packaging. •... -
Page 17: Storing Food In The Zero+ Compartment
Storing food in the Zero+ compartment In the Zero+ compartment, food stays fresh three times as long as in a conventional refrigerator, retaining more fl avour and nutrients. Decay and loss of mass are slowed down; therefore, fruit and vegetables remain fresh and natural longer. Storage temperature is around 0°C (preset). - Page 18 Approximate storage Type of food Time time in the Zero+ Sausages, cold cuts, beef, pork, venison, up to 7 days raw meat poultry up to 5 days fi sh up to 4 days seafood up to 3 days Vegetables: cabbage, garlic, carrots up to 180 days celery, herbs up to 30 days...
-
Page 19: Storing Food In The Fresh+ Compartment
Storing food in the Fresh+ compartment The Fresh+ drawer allows storing a wide variety of fresh food to keep longer than in a conventional refrigerator. The food stays fresh longer, retaining the fl avour and nutrients. It lows down decay and loss of mass; therefore, fruit and vegetables remain fresh and natural longer. -
Page 20: Freezing And Storing Frozen Food
Freezing and storing frozen food Freezing procedure • Activate the super freeze function 24 hours before freezing fresh food: - control unit I and II: press the E key (signal light F will light up). After that, distribute the food evenly across the shelf in the upper position, making sure they are not in contact with the already frozen food packages. - Page 21 Storage periods of Recommended periods of storing frozen food in the freezer frozen food Food Period Fruit, beef from 10 to12 months Vegetables, veal, poultry from 8 to 10 months Venison from 6 to 8 months Pork from 4 to 6 months Chopped (minced ) meat 4 months Bread, pastry, TV-dinners, fat free fi...
-
Page 22: Defrosting The Appliance
Defrosting the appliance Automatic defrosting of Refrigerator needs no special defrosting procedure, because ice the refrigerator deposited at the inner back wall is defrosted automatically. Ice deposited on the inner back wall during the compressor operation is defrosted when the compressor stops operating, and condensed water drops are drained through the outlet in the inner back wall into the drain pan situated above the compressor where it evaporates. -
Page 23: Cleaning The Appliance
Cleaning the appliance Prior any cleaning attempt disconnect the appliance from the mains (see the control chapter for ON/OFF function), and pull the power cord from the mains wall outlet. Make sure to remove traces of any cleansing agents you had been using. -
Page 24: Troubleshooting Guide
Troubleshooting guide Fault: Cause/Remedy The appliance does not • Check if there is power in the socket and if the appliance is operate after connection to the switched on. mains: Cooling system operates • Ambient temperature too high. continuously without •... - Page 25 Fault: Cause/Remedy LED lighting does not work: • If the LED lighting no longer works, call an authorized Gorenje service technician. Signal light B is fl ashing: • If the signal light B is fl ashing, call a service technician. Error code displayed (certain •...
-
Page 26: Noise Level
Noise level The refrigerator – freezer appliances are cooled by the refrigeration system with a compressor (assisted by fan in certain models) whose operation may produce certain noise. The level of such noise depends upon the location, correct use and age of the appliance. •... - Page 28 COOLER 540 4ZV G+ 479390/en (10-14)
